- Page 1 Anybus ® WLAN Access Point IP67 STARTUP GUIDE SP2383 EN 1.1 ENGLISH...
-
Page 2: Important User Information
HMS Industrial Networks AB has intellectual property rights relating to technology embodied in the product described in this document. These intellectual property rights may include patents and pending patent applications in the USA and other countries. Anybus ® WLAN Access Point IP67 Startup Guide SP2383 EN 1.1... -
Page 3: About This Document
About This Document 3 (12) About This Document This document describes how to install the Anybus WLAN Access Point IP67 and set up a basic configuration. For additional documentation and software downloads, FAQs, troubleshooting guides and technical support, please visit www.anybus.com/support. -
Page 4: Installation
A minimum distance of 50 cm between the devices should also be observed to avoid interference. The Anybus WLAN Access Point IP67 can be screw-mounted onto a stable flat surface using the included wall mounting plate. It can also be pole-mounted using the included adjustable steel band straps. - Page 5 Installation 5 (12) Overview 1, 2 Antenna connectors Power connector (M12) LED indicators Reset button Ethernet connector (M12) Anybus ® WLAN Access Point IP67 Startup Guide SP2383 EN 1.1...
-
Page 6: Wall Mounting
The plate can be attached vertically or horizontally. Thread the two supplied metal mounting straps through the large slots on the mounting plate and then put the straps around the pole. Anybus ® WLAN Access Point IP67 Startup Guide SP2383 EN 1.1... - Page 7 The Ethernet connector is an 8-pin A-coded M12 type connector. The Ethernet port supports PoE (Power over Ethernet) compliant with IEEE 802.3af. Function BI_DC+ BI_DD+ BI_DD- BI_DA- BI_DB+ BI_DA+ BI_DC- BI_DB- Anybus ® WLAN Access Point IP67 Startup Guide SP2383 EN 1.1...
-
Page 8: Led Indicators
WLAN traffic Factory Reset To restore the factory default settings, press and hold RESET on the front panel until the power LED indicator(s) starts to flash, then release the button. Anybus ® WLAN Access Point IP67 Startup Guide SP2383 EN 1.1... - Page 9 9 (12) Configuration Anybus WLAN Access Point IP67 is configured through a web interface which is accessed by pointing a web browser to the IP address of the unit. The default IP address is 192.168.0.2. The computer accessing the web interface must be in the same IP subnet as the access point.
-
Page 10: Technical Data
Protection class IP67 Certifications See datasheet For more technical details and specifications, visit www.anybus.com/support. Disposal and recycling You must dispose of this product properly according to local laws and regulations. Because this product contains electronic components, it must be disposed of separately from household waste. When this... - Page 11 Technical Data 11 (12) Dimensions All measurements are in mm. Anybus ® WLAN Access Point IP67 Startup Guide SP2383 EN 1.1...
- Page 12 last page © 2018 HMS Industrial Networks Box 4126 300 04 Halmstad, Sweden info@hms.se SP2383 EN 1.1 / 2018-08-20 / 9143...
