User Manual.Rx Only
Dental Computed Radiography Reader
Intended Use: The FireCR Dental Imaging System is indicated for capture, digitization and
processing of intra oral x-ray images stored on imaging plate recording media.
3DISC, FireCR, Quantor and the 3D Cube are trademarks of 3D Imaging & Simulations Corp,
South Korea, and its affiliates. All other trademarks are held by their respective owners and
are used in an editorial fashion with no intention of infringement. The data in this publication
are for illustration purposes only and do not necessarily represent standards or specifications,
which must be met by 3D Imaging & Simulations Corp. All information contained herein is
intended for guidance purposes only, and characteristics of the products and services described
in this publication can be changed at any time without notice. Products and services may not
be available in your local area. Please contact your local sales representative for availability
information. 3D Imaging & Simulations Corp. strives to provide as accurate information as
possible, but shall not be responsible for any typographical error.
© Copyright 2014 3D Imaging & Simulations Corp. All rights reserved.
Doc No. : TM-801-EN
Rev 1.2.3 Jul 2018
Part No. : CR-FPM-11-001-EN
Advertisement
Table of Contents
Related Manuals for 3Disc FireCR dental
Summary of Contents for 3Disc FireCR dental
- Page 1 Rev 1.2.3 Jul 2018 Part No. : CR-FPM-11-001-EN 3DISC, FireCR, Quantor and the 3D Cube are trademarks of 3D Imaging & Simulations Corp, South Korea, and its affiliates. All other trademarks are held by their respective owners and are used in an editorial fashion with no intention of infringement. The data in this publication are for illustration purposes only and do not necessarily represent standards or specifications, which must be met by 3D Imaging &...
- Page 2 User Manual FireCR Dental TM-801-EN Contact 3D Imaging & Simulations Corp. Bldg.1, 48, Yuseong-daero 1184 beon-gil, Yuseong-gu, Daejeon, 34109 Korea Tel : 82-42-931-2100 Fax : 82-42-931-2299 Website : www.3DISC.com E-mail : info@3DISC.com 3DISC Americas 22560 Glenn Dr, Suite 116 Sterling, VA 20164 USA Tel : 1-703-430-6080 E-mail : info@3DISC.com...
- Page 3 User Manual FireCR Dental TM-801-EN The device complies with DHHS Radiation Safety Standards in effect as of the date of manufacture. The device complies with Part 15 of the FCC Rules. Operation is subject to the condition that this device does not cause harmful interference.
- Page 4 User Manual FireCR Dental TM-801-EN Warnings and Used Symbols To ensure the safety of patients, staff and other persons, any changes to software and hardware delivered by 3D Imaging & Simulations Corp. may only be made with prior written permission from 3D Imaging &...
- Page 5 User Manual FireCR Dental TM-801-EN General Safety Guidelines All the safety and operating instructions should be read carefully before this device is operated. This device has been designed and tested to meet strict safety requirements applicable to medical equipment, and has been supplied in a safe condition. To ensure personnel and patient safety, the device shall be operated and serviced in compliance with all procedures, warnings and precautions during all phases of operation and service of this device.
- Page 6 User Manual FireCR Dental TM-801-EN Do not look inside of the device. If any of the following conditions occur, unplug the device from the electrical outlet and contact authorized service personnel. The power cord or power adapter is damaged.
-
Page 7: Table Of Contents
User Manual FireCR Dental TM-801-EN Index of contents Chapter 1. Introduction ..............9 Chapter 2. Unpacking ..............10 2.1. Inspection for Damage ..............10 2.2. Identify the Components ..............10 Chapter 3. Setting Up ..............13 3.1. Positioning ..................13 3.2. - Page 8 User Manual FireCR Dental TM-801-EN 4.4.4. Imaging Plate Placement and Removal ........31 4.4.5. Getting a scanned image ............32 4.4.6. Circuit Functions ............... 33 Chapter 5. Symbols ............... 35 Manufacturer’s Declaration – Electromagnetic Emission .... 36 5.1. Manufacturer’s Declaration - Electromagnetic Immunity ....37 5.2.
-
Page 9: Chapter 1. Introduction
Chapter 1. Introduction Dear Customer Thank you for choosing the 3DISC Imaging FireCR Dental Reader as your new dental solution. The advanced CR technology of the FireCR Dental Reader enables you to produce high- quality digital images for diagnosing the patients in your facility. The reader can be used as a central reader, which distributes images throughout your facility, or as an exam-room based solution. -
Page 10: Chapter 2. Unpacking
Chapter 2. Unpacking 2.1. Inspection for Damage FireCR Dental Reader is shipped in a custom designed container to protect the reader from external shock. Before unpacking the reader, inspect the shipping container for damage. In case the container is damaged, notify the shipper immediately. - Page 11 Box of 100 pcs CR-FP-51-010 FireID Kit (RFID Reader, mini USB cable) ARNING If the FireCR Dental needs to be returned to manufacturer or one of its representatives, the reader must be repacked in the original container with all accessories.
