- Page 1 Core Health & Fitness Glute Drive OWNER’S MANUAL...
-
Page 2: Table Of Contents
TABLE OF CONTENTS PRODUCT SPOTLIGHT ............................. 2 IMPORTANT SAFETY INSTRUCTIONS ............................. 3 ..................3 Warnings IMPORTANT LABEL LOCATIONS ............................. 5 OPERATIONS ............................. 6 INSTALLATION ............................. 7 MAINTENANCE ............................. 9 SUPPORT AND SERVICE ............................11 WARRANTY ............................12 Page 1... -
Page 3: Product Spotlight
PRODUCT SPOTLIGHT NP-L1131 Glute Drive Overall Weight Width Length Height Max User Weight Max Load Weight 202 lbs (92 kg) 60 in (152 cm) 62 in (157 cm) 35 in (89 cm) 0-350 lbs (0-158 kg) 0-360 lbs (0-163 kg) All products may be covered by US and Foreign Patents and Patents Pending. -
Page 4: Important Safety Instructions
Read all warnings posted on the machine. Health related injuries may result from incorrect or excessive use of exercise equipment. NAUTILUS strongly recommends you to encourage your members to discuss their health program or fitness regimen with a health care professional, especially if you or they have not exercised for several years, are over 35, or have known health conditions. - Page 5 Nautilus will provide service and maintenance training at the equipment removed from service until the repair our corporate facility upon request or in the field if proper is made.
-
Page 6: Important Label Locations
IMPORTANT LABEL LOCATIONS This page shows examples of the Nautilus® Leverage Strength® warning labels and communication stickers placed on the equipment as part of the manufacturing process. It is critical that owners maintain the integrity and placement of these stickers. If you find any stickers missing or damaged each sample indicated includes its corresponding part number so that replacements may be ordered. -
Page 7: Operations
OPERATIONS Page 6... -
Page 8: Installation
INSTALLATION GENERAL NOTES: Required Tools • 13mm Box / Open-End Wrench • 4mm Hex Key Socket • Unless otherwise noted Loctite • Torque Wrench 242/243 or equivalent thread locker must be used on all threaded fasteners. (Do not use thread locker when a Nyloc nut is used.) •... - Page 9 Assembly Instructions Install the four (4) rubber feet onto the bottom of the frame. Use a 6mm allen key and a 16mm open-ended wrench to secure the foot plate to the frame using four (4) pieces each of the M10 x 30mm screw, M10 flat washer, and M10 nylock nut.
-
Page 10: Maintenance
MAINTENANCE With durable, high performance components, this equipment is designed for heavy usage with minimal maintenance required. To keep it in top condition, perform regular daily, weekly and monthly preventive maintenance routines out- lined below. The safety and integrity of this machine can only be maintained when the equipment is regularly examined for damage and wear and repaired. - Page 11 Note – do not use cleaners that contain solvents, alcohol or abrasives. Inspection Visual inspection of your Nautilus® units will insure a safe environment for your clients and alert you to any issues that may require maintenance prior to equipment failure. Proper, timely visual inspec- tion is a critical component to the long term care of your product.
-
Page 12: Support And Service
SUPPORT AND SERVICE The Nautilus Support website provides a wealth of resources to help you get the best experience from your Inspiration Strength unit. It is important to check the website periodically for Owner’s Manual and Installation Instructions, Service Bulletins, and other information. The resources include: •... -
Page 13: Warranty
WARRANTY Core Health & Fitness, LLC Limited Warranty Commercial Fitness Products CORE HEALTH & FITNESS, LLC, warrants to the original purchaser that its Commercial Fitness Products are free of defects in workmanship and materials. Mechanical parts are covered for a period of two (2) years from date of purchase. Electronic parts are covered for one (1) year from the date of purchase. - Page 14 © 2018 CORE HEALTH & FITNESS, LLC PART NUMBER 620-8651, REV A...
