GE PVM9179, PSA9120, PSA9240 Installation Instructions Manual
  1. Manuals
  2. Brands
  3. GE Manuals
  4. Cooktop
  5. PVM9179, PSA9120, PSA9240
  6. Installation instructions manual

GE PVM9179, PSA9120, PSA9240 Installation Instructions Manual

Cooktop oven
Hide thumbs Also See for PVM9179, PSA9120, PSA9240:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Owner's Manual, Instruction and Installation Manual
Installation
Instructions
Questions? Call 800.GE.CARES (800.432.2737)
BEFORE YOU BEGIN
Read these instructions completely and carefully.
IMPORTANT –
instructions for local inspector's use.
IMPORTANT –
governing codes and ordinances.
Note to Installer –
instructions with the Consumer.
LA SECCIÛN EN ESPAÒOL EMPIEZA
EN LA P·GINA 25.
Save these
Observe all
Be sure to leave these
PVM9179, PSA9120, PSA9240
or
Visit our Website at:
Note to Consumer –
for future reference.
– Installation of this appliance requires basic
mechanical and electrical skills.
Proper installation is the responsibility of the installer.
Product failure due to improper installation is not
covered under the Warranty.
GEAppliances.com
Keep these instructions
READ CAREFULLY.
KEEP THESE INSTRUCTIONS
.

Advertisement

Table of Contents
loading

Related Manuals for GE PVM9179, PSA9120, PSA9240

Summary of Contents for GE PVM9179, PSA9120, PSA9240

  • Page 1 Installation Instructions PVM9179, PSA9120, PSA9240 Questions? Call 800.GE.CARES (800.432.2737) GEAppliances.com Visit our Website at: BEFORE YOU BEGIN Read these instructions completely and carefully. Note to Consumer – Keep these instructions for future reference. IMPORTANT – Save these – Installation of this appliance requires basic instructions for local inspector’s use.

  • Page 2: Table Of Contents

    Installation Instructions Recirculating ..........19–22 CONTENTS Attach Mounting Plate to Wall ....19 General information Preparation of Top Cabinet...... 19 Important Safety Instructions........3 Adapting Blower Electrical Requirements ..........3 for Recirculation ........20, 21 Hood Exhaust ..............4, 5 Mount the Oven ........21, 22 Damage –...

  • Page 3: Important Safety Instructions

    Installation Instructions IMPORTANT SAFETY INSTRUCTIONS A qualified electrician must perform a ground continuity Where a standard two-prong wall receptacle is check on the wall receptacle before beginning the encountered, it must be replaced with a properly installation to ensure that the outlet box is properly grounded three-prong wall receptacle, installed by a grounded.

  • Page 4: Hood Exhaust

    Installation Instructions HOOD EXHAUST NOTE: OUTSIDE TOP EXHAUST (EXAMPLE ONLY) The following chart describes an example of one possible ductwork installation. EQUIVALENT NUMBER EQUIVALENT DUCT PIECES LENGTH USED LENGTH Roof Cap 24 Ft. 24 Ft. 12 Ft. Straight Duct 12 Ft. 12 Ft.
  • Page 5 Installation Instructions Maximum duct length: NOTE: If you need to install ducts, note that the total duct length of 3 x 10 rectangular or 6 diameter round duct For satisfactory air movement, the total duct length of x 10 rectangular or 6 diameter round duct should Outside ventilation requires a HOOD EXHAUST DUCT.

  • Page 6: Damage - Shipment/Installation

    Installation Instructions PARTS INCLUDED DAMAGE – SHIPMENT/ INSTALLATION ADDITIONAL PARTS If the unit is damaged in shipment, return PART QUANTITY the unit to the store in which it was bought for repair or replacement. Top Cabinet If the unit is damaged by the customer, repair or Template replacement is the responsibility of the customer.

  • Page 7: Tools You Will Need

    Installation Instructions TOOLS YOU WILL NEED Ruler or tape measure and straight edge Pencil Carpenter square # 1 and #2 Phillips (optional) screwdriver Tin snips (for cutting damper, if required) Scissors Electric drill with 3 16 7 16 (to cut template, if drill bits necessary) Filler blocks or scrap...

  • Page 8: Placement Of Mounting Plate

    Installation Instructions PLACEMENT OF THE MOUNTING PLATE REMOVING THE OVEN FROM FINDING THE WALL STUDS THE CARTON/REMOVING THE MOUNTING PLATE Remove the box containing the installation instructions, filters, exhaust adaptor, damper and the small hardware bag. Do not remove Wall the foam packing protecting the front of the oven.

  • Page 9: Determining Wall Plate Location

    Installation Instructions DETERMINING WALL PLATE LOCATION UNDER YOUR CABINET Plate position – beneath framed recessed Plate position – beneath flat bottom cabinet bottom cabinet Mounting Plate Tabs Mounting Plate Tabs Touching the Back Touching the Cabinet Frame Bottom 30 to Cooktop Plate position –...

  • Page 10: Aligning The Wall Plate

    Installation Instructions ALIGNING THE WALL PLATE Hole B Draw a Hole A Vertical Line on Wall from Center of Top Cabinet Hole D Hole C Area E CAUTION: fingers on sharp edges. Draw a vertical line on the wall at the center of the 30 NOTE: Holes C and D are inside area E.