- Page 12 3D imaging & Simulations Corp. AC/DC Adapter Manufacturer : Bridge Power corp. Model : BPM050X24XXX This adapter meets the requirements of IEC60601-1. ARNING Use only devices meeting the requirements of IEC60950-1 or IEC60601-1 when connecting to the FireCR Dental via the USB port.
-
Page 13: Chapter 3. Setting Up
User Manual FireCR Dental TM-801-EN Chapter 3. Setting Up ARNING Unsuitable Installation Sites Locations with excessive humidity or dust Locations subject to high temperature Locations subject to shaking or vibration Locations exposed to considerable electrical or magnetic noise, or other forms of electromagnetic energy Locations with poor heat radiation 3.1. -
Page 14: Identify Important Features
User Manual FireCR Dental TM-801-EN ARNING Sliding of the reader may result in internal damage or misalignment of the optics. External vibration or shock during scanning may affect image quality. The reader must be placed on a rigid, flat and reinforced desk or tabletop. -
Page 15: Touch Display Panel
User Manual FireCR Dental TM-801-EN 3.2.2. Touch Display Panel Screen displays the status of the reader and control of the reader can be done through touch display panel. Touch display panel Figure 3. Touch Display Panel Display Status Remark When the reader is turned on,... - Page 16 User Manual FireCR Dental TM-801-EN Auto Sleep mode – IP tray moves Sleeping back into the reader and door will be closed. : Size of imaging plate. Description of : High resolution, standard icons resolution. Temporarily toggles when it is touched.
- Page 17 User Manual FireCR Dental TM-801-EN Ready for IP size is recognized and the Scan reader is ready. Scanning Scanning is in progress. Erasing Erasing is in progress. Unexpected system error. System error Contact technical support.
- Page 18 User Manual FireCR Dental TM-801-EN When button is selected from Setting mode main screen, Setting mode is displayed. Scanning Choose HD or SD resolution HD: High Definition setting SD: Standard Definition System setting for Auto Sleep and System setting Auto Trim...
- Page 19 User Manual FireCR Dental TM-801-EN Choose Off or On Auto Trim Off : Scan corresponding Auto Trim area of IP detected by the reader setting Auto trim on : Scan whole tray area and crop the image automatically Language Choose language...
- Page 20 User Manual FireCR Dental TM-801-EN Type in IP address manually. IP Address setting When this setting is changed, the system will restart automatically. Type in Subnet mask manually. Subnet mask setting When this setting is changed, the system will restart automatically.
-
Page 21: Computer Requirements
User Manual FireCR Dental TM-801-EN 3.3. Computer Requirements 3.3.1. Recommended Configuration Operation System Microsoft Windows 7, 8, 10 (32 bit or 64 bit) Core Duo / Core2 Processor Memory RAM 4GB or more Hard Disk 300GB Free Hard Disk Space... -
Page 22: Connect The Cable And Power Cord
TM-801-EN 3.5. Connect the Cable and Power Cord FireCR Dental supports direct connection mode for single reader with single computer and network sharing mode for multiple readers with multiple computers. This manual describes direct connection mode only. Network sharing mode requires additional FireID Kit (RFID reader) and detailed instruction for network sharing mode is provided with FireID Kit. -
Page 23: Connecting The Ethernet Cable
User Manual FireCR Dental TM-801-EN 3.5.2. Connecting the Ethernet Cable The reader interfaces with the computer via Ethernet cable (RJ45 CAT.5E FTP). 1. Connect the cable to the reader’s Ethernet port, located on the connection panel. 2. Connect the other end of the cable to the Ethernet port of the Ethernet-hub. -
Page 24: Connecting The Power Cord
User Manual FireCR Dental TM-801-EN 3.5.3. Connecting the Power Cord 1. Connect the power cord to the reader, located on the connection panel. 2. Connect the other end of the cord to a grounded power outlet. Figure 6. Power Connection... -
Page 25: Installation Report
User Manual FireCR Dental TM-801-EN ARNING Socket-outlet should be installed near the device and should be easily accessible. Do not place the device where access to appliance inlet is obstructed. Do not unplug the power cord or turn the power switch off during scanning. -
Page 26: Chapter 4. Operating
User Manual FireCR Dental TM-801-EN Chapter 4. Operating 4.1. System Specifications 64um Sampling Pixel Pitch 35um 343 x 484 Pixel Matrix (Size 0) 628 x 885 375 x 625 Pixel Matrix (Size 1) 685 x 1143 484 x 640 Pixel Matrix (Size 2) -
Page 27: Operation Conditions
User Manual FireCR Dental TM-801-EN 4.2. Operation Conditions Indoor use only Operating Temperature 15C ~ 30C (59F ~ 86F) Temperature Gradient 0.5C / Min Relative Humidity 15% ~ 95% (non-condensing) Storage Temperature - 10C ~ 50C (14F ~ 122F) Storage Humidity... -
Page 28: Use, Care, Maintenance And Infection Control
User Manual FireCR Dental TM-801-EN 4.3. Use, Care, Maintenance and Infection Control Use proper dental aseptic techniques. As with other radiographic procedures, the use of imaging plate requires the same high standards of infection control. Unfortunately, imaging plates create a greater challenge since they are not disposable. Another problem is that there is a higher potential for damaging them since they are reusable. -
