ACE PLUS CORP.
EX-G013A v1.3 / EX-G013B v1.3
EX-G015 / EX-G016
EX-G083 / EX-G076B
HDMI 1.3 over Single CAT5 Distribution Series
User Manual
EX-G013B
EX-G013A
v1.3
v1.3
EX-G015
EX-G016
EX-G083
EX-G076
Page 1 of 18
Headquarters :
9F-2., No. 190 Sec. 2 Jung Shing Rd.,Hsin-dian,
Taipei, Taiwan 231
TEL: +886-2-2912-4201
FAX: +886-2-2912-3164
Website:
www.ace-plus.com
Advertisement
Table of Contents
Related Manuals for Ace Plus EX-G013A
Summary of Contents for Ace Plus EX-G013A
-
Page 1: User Manual
ACE PLUS CORP. EX-G013A v1.3 / EX-G013B v1.3 EX-G015 / EX-G016 EX-G083 / EX-G076B HDMI 1.3 over Single CAT5 Distribution Series User Manual EX-G013B EX-G013A v1.3 v1.3 EX-G015 EX-G016 EX-G083 EX-G076 Page 1 of 18 Headquarters : 9F-2., No. 190 Sec. 2 Jung Shing Rd.,Hsin-dian,... -
Page 2: Safety And Notice
Safety and Notice The HDMI over Single CAT5 Distribution Series, including EX-G013A v1.3 1x2 HDMI 1.3 over Single CAT5 Distribution Amplifier, EX-G015 2x8 HDMI 1.3 over Single CAT5 Distribution Amplifier, EX-G013B v1.3 1x2 HDMI 1.3 over Single CAT5 Cascading Distribution Amplifier, EX-G016 2x8 HDMI 1.3 over Single CAT5 Cascading Distribution Amplifier,... - Page 3 ACE PLUS CORP. Introduction The HDMI 1.3 over Single CAT5 Distribution Series provides the most flexible solution by which the high definition video and high quality audio can be transmitted to different locations over a long distance. The devices are cascadable, allowing you to extend HDMI/DVI compliant displays almost anywhere.
- Page 4 Allows cascading Perfectly integrated with other HDMI over CAT5 series products 1U rack mountable [EX-G015 / EX-G016]; wall mountable [EX-G013A v1.3/ EX-G013B v1.3] The length depends on the characteristics and quality of the cables. Higher resolutions and longer transmission distances require low skew cables (<25ns/100m) for best performance.
-
Page 5: Technical Specifications And Package Content
Operation temperature 0~40°C [32~104°F] Storage temperature -20~60°C [-4~140°F] Relative humidity 20~90% RH [no condensation] 1x EX-G013A v1.3 or EX-G013B v1.3 1x 5V power adapter Package Contents 1x User Manual Page 5 of 18 Headquarters : 9F-2., No. 190 Sec. 2 Jung Shing Rd.,Hsin-dian,... - Page 6 ACE PLUS CORP. Model Name EX-G015 EX-G016 Technical 2x8 distribution amplifier Role of usage Transmitter [TX] Transceiver [TRX] HDMI compliance HDMI 1.3c HDCP compliance Video bandwidth Single-link 225MHz [6.75Gbps] Video support 480i / 480p / 720p / 1080i / 1080p60 36-bit color depth...
- Page 7 ACE PLUS CORP. Model Name EX-G083 EX-G076B Technical Role of usage Receiver [long range RX] Receiver [short range RX] HDMI compliance HDMI 13c HDCP compliance Video bandwidth Single-link 225MHz [6.75Gbps] Video support 480i / 480p / 720p / 1080i / 1080p60 36-bit color depth...
-
Page 8: Panel Descriptions
4. Audio out: Plug in a local speaker here 5. HDMI Out: Connect to a HDMI display with a HDMI M-M cable here 6. RJ-45 Out: Link to EX-G013A for cascading; or link to EX-G083 or EX-G076B to another HDMI display with a CAT5e/6 LAN cable 7. - Page 9 8-to-F (longest-to-shortest transmission length). It is recommended to adjust from 7-to-0 or from F-to-8 to find the optimal visual experience. 3. RJ-45 In: Link to CV-57G-TX, EX-G013A, or EX-G013B with a CAT-5e/6 cable 4. Audio out: Plug in a local speaker here 5.
-
Page 10: Dip Switch
ACE PLUS CORP. EX-G083 HDMI 1.3 over Single CAT5 Receiver HDMI-OUT HDMI-OUT: Connect to a HDMI display with a HDMI M-M cable here. EQ: Adjust the 8-level equalization control knob to the received HDMI signals. 0 – 7 = strongest –... -
Page 11: Front Panel
ACE PLUS CORP. Set pin#2-ON [ ] firstly and then connect the HDMI Input to HDMI display through HDMI cable. Waiting for 20 seconds, the learning procedure will be accomplished. When update the EDID content with another display, you must set pin#2-OFF[ ] and repeat this procedure again. -
Page 12: Rotary Control
7. RJ-45 IN 1: for cascading from another EX-G016 or EX-G013B 8. HDMI IN 2: for connecting to video source, EX-G013A, EX-G017A, or another EX-G016 9. RJ-45 OUT: for connecting to display through EX-G083 or EX-G076B; or for cascading to another EX-G013B or EX-G016 10. - Page 13 ACE PLUS CORP. EX-G013B v1.3 Relays HDMI signals to next cascading device with one local display 1. Switch off all devices, including monitors. 2. Connect a local HDMI display to the HDMI Out of the EX-G013B and then connect a speaker to the 3.5mm audio socket.
- Page 14 ACE PLUS CORP. EX-G013B v1.3 Relays HDMI signals to next cascading device with one local display 1. Switch off all devices, including monitors. 2. Connect a local HDMI display to the HDMI Out of the EX-G013B and then connect a speaker to the 3.5mm audio socket.
- Page 15 ACE PLUS CORP. EX-G015 Broadcasts HDMI signals to 8 remote displays from either of two HDMI sources HDMI source #1 HDMI cable HDMI source #2 EX-G015 HDMI cable CAT5 cable HDTV#8 CAT5 cable up to 25m (80ft) EX-G076B CAT5 cable...
-
Page 16: Hdmi Pin Definition
ACE PLUS CORP. EX-G016 Broadcasts HDMI signals to 7 HDMI displays and cascade to another EX-G016 HDMI Pin Definition Pin 1 TMDS Data2+ Pin 8 TMDS Data0 Shield Pin 15 SCL Pin 2 TMDS Data2 Shield Pin 9 TMDS Data0–... - Page 17 ACE PLUS CORP. Notice 1. If the DVI or HDMI device requires the EDID information, please use EDID Reader/Writer to retrieve and provide DVI/HDMI EDID information. 2. All HDMI over CAT5 transmission distances are measured using Belden 1583A CAT5e 125MHz LAN cable and ASTRODESIGN Video Signal Generator VG-859C.
-
Page 18: Limited Warranty
ACE PLUS CORP. Limited Warranty The SELLER warrants the HDMI 1.3 over Single CAT5 Distribution Series to be free from defects in the material and workmanship for 1 year from the date of purchase from the SELLER or an authorized dealer. Should this product fail to be in good working order within 1 year warranty period,...
