Display Items - Pivot 3-drive PRO User Manual

Degree of Acceleration Monitor
• Degree of Acceleration Monitor shows the rate of acceleration output to the ECU
where 0 represents the pedal not being pressed in and 100 equals when the
pedal is fully pressed down.
• Displays accelerator opening in units of 1% from 5 to 100%.
(When it is 100%, 00. is displayed.)
1
Check acceleration during ECO driving
USE
To ensure reduced fuel
consumption during
acceleration the degree of
acceleration should be
between 15% and 25%. To
further improve results use
ECO Mode when wishing to
save fuel.
2
Check acceleration during regular driving
USE
Please use to check the degree of acceleration for any type of driving, not just ECO Mode.

Display Items

Display Items
Display
(e.g. 32%)
6
USE
With the ignition in the ON position and
-
under NORMAL Mode press in the pedal
until it reaches 40%, if the mode is
0 0
changed to P7 the display should read
% %
100 100 100
% %
ECO
67 (67%) and if placed in E5 the display
should change to 27 (27%).
Note: The actual display may differ slightly.
Details
POWER Mode (higher number = higher response)
RESPONSE Mode (higher number = higher response)
ECO Mode (higher number = lower response)
NORMAL (Normal Performance)
Degree of Acceleration
Degree of Acceleration (100%)
Displays the amount of pressure placed on the accelerator pedal.
(output signal) [5–100%, 1% unit .]
Acceleration (output)
3
Check control status
Display for Settings
Degree of
3-drive
PRO
(20%)
Press down on pedal.
In NORMAL Mode
4 0
%
Switch mode to Switch mode to
P7
Display Details
Initial Settings Mode
Position when accelerator is
not pressed down
Position when accelerator is
fully pressed down
Settings Completed
P POWER
r
RESPONSE
E ECO
E5