Page 29: Use Hygienic Bag
User Manual FireCR Dental TM-801-EN 4.3.2. Use Hygienic Bag Insert prepared imaging plate with protective cover into hygienic bag. Please beware of correct side of imaging plate as shown in Figure 8. Figure 8. Hygienic Bag Figure 8. Insertion of imaging plate into hygienic bag: (a) Blank side should face to X-ray source. -
Page 30: Cleaning Of The Tray
User Manual FireCR Dental TM-801-EN 4.3.3. Cleaning of the Tray Clean the tray using soft lint-free cellulose cloth with Ethanol (99.7%) Tray Figure 9. Imaging Plate Tray 4.4. Operating Instructions 4.4.1. Turn on the Reader Turn on the reader. Power switch is located on the connection panel. -
Page 31: X-Ray Exposure On Imaging Plate
User Manual FireCR Dental TM-801-EN 4.4.3. X-ray exposure on imaging plate Blank side of hygienic bag (active side of imaging plate) must face the tooth and X-ray source. Figure 10. Direction of imaging plate for X-ray exposure. 4.4.4. Imaging Plate Placement and Removal Take imaging plate out of the hygienic bag after tearing off the seal. -
Page 32: Getting A Scanned Image
User Manual FireCR Dental TM-801-EN Push tray in to start scan. The imaging plate can be removed when scanning and erasing are completed and the tray is outside again. Gently pull up the imaging plate not to scratch the active side. -
Page 33: Circuit Functions
User Manual FireCR Dental TM-801-EN 4.4.6. Circuit Functions Figure 13. Circuit Diagram Base Board: Base board is a controller of peripherals. It controls peripherals upon command of core board. Peripheral: These are peripherals for image acquisition. They consist of “Eraser” which erases residual images in imaging plate, “Step Motor”... - Page 34 User Manual FireCR Dental TM-801-EN Image Sensor (PMT): This Photomultiplier Tube receives the signal through scanning of the imaging plate, and then sends the signal to the analog readout circuit. Power Adapter: Supplies power to all modules of the system which are required for operation.
-
Page 35: Chapter 5. Symbols
User Manual FireCR Dental TM-801-EN Chapter 5. Symbols Symbol Description Manufacturer Date of Manufacture Equipment Power ON Warning, Consult Accompanying Documents General mandatory action manual prohibition General indication User Manual Reference Directive on Waste Electrical and Electronic Equipment Authorized Representative in the European... -
Page 36: Manufacturer's Declaration- Electromagnetic Emission
5.1. Manufacturer’s Declaration- Electromagnetic Emission The FireCR Dental system is intended for use in the electromagnetic environment specified below. The customer or the user of FireCR Dental system should assure that it is used in such an environment Emission test... -
Page 37: Manufacturer's Declaration - Electromagnetic Immunity
5.2. Manufacturer’s Declaration - Electromagnetic Immunity The FireCR Dental system is intended for use in the electromagnetic environment specified below. The customer or the user of FireCR Dental system should assure that it is used in such an environment IEC 60601... - Page 38 User Manual FireCR Dental TM-801-EN Conducted RF 3 Vrms 3 Vrms Portable and mobile RF IEC 61000-4-6 150 kHz to 80 MHz 150 kHz to 80 MHz communications equipment should be used no closer to Dental any part of the FireCR...
- Page 39 The FireCR Dental system is intended for use in an electromagnetic environment in which radiated RF disturbances are controlled. The user of the FireCR Dental system can help prevent electromagnetic interference by maintaining a minimum distance between portable and mobile RF communications equipment (transmitters) and the FireCR Dental system as recommended below, according to the maximum output power of the communications equipment.
-
Page 40: Guidance And Manufacturer 'S Declaration - Electromagnetic Immunity
5.3. Guidance and Manufacturer ’s Declaration – Electromagnetic Immunity The FireCR Dental system is intended for use in the electromagnetic environment specified below. The customer or the user of FireCR Dental system should assure that it is used in such an environment IEC 60601... -
Page 41: Laser Safety Statement
User Manual FireCR Dental TM-801-EN 5.4. Laser Safety Statement The Computed Radiography Reader is Certified in the U.S. to Conform to the Requirements of DHHS 21 CFR, chapter 1 Subchapter J for Class I(1) Laser Products, and Elsewhere is Certified as a Class I(1) Laser Product Conforming to the Requirements of IEC 60825-1 : 2007. -
Page 42: Chapter 6. Technical Assistance
User Manual FireCR Dental TM-801-EN Chapter 6. Technical Assistance If user has any questions about installing or using the device, contact your 3D Imaging & Simulations Corp. representative or your local dealer. 3D Imaging & Simulations Corp. Bldg.1, 48, Yuseong-daero 1184 beon-gil, Yuseong-gu, Daejeon, 34109 Korea... - Page 43 Fax : +82-42-931-2299 E-mail : support@3DISC.com Date of Installation : Customer Information Hospital / Institute Name Address E-mail Installer Information Company Name Address E-mail System Information Model FireCR Dental Reader System S/N Installer’s Signature: Date: Customer’s Signature: Date:...
