I HCW e HCA sono certificati:
EN60730 sicurezza
EN61000-6-4 emissioni elettromagnetiche industriali
EN61000-6-3 emissioni elettromagnetiche residenziali.
I Sezione cavo in funzione della lunghezza.
Istruzioni-HCMMMTTT-24082018 (Cod.620100006 Rev.11) ItaEng MAC3.doc
Model TT 3hp
Model MT 2hp
Model MM 1.5hp
2
S mm L max mt
1.5 20
2.5 50
4 100
Model TT 10hp
2
S mm
4
6
10
EN HCW and HCA are certified:
EN60730 safety
EN61000-6-4 EMC industrial environment.
EN61000-6-3 EMC residential environment.
EN Section cable linked to cable length.
Model TT 5.5hp
2
S mm L max mt
1.5 20
2.5 50
4 100
Model TT 15hp
2
L max mt S mm
20 6
50 10
100 16
Model TT 7.5hp
Model MT 3hp
Model MM 2hp
2
S mm L max mt
2.5 20
4 50
8 100
L max mt
20
50
100
