Troubleshooting
Table A-3 and Table A-4 list the two (2) Tri-Color LED Status/Error Code indications for the Recycler
Unit Assembly.
Left LED
Flashes or lit a Red,
Extinguished (Out)
Flashes or lit a Red, Green
or Yellow Color
Flashes (Green)
Lit (Red)
Lit (Yellow)
Lit (Green)
*. This condition can exist when the UBA-RC is not performing a Banknote storage, and an error has occurred.

Table A-4 Various Recycler Unit LED Flashing Error Code Conditions

LED Flashes
™
0 UBA
1 UBA-RC
Unit disabled to confirm that the RC1 Space Transport Motor is performing correctly.
2
Unit disabled to confirm that the RC2 Space Transport Motor is performing correctly.
3
Unit disabled to confirm that the RC1 Flapper is performing correctly.
4
Unit disabled to confirm that the RC2 Flapper is performing correctly.
5
Unit disabled to confirm that the Lifter is performing correctly.
6
Banknote Jam occurred in the Transport Path when storing a Banknote into the RC1 Space.
7
Banknote Jam occurred in the Recycler Unit when storing a Banknote into the RC1 Space.
8
Banknote Jam occurred in the Transport Path when storing a Banknote into the RC2 Space.
9
Banknote Jam occurred in the Recycler Unit when storing a Banknote into the RC2 Space.
10
Banknote Jam occurred in the Transport Path when storing a Banknote in the Cash Box.
11
Banknote Jam occurred in the Cash Box when storing a Banknote to the Cash Box.
12
Banknote Jam occurred in the Transport Path when dispensing a Banknote from the RC1 Space.
13
Banknote Jam occurred in the Recycler Unit when dispensing a Banknote from the RC1 Space.
14
Banknote Jam occurred in the Transport Path when dispensing a Banknote from the RC2 Space.
15
Banknote Jam occurred in the Recycler Unit when dispensing a Banknote from the RC2 Space.
16
Unit disabled to access to the EEPROM, or the Sensors are not calibrated.
17
Double Note Detection Sensor Magnification Error.
18
P/N 960-100928R_Rev. 3 {EDP #192692}
UBA-RC™ Series Banknote Recycler

Table A-3 Recycler Unit LED Code Conditions

Right LED
While storing Banknotes, or during an error occurring when Banknotes are being
stored. Count the flashes of the specific Color to define the error condition being
Green
or Yellow Color indicated (see Table A-4 "Various Recycler Unit LED Flashing Error Code
Conditions " for more detail).
While dispensing Banknotes, or during an error occurring when dispensing
Banknotes. Count the flashes of the specific Color to define the error condition
Extinguished (Out)
being indicated (see Table A-4 "Various Recycler Unit LED Flashing Error Code
Conditions " for more detail).
A Stand-by
Flashes (Green) error condition being indicated (see Table A-4 "Various Recycler Unit LED
Flashing Error Code Conditions " for more detail).
Lit (Red) An UBA-RC
Lit (Yellow) Downloading UBA-RC
A Reset was not performed after power was supplied.
Lit (Green)
Transport Unit Performance Error.
™
Motor Speed Error.
Causes
*
Error occurred. Count the flashes of the specific Color to define the
™
Software booting error occurred.
™
Software into the Unit.
Error Causes
© 2018, JAPAN CASH MACHINE CO., LTD.
A - 3
Appendix A
