Host Application Objects
Extended
# Name
7 Manufacturer
Hardware Version
8 Manufacturer
Software Version
-
9 - 13
14 Default PDO map
configuration
®
Anybus CompactCom ™ 30 Network Guide
Access Data Type Default
Value
Get Array of Object entry
CHAR (Max. 1009h not
24 bytes) implemented
x.yy
Get Array of
CHAR (Max.
24 bytes)
- - -
Get UINT8 00h
Comment
Specifies the value of object entry 1009h (Man-
ufacturer Hardware Version)
Replaces object entry 100Ah (Manufacturer
Software Version)
(reserved)
00h: Standard default PDO mapping
(minimalistic mapping)
01h: Use all available ADIs for de-
fault mapping (no consistency
checking of the mapping is
done). This must be maintained
by the application by ADI map-
ping order and ADI data typed
mapped.
02h - FFh (reserved)
