- Page 1 CORE HEALTH & FITNESS Glute Drive OWNER’S MANUAL...
-
Page 2: Table Of Contents
TABLE OF CONTENTS IMPORTANT SAFETY INSTRUCTIONS ........................2 IMPORTANT LABEL LOCATIONS ........................4 PRODUCT SPECIFICATIONS ........................6 OPERATIONS ........................7 ASSEMBLY ........................8 MAINTENANCE ........................11 TOOLS ..............11 MAINTENANCE SCHEDULE ..............12 SUPPORT & SERVICE ........................13 Page 1... -
Page 3: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS WARNING! Before using this product, it is essential to read the ENTIRE Owner’s Manual and ALL installation instructions. The Owner’s Manual describes equipment setup and instructs members on how to use correctly and safely. Read all warnings posted on the machine. Health related injuries may result from incorrect or excessive use of exercise equipment. - Page 4 Ensure all adjustment and locking features are properly secured before using the equipment. 10. Use only replacement components supplied by Nautilus®. Substitutes are forbidden and will void all warranties. 11. Wear proper exercise clothing and athletic shoes during a workout. Avoid wearing loose clothing.
-
Page 5: Important Label Locations
IMPORTANT LABEL LOCATIONS This page shows examples of the warning labels and communication stickers placed on the equipment as part of the manufacturing process. It is critical that owners maintain the integrity and placement of these stickers. If you find any stickers missing or damaged the replacement numbers are shown on the support site. See Support and Service to order replacements. - Page 6 050-5594 INSPECT THE MACHINE PRIOR TO USE. DO NOT USE EQUIPMENT IF SEATBELT IS CUT OR HAS ABRASIONS THROUGH THE BELT BADGE,NAME,GLUTE DRIVE OR THE BELT CLASP DOES NOT FASTEN. IMMEDIATELY REPORT WORN, LOOSE OR DAMAGED EQUIPMENT TO MANAGEMENT AND DO NOT USE EQUIPMENT UNTIL REPAIRED.
-
Page 7: Product Specifications
PRODUCT SPECIFICATIONS Fig. 3 NP-L1131 Glute Drive Unit Weight Width Length Height Max User Weight Max Load Weight Page 6... -
Page 8: Operations
OPERATIONS Page 7... -
Page 9: Assembly
ASSEMBLY Metric Steel Bolts Torque Specifications Bolt Size Thread Pitch Torque, N-m (lbs-ft) 1.25 10 to13.5 (8 to10) Required Tools: 1.25 25.5 to 28.5 (19 to 21) • Metric Allen Key Set 10mm 1.75 55.5 to 58 (41 to 43) •... - Page 10 PROCEDURE 1. Swing the arms up and forward until they stop. Fig. 4 Fig. 5 2. Use a 16mm socket to install the four (4) pieces each of the M10 x 35mm hex head screws and M10 flat washers to attach the seat pad to the frame. Page 9...
- Page 11 3. Remove the pivot shaft from the frame prior to mounting the back rest assembly. (Fig. 6) 4. Install the seat by lowering the back rest assembly into position, then inserting the shaft into the frame and through the back-rest assembly.
-
Page 12: Maintenance
MAINTENANCE TOOLS Working on this product will require basic and/or sometimes specialty tools based on the type of service that will be performed at any time. To assist, we recommend having the tools listed available when performing maintenance. Tool Metric Allen Key Set Screwdriver Set, Phillips Metric Open-Ended Wrench Set Screwdriver Set, Flat... -
Page 13: Maintenance Schedule
MAINTENANCE SCHEDULE With durable, high performance components, this equipment is designed for heavy usage with minimal maintenance required. To keep it in top condition, perform regular daily, weekly and monthly preventive maintenance routines outlined below. The safety and integrity of this machine can only be maintained when the equipment is regularly examined for damage and wear and repaired. -
Page 14: Support & Service
SUPPORT & SERVICE For Technical Support, Service, Parts Orders or any Customer Service needs, please contact us direct by phone, email, or through our 24 hour support site: GLOBAL SUPPORT CENTER 4400 NE 77th Avenue, Suite 300 Vancouver, WA 98662 Tel: (360) 326-4090 •... - Page 15 THIS PAGE INTENTIONALLY BLANK Page 14...
- Page 16 PART NUMBER 620-8651, REV C All rights reserved. Star Trac, the Star Trac logo and StairMaster are registered trademarks of Core Health & Fitness, LLC. Schwinn and Nautilus are registered trademarks of Nautilus Inc. used under license to Core Health & Fitness LLC. Throwdown is a registered trademark of Throwdown Industries, LLC.
