Comelit 1622 Technical Instructions

Audio module for sb1 system
Hide thumbs Also See for 1622:
Table of Contents

Advertisement

Quick Links

See also: Technical Manual
EN
TECHNICAL
MANUAL
Audio module for SB1 system
Art. 1622

Advertisement

Table of Contents
loading

Related Manuals for Comelit 1622

Summary of Contents for Comelit 1622

  • Page 1 TECHNICAL MANUAL Audio module for SB1 system Art. 1622...

  • Page 2: Table Of Contents

    Warning Intended use This Comelit product was designed for use in the creation of audio and video communication systems in residential, commercial or industrial settings and in public buildings or buildings used by the public. Installation All activities connected to the installation of Comelit products must be carried out by qualified technical personnel, with careful observation of the indications provided in the Manuals / Instruction sheets supplied with those products.

  • Page 3: Description

    Description Art. 1622 is an audio module which is compatible with Comelit “SB1” entry phone systems, exclusively for use in conjunction with power supply unit Art. 1595. It can be installed in Ikall, Ikall Metal, Vandalcom and Roma series external units and can be finished with additional modules to meet all system requirements.

  • Page 4: Technical Characteristics

    1. Loudspeaker. 2. Microphone. 3. Loudspeaker volume control. Technical characteristics Art. 1622 MAIN FEATURES Audio system Audio/video system Clamps L L V+V- RTE DO PR GND SE COM NC NO Microphone volume control Loudspeaker volume control Operating temperature (°C) -25 ÷ 55...

  • Page 5: External Unit Installation

    External unit installation Connect the module support frame to earth. BLUE WHITE Nameplate LED lighting selection. Close Open Alternative microphone position (excluding 4 module entrance panel)

  • Page 6: Connections

    1622 Set dip switches in permanent mode as shown in figure (Dip switch 8 ON, Dip switches 1,2,3,4,5,6,7 OFF) Applies to Art. 1622 with R.I. 038 or greater Jumper On C. NO. contacts. On C. NC contacts Excluded: voltage-free contact...

  • Page 7: Module Connection

    Module connection Ikall / Ikall Metal modules Connection of button modules 33433, 33434, 33436, 33433M, 33434M, 33436M 1622 Connection Art. 3348B, 3348BM AUDIO ENTRY SYSTEM RISER 1595 120-230 V 1622 3348B 3348BM Connection Art. 3360B, 3360BM 1622 3360B 3360BM...

  • Page 8: Vandalcom Modules

    Vandalcom modules Connection Art. 3064S AUDIO ENTRY SYSTEM RISER 1595 120-230 V 1622+3262S 3064S 3064S 3064S 3064S 1172B 1172B 1172B 1172B Use the cable supplied with Art. 3262S. Use bulb Art. 1172B for nameplate lighting. The bulb is polarised. Connection Art. 3188SB...

  • Page 9: Connection Art. 3070S, 3072S

    Connection Art. 3070S, 3072S AUDIO ENTRY SYSTEM RISER 1595 120-230 V 1622 3070S 3072S "V-" BLUE "S" YELLOW "V+" BROWN 2E7T000696 Use the cable 2E7T000696 supplied with Art. 3070S and Art. 3072S. 20m max. Local lock-release button. Modules for Single-plate external unit Connection Art. 3063D...

  • Page 10: Button Programming

    Button programming 33433 33434 33436 33433 33434 33436 Set the user code using the dip switches; see addressing table.

  • Page 11: Special Programmes

    Special programmes 1 sec Set the dip switches for the function you wish to program, see the table below.
  • Page 12 Reset after lock-release in audio: disabled 1,4,5,6,7,8 Call transmission: single (default) 2,4,5,6,7,8 Call transmission: triple Control of internal units connected to Art. 1622: up to 70 (default) 1,5,6,7,8 Control of internal units connected to Art. 1622: from 71 to 100 2,5,6,7,8...

  • Page 13: Installation Information

    • Module Art. 1622 normally function as a main external unit (timed busy signal). To set it as a secondary external unit (busy signal active for the whole time the riser is in use), set all the selector DIP switches to ON.
  • Page 14 C E R T I F I E D M A N A G E M E N T S Y S T E M S w w w . c o m e l i t g r o u p . c o m Via Don Arrigoni, 5 - 24020 Rovetta (BG) - Italy...
