- Page 1 Richter Optica info@richter-optica.com Instructions for Models: HS-1M, HS1+1, HS-1D Compound Microscope...
- Page 2 Eyepiece Dual Observer Diopter Adjustment Nosepiece Safety rack stop Objective Lenses Stage Clips Stage Disc Diaphragm Coarse-focusing Knob Lamp House Fine-focusing knob Rheostat Control Base DUAL HEAD MODELS (HS-1+1, HS-1D Models) Iris Diaphragm MONOCULAR MODEL (HS-1M)
-
Page 3: Description Of Components
Thank you for your purchase of a Richter Optica microscope. The information in this manual is provided to answer most questions that can arise when operating your microscope and to help you avoid unnecessary maintenance expenses in the future. Please carefully read instructions before operating microscope. Nomenclature used to describe components and controls are identi ed on opposite page. - Page 4 Changing Magni cation Magni cation is changed by rotating the nosepiece until a di erent lens is moved into the optical path. Always turn the turret until you hear it “click”. This indicates that the lens is properly positioned. The standard lenses that are provided with your microscope are a wide eld 10x eyepiece (HS1+1, HS-1D Models come with 2 separate eyetubes as well as 2 eyepieces).
-
Page 5: Maintenance
Do not let the lens element come into contact with a wet slide surface, as prolonged contact with any moisture could damage the lens. If lens is exposed to moisture, promptly wipe with lens paper/micro ber cloth to remove moisture. Diopter adjustment for HS1+1 dual head model. - Page 6 Do not remove eyepieces or objective lenses to clean. Clean only the outer lens surface. Breathe on lens to dampen surface, then wipe with lens paper or use a cotton swab moistened with distilled water. Wipe lens with a circular motion, applying as little pressure as possible. Avoid wiping dry lens surface as lenses are scratched easily.
-
Page 7: Troubleshooting
TROUBLESHOOTING Problem Reason for Problem Solution Have quali ed service technician Outlet inoperative. repair outlet. Light Fails to operate. Plug into outlet. AC Power cord not connected. Have quali ed service technician Bulb burned out, Fuse blown replace bulb and/or fuse Reason for Problem Problem Solution...
