- Page 1 Richter Optica info@richter-optica.com Instructions for Model: HSX1 High School Microscope...
- Page 2 Eyepiece 360° Rotatable Head Objectives Carrying Handle Revolving Nosepiece Rack Stop Slide Holder Focus Tension Control Coarse Focus Stage Abbe Fine Focus Condenser Light X & Y Mechanical Stage Controls Power On/Off Cord Switch Insertion Light Rheostat Fuse...
-
Page 3: Before Use
Thank you for your purchase of a Richter Optica microscope. The information in this manual is provided to answer most questions that can arise when operating your microscope and to help you avoid unnecessary maintenance expenses in the future. Please carefully read instructions before operating microscope. Nomenclature used to describe components and controls are identified on opposite page. -
Page 4: Using The Microscope
ASSEMBLING THE MICROSCOPE 1. POWER CORD: Connect the power cord to the wall outlet (110~240V). Insert 3 AA batteries into compartment in base on the bottom of microscope. 2. ADJUST ILLUMINATION: Turn the main power switch to the on position. Adjust the light intensity by rotating the rheostat control knob. -
Page 5: Possible Cause
TROUBLESHOOTING: Optical PROBLEM POSSIBLE CAUSE Dust or dirt on objective, illuminator or Dust or dirt in field of view. eyepiece. Iris diaphragm is not set properly. No cover glass in place. Poor image (low contrast or resolution) Too thick or thin cover glass being used. Greasy residue on eyepiece or lens. -
Page 6: Care And Maintenance
1. When not in use, cover the instrument with a dust cover and store in a place low in humidity where mold is not likely to form. 2. Proper handling of the microscope will ensure years of trouble free service. 3. If repair becomes necessary, please contact Richter Optica at info@richter-optica.com. - Page 7 LED Light Bulb Replacement 1. Unplug the microscope. 2. Unscrew the single screw in the center of the bottom of the base plate (image at right). 3. When opening the base take care as wires will be connected to the microscope frame and pulling the frame too far from the base could disconnect wires.