  • Page 11: Installation Types

    Installation Instructions INSTALLATION TYPES (Choose A, B or C) This oven is designed for adaptation to the following NOTE: This oven is shipped assembled for Outside Top 3 types of ventilation: Exhaust. Select the type of ventilation required for your installation and proceed to that section.

  • Page 12: A Outside Top Exhaust

    Installation Instructions OUTSIDE TOP EXHAUST (Vertical Duct) INSTALLATION OVERVIEW A1. Attach Mounting Plate to Wall A2. Prepare Top Cabinet A3. Install Adaptor A4. Mount Oven A5. Adjust Exhaust Adaptor A6. Connect Ductwork To use toggle bolts: ATTACH THE MOUNTING PLATE TO THE WALL Spacing for Toggles More Than...

  • Page 13: Preparation Of Top Cabinet

    Installation Instructions USE TOP CABINET TEMPLATE FOR MOUNT THE OVEN PREPARATION OF TOP CABINET You need to drill holes for the top support screws, a hole large enough for the power cord to fit through, and a cutout large enough for the exhaust adaptor. CAUTION: IMPORTANT: Do not grip or use handle during installation.

  • Page 14: Adjust The Exhaust Adaptor

    Installation Instructions ADJUST THE EXHAUST ADAPTOR MOUNT THE OVEN (continued) Open the top cabinet and adjust the exhaust adaptor 3 Attach the oven to the top cabinet. to connect to the house duct. Insert 3 self-aligning screws Damper -28 x ) through outer top cabinet holes.

  • Page 15: Boutside Back Exhaust

    Installation Instructions OUTSIDE BACK EXHAUST (Horizontal Duct) INSTALLATION OVERVIEW B1. Prepare Rear Wall B2. Attach Mounting Plate to Wall B3. Prepare Top Cabinet B4. Adjust Blower B5. Mount the Oven ATTACH THE MOUNTING PLATE PREPARING THE REAR WALL TO THE WALL FOR OUTSIDE BACK EXHAUST You need to cut an opening in the rear wall for outside exhaust.

  • Page 16: Preparation Of Top Cabinet

    Installation Instructions To use toggle bolts: ADAPTING BLOWER FOR OUTSIDE BACK EXHAUST Spacing for Toggles More Than Wall Thickness 1 Remove the three screws that hold the blower Toggle Wings plate to the oven. Slide blower plate from under Mounting Toggle its retaining flange.
  • Page 17 Installation Instructions Roll the blower unit 90° so that fan blade openings Replace the blower plate in the same position are facing out the back of the oven. as before with the screws. Blower Plate Screws Before Rolling After Rolling Blower Plate Back of Oven 9 Insert the tabs on each side of the damper...

  • Page 18: Mount The Oven

    Installation Instructions Cabinet Front MOUNT THE OVEN Cabinet Bottom Shelf Filler Block This Equivalent distance to Depth can NOT of Cabinet exceed 2” to ensure Recess proper installation CAUTION: Self-Aligning Screw Oven Top Attach the oven to the top cabinet. Insert 3 self-aligning screws IMPORTANT: Do not grip or use handle during -28 x...

  • Page 19: Recirculating

    Installation Instructions RECIRCULATING (Non-Vented Ductless) INSTALLATION OVERVIEW C1. Attach Mounting Plate to Wall C2. Prepare Top Cabinet C3. Adjust Blower C4. Mount the Oven C5. Install Charcoal Filter (not supplied) Place the mounting plate against the wall and insert ATTACH THE MOUNTING PLATE the toggle wings into the holes in the wall to mount TO THE WALL the plate.

  • Page 20: Adapting Blower For Recirculation

    Installation Instructions ADAPTING BLOWER Carefully pull out the blower unit. The wires will extend far enough to allow you to adjust FOR RECIRCULATION the blower unit. NOTE: The exhaust adaptor with damper is not needed for recirculating models. You may want to save them for possible future use.

  • Page 21: Mount The Oven

    Installation Instructions MOUNT THE OVEN ADAPTING BLOWER FOR RECIRCULATION (continued) Place the blower unit back into the opening. WARNING: can cause injury or death. Do not pull or stretch not pinched. CAUTION: Secure blower unit to oven with the 2 screws IMPORTANT: Do not grip or use handle during removed in Step 2.

  • Page 22: Installing The Charcoal Filter

    Installation Instructions INSTALLING THE CHARCOAL MOUNT THE OVEN (continued) FILTER Insert a self-aligning screw through top-center cabinet hole. Temporarily secure the oven by Remove 2 screws on top of oven, just above turning the screw at least two full turns after the grille panel, using a Phillips screwdriver.
  • Page 23 Installation Instructions BEFORE YOU USE YOUR OVEN (continued) Make sure the oven has been installed according to instructions. 240 V Models: The wall outlet receptacle recommended for this appliance is NEMA #14–30R and accepts the four-prong grounded plug of this appliance. NEMA 14–30R Wall Receptacle Ensure proper...
