NON-CONTACT TEMPERATURE MEASUREMENTS

1. Point the meter at the surface to be measured.
2. Press the red
3. Use the laser pointer to identify the exact spot to be measured.
4. The area of the surface to be measured must be larger than the spot size as
determined by the distance to spot size specification.
5. Read the temperature in the display.
WARNING: Do not directly view or direct the laser pointer at an eye. Low power
visible lasers do not normally present a hazard, but may present some potential for
hazard if viewed directly for extended periods of time.

MIN/MAX and Last Reading Memory Recall

The meter will record Maximum, Minimum, and Last Reading for the period of time the
Measure button is held. These stored values can then be recalled directly on the meter's
display. The readings will remain in the display for approximately four seconds after a
button press.
1. Press the Memory key once: The "Last" icon appears with the stored last reading.
2. Press the Memory key again. The "MAX" icon appears with stored maximum reading
3. Press the Memory key again. The "MIN" icon appears with stored minimum reading
IR thermometer button.
3"
5
Diameter of spot
1"
0.5"
6"
24"
Distance to object
4"
RPM10 V1.4 8/07
