Electrovision A195CF User Manual

Fixed tv mounting bracket, vesa size 400 x 400mm

Table of Contents

Download this manual

A195CF

FIXED TV MOUNTING BRACKET

Vesa Size : 400 x 400mm

User Manual

Notice d'Utilisation

Thank you for purchasing an Electrovision bracket, please read these instructions carefully

and leave with the user of the product for future reference.

Table of Contents

Need help?

Do you have a question about the A195CF and is the answer not in the manual?

Page 1 A195CF FIXED TV MOUNTING BRACKET Vesa Size : 400 x 400mm User Manual Notice d’Utilisation Thank you for purchasing an Electrovision bracket, please read these instructions carefully and leave with the user of the product for future reference.
Page 2 IMPORTANT Installer and Users please note: These instructions should be read carefully and left with the user of the product for future reference. BEFORE USE Inspect the product for any signs of damage. If the product is damaged, DO NOT use it, and contact your supplier immediately PRODUCT SAFETY •...
Page 3 TV MOUNTING BRACKETS The A195CF Brackets have a wall bracket (H) and a TV bracket (G) that slots into the wall bracket (H). The part G has two holes, one for screws M4 to M6 and one for the M8. You will need to...
Page 4 BRICK/CONCRETE WALL FITTING INSTRUCTIONS • Select a suitable position to mount the frame. • Use a stud detector to check for hidden cables, pipes or steelwork. • Measure the distance between the centre of the mounting points on the rear of the television (L in Fig 1) •...
Page 5 If your product arrives damaged, you must contact the retailer from whom you bought it. The retailer’s contact details will be on the invoice that arrived with the product, or on the e-mail you received when you placed the order. Do not contact Electrovision, only your retailer can arrange a replacement.
