Quick Installation Guide Doc. no.: 9.17.098A Date: 19-03-2018 Starting up EL-FLOW®Select in 10 steps...
Page 2
9.16.118 · The instrument manual and hook-up diagrams can be downloaded from the EL-FLOW® Select product pages on the Bronkhorst website: www.bronkhorst.com/products · Other documents can be found on our general download page (www.bronkhorst.com/downloads) Starting up Check functional properties Before installing the instrument, check if the properties stated on the instrument label match your requirements: ·...
Page 3
This principle also applies to digital operation. Digital RS232 operation Connecting the instrument with an RS232 cable to a Windows computer enables the use of the free Bronkhorst® software for Windows, such as FlowDDE and FlowPlot.
Page 4
(this can be done while purging). Adjusting zero point The zero point of each Bronkhorst® flow meter is factory adjusted. If required, the zero point can be re-adjusted via RS232 or with the multifunctional switch. Procedure for adjustment with the multifunctional switch: ·...
