- Page 1 Matchbox Demo User Manual Intelligent Proximity Sensing Rolf Weber | August 2013...
-
Page 2: Table Of Contents
Matchbox Demo Manual Page 1. Demo Kit Contents 2. Getting Started 3. Modes 4. Software Installation 5. Graphical User Interface 6. PCB... -
Page 3: Demo Kit Contents
1. Demo Kit Contents Battery pack with Sensor demo Micro USB with Micro USB connector jack 3 x AAA USB cable batteries... -
Page 4: Getting Started
2. Getting Started Use the battery pack or USB cable to power the demo. 1a. Battery Pack 2. Operating the demo • Insert AAA batteries in the battery pack • Connect the battery pack to the demo • Switch on battery pack 1b. -
Page 5: Modes
3. Modes Proximity sensing Touch (1”, 4” & 6”) Tap indicator LED to Place hand over turn on/off. Hold finger indicator LED at down to increase/ respective distance for decrease brightness. on. Remove hand for off. Slide Wave Slide finger across the Wave hand left- right- two indicator LEDs for left once for on. -
Page 6: Software Installation
4. Software Installation Go to: http://ledlight.osram-os.com/matchboxdemo... -
Page 7: Graphical User Interface
5. Graphical User Interface File name | ORG CODE | Initial Title/Occasion | MM/DD/YYYY... - Page 8 5. Graphical User Interface Proximity sensor parameters: • Active LED indicator • Display mode: • shows all events • shows events above threshold only...
- Page 9 5. Graphical User Interface Ambient light sensor parameters: • ALS lower threshold • ALS upper threshold • Actual ALS readings in counts • Display mode: • shows all events • shows events above upper or below lower threshold only...
- Page 10 5. Graphical User Interface • Counter of measurements • Counter limit • Save data: Active / non active • Display data: Active / non active • Data saved in shown excel files • Data in new file or appended • Display of measured prox and ALS values...
- Page 11 5. Graphical User Interface Run Mode: • Preset: Takes values stored on demo board • Screen Values: Takes values from GUI Settings: • Saves GUI values in excel file • Reads GUI values from excel file...
- Page 12 5. Graphical User Interface Application Mode: • 1 inch Prox. • 4 inch Prox. • 6 inch Prox. • Slide • Rotary • Touch function • Wave detection • ALS...
-
Page 13: Pcb
6. PCB: Top view Externally switched SFH 7743 SFH 7770 E6: SFH 4059S LED for application selection 3 prox. channels and ALS for long range SFH 4059 LEDs... - Page 14 6. PCB: Side view Display SCDQ 5544 Q for application mode display...
- Page 15 6. PCB: Bottom view Microcontroller Microchip PIC18F46J50 USB Micro connector for I²C and USB communication...
-
Page 16: Thank You
Thank You. - Page 17 Mouser Electronics Authorized Distributor Click to View Pricing, Inventory, Delivery & Lifecycle Information: Osram Opto Semiconductor MATCHBOX DEMO...
