- Page 1 Richter Optica info@richter-optica.com Instructions for Model: MDS2 Middle School Microscope...
- Page 2 Eyepiece 360° Rotatable Head Carrying Handle Revolving Nosepiece Rack Stop Objectives Stage Stage Clips Disc Coarse Focus Diaphragm Fine Focus Light Fuse On/Off Switch Light Rheostat...
-
Page 3: Before Use
Thank you for your purchase of a Richter Optica microscope. The information in this manual is provided to answer most questions that can arise when operating your microscope and to help you avoid unnecessary maintenance expenses in the future. Please carefully read instructions before operating microscope. Nomenclature used to describe components and controls are identified on opposite page. -
Page 4: Assembling The Microscope
ASSEMBLING THE MICROSCOPE 1. EYEPIECE: Remove the cap from the eyetube and insert the 10x eyepiece into the eyetube. 2. POWER CORD: Connect the power cord to the wall outlet (110~240V). 3. ADJUST ILLUMINATION: Turn the main power switch to the on position. Adjust the light intensity by rotating the rheostat control knob. -
Page 5: Possible Cause
TROUBLESHOOTING: Optical PROBLEM POSSIBLE CAUSE Dust or dirt on objective, illuminator or Dust or dirt in field of view. eyepiece. Disc diaphragm is not set properly. No cover glass in place. Poor image (low contrast or resolution) Too thick or thin cover glass being used. Greasy residue on eyepiece or lens. -
Page 6: Care And Maintenance
1. When not in use, cover the instrument with a dust cover and store in a place low in humidity where mold is not likely to form. 2. Proper handling of the microscope will ensure years of trouble free service. 3. If repair becomes necessary, please contact Richter Optica at info@richter-optica.com. - Page 7 LED Light Bulb Replacement 1. Unplug the microscope. 2. Unscrew the 4 screws in the corners of the bottom of the base plate. The screws are holding rubber feet onto the microscope. (See image at right). 3. When opening the base take care as wires will be connected to the microscope frame and pulling the frame too far from the base could disconnect wires.
