Manual 26283 L-Series In-Line Power Module Chapter 1. General Information Purpose and Scope The purpose of this manual is to provide the necessary background information for applying the In-Line Power Module to the L-Series actuator, used on reciprocating engines. Topics covered include mechanical installation and electrical wiring.
Chapter 3. Unpacking Be careful when unpacking the module. Check the unit for signs of damage, such as bent or dented panels, scratches, and loose or broken parts. Notify the shipper and Woodward if damage is found. Woodward...
Manual 26283 L-Series In-Line Power Module Chapter 3. Power Module Electrical Installation Introduction This chapter provides instructions on how to connect the in-line power module into a system using an L-Series actuator. A wiring pinout of the power module, as viewed by looking into the connector feature, is shown in Figures 3-1a and 3-1b.
L-Series In-Line Power Module Manual 26283 Connector The following Deutsch connector components are recommended for harness designs: Recommended Mating Connector DT06-12SB-EP20 (barbed entry point for heat shrink shroud) Secondary Lock W12S-P012 Sockets 0462-201-16141, or optionally 0462-201-16141 The use of proper wire type and wiring practices is critical to operation.
Manual 26283 L-Series In-Line Power Module connector connector Connector Pinout as Viewed Looking Into Power Module Mates with Deutsch # DT06-12SB-EP20 Figure 3-1b. Power Module Connector Pin Arrangement Connector Pin # Description Comment Input Power – Ground for 18–32 V Input Power...
0 Vdc. Woodward recommends using a 6 A fuse on the power supply line feeding pin 12 of the power module. The input power must be fused. Failure to fuse the power module could, under exceptional circumstances, lead to personal injury, damage to the control valve, and/or explosion.
Manual 26283 L-Series In-Line Power Module The power module does not include any on-board diagnostics for loss of output power. Because of this, it is recommended that the end user configure the status output of the L-Series actuator to be active during normal operation.
L-Series In-Line Power Module Manual 26283 Mounting Hardware Use M5 or #10 fasteners torqued to 4 Nm (35 lb-in) to attach the power module to the mounting bracket. Use four #10 external tooth shaped washers to insure proper chassis ground. The bracket and attaching hardware must be designed to hold the weight and to withstand the vibration associated with use in an on- engine environment.
A current list of Woodward Business Partners is available at www.woodward.com/directory. Product Service Options Depending on the type of product, the following options for servicing Woodward products may be available through your local Full-Service Distributor or the OEM or Packager of the equipment system.
To prevent damage to electronic components caused by improper handling, read and observe the precautions in Woodward manual 82715, Guide for Handling and Protection of Electronic Controls, Printed Circuit Boards, and Modules.
Field Service engineering on-site support is available, depending on the product and location, from one of our Full-Service Distributors. The field engineers are experienced both on Woodward products as well as on much of the non- Woodward equipment with which our products interface.
Manual 26283 Technical Assistance If you need to contact technical assistance, you will need to provide the following information. Please write it down here before contacting the Engine OEM, the Packager, a Woodward Business Partner, or the Woodward factory: General...
Manual 26283 L-Series In-Line Power Module Appendix A. Acronyms/Abbreviations electromagnetic compatibility Fuel Control Valve inputs/outputs L-Series Woodward electronic engine control that contains both a rotary actuator and a controller circuit board original equipment manufacturer Woodward...
L-Series In-Line Power Module Manual 26283 Appendix B. Power Module Specifications Specifications Power Supply 24 V systems (18–32 Vdc) reverse polarity protection, 2 A max Power Consumption 36 W maximum (2 A at 18 V) at 25 °C Mass/Weight 499 g (1.1 lb) Power-Up to Operation Time <10 ms...
