Model No. 25049.5
Serial No.
Write the serial number in the space
above for reference.
Serial Number
Decal
ACTIVATE YOUR
WARRANTY
To register your product and
activate your warranty today, go
to my.nordictrack.com
CUSTOMER CARE
For service at any time, go to
nordictrackservice.com.
Or call 1-800-TO-BE-FIT
(1-800-862-3348)
Mon.–Fri. 6 a.m.–6 p.m. MT
Sat. 8 a.m.–12 p.m. MT
Please do not contact the store.
CAUTION
Read all precautions and
instructions in this manual before
using this equipment. Save this
manual for future reference.
USER'S MANUAL
Advertisement
Table of Contents
Related Manuals for NordicTrack C970PRO
Summary of Contents for NordicTrack C970PRO
- Page 1 Serial Number Decal ACTIVATE YOUR WARRANTY To register your product and activate your warranty today, go to my.nordictrack.com CUSTOMER CARE For service at any time, go to nordictrackservice.com. Or call 1-800-TO-BE-FIT (1-800-862-3348) Mon.–Fri. 6 a.m.–6 p.m. MT Sat.
-
Page 2: Table Of Contents
NORDICTRACK and IFIT are registered trademarks of ICON Health & Fitness, Inc. App Store is a trademark of Apple Inc., registered in the U.S. and other countries. Android and Google Play are trademarks of Google Inc. The BLUETOOTH ®... -
Page 3: Important Precautions
5. The treadmill is intended for home use only. purchase a surge suppressor, see your local Do not use the treadmill in any commercial, NORDICTRACK dealer, call the telephone rental, or institutional setting. number on the front cover of this manual, or see your local electronics store. - Page 4 19. Always stand on the foot rails when starting able to safely lift 45 lbs. (20 kg) to move the or stopping the walking belt. Always hold the treadmill. handrails while using the treadmill. 26. When folding or moving the treadmill, make 20.
- Page 5 STANDARD SERVICE PLANS...
-
Page 6: Before You Begin
BEFORE YOU BEGIN Thank you for selecting the revolutionary reading this manual, please see the front cover of this NORDICTRACK C 970 PRO treadmill. The C 970 manual. To help us assist you, please note the product ® PRO treadmill offers an impressive selection of fea- model number and serial number before contacting us. -
Page 7: Part Identification Chart
PART IDENTIFICATION CHART Use the drawings below to identify small parts used for assembly. The number in parentheses below each draw- ing is the key number of the part, from the PART LIST near the end of this manual. The number following the key number is the quantity used for assembly. -
Page 8: Assembly
To avoid damaging parts, do not use power tools. • Left parts are marked “L” or “Left” and right parts are marked “R” or “Right.” 1. Go to my.nordictrack.com on your computer and register your product. • documents your ownership •... - Page 9 2. Make sure that the power cord is unplugged. Remove the tie securing the Upright Wire (81) to the front of the Base (94). Next, identify the Right Upright (90). Have a second person hold the Right Upright near the Base (94).
- Page 10 4. Hold the Right Upright (90) against the Base (94). Make sure not to pinch the Upright Wire (81). Attach the Right Upright (90) and a Wheel (97) with two 3/8" x 2 1/4" Screws (7), a 3/8" x 1 1/4" Screw (63), a 3/8"...
-
Page 11: Then, Remove And Discard The Indicated
6. Attach a Handrail (86) to the Right Upright (90) with two 5/16" x 2 1/2" Screws (28) and two 5/16" Star Washers (11); do not fully tighten the Screws yet. Make sure not to pinch the Upright Wire (81), and make sure that the wire is on the indicated side of the Upright. - Page 12 8. Set the console assembly (F) face down on a soft surface to avoid scratching the console assembly. Remove and save the four 1/4" x 1/2" Screws (4). 9. Hold the console assembly (F) near the Pulse Crossbar (93). See the inset drawing. Connect the pulse wires (G, H).
- Page 13 10. Insert the Upright Wire (81) through one looped tie (I) on the console assembly (F), and insert the console wire (J) through the other looped tie. Connect the Upright Wire (81) to the con- sole wire (J). The connectors should slide together easily and snap into place.
- Page 14 12. Identify the Right and Left Trays (34, 36). Attach the Trays (34, 36) to the Console Base (64) with eight #8 x 1/2" Screws (1); do not overtighten the Screws. 13. Carefully slide the Upright Crossbar (58) between the Left and Right Uprights (89, 90). Attach the Upright Crossbar with the four 5/16"...
- Page 15 14. Attach the Tray (74) to the Upright Crossbar (58) with four #8 x 3/4" Truss Head Screws (23); start all four Truss Head Screws, and then tighten them. Then, tighten the four 1/4" x 1/2" Screws (4). 15. Identify the Right Handrail Cover (92). Set the Right Handrail Cover on the right Handrail (86).
- Page 16 16. Note: If the treadmill is assembled on a smooth surface, it may roll forward during this step. Raise the Frame (56) to the upright position. IMPORTANT: Do not raise the Frame past the vertical position. Have a second person hold the Frame until step 18 is completed.
- Page 17 18. Remove the 5/16" Nut (12) and the 5/16" x 2 1/4" Bolt (3) from the bracket on the Latch Crossbar (38). Align the upper end of the Storage Latch (53) with the bracket on the Latch Crossbar (38), and insert the 5/16" x 2 1/4" Bolt (3) through the bracket and the Storage Latch.
- Page 18 20. Press the two tabs (not shown) on the Tablet Holder (105) into the slots (O) in the console assembly (F). Then, attach the Tablet Holder (105) with four Start First #8 x 5/8" Machine Screws (26). Tip: Start the two upper Machine Screws fi...
-
Page 19: How To Use The Treadmill
HOW TO USE THE TREADMILL HOW TO CONNECT THE POWER CORD more amps. To avoid overloading the circuit, do not plug other electrical devices, except for low- Use a Surge Suppressor power devices such as cell phone chargers, into the surge suppressor or into an outlet on the same Your treadmill, like other electronic equipment, can be circuit. - Page 20 CONSOLE DIAGRAM FEATURES OF THE CONSOLE To turn on the power, see page 21. To use the man- ual mode, see page 21. To use an onboard workout, IMPORTANT: To activate your console and begin see page 23. To use a custom-focus weight loss using its exclusive features, see assembly step 21 workout, see page 24.
- Page 21 HOW TO TURN ON THE POWER HOW TO USE THE MANUAL MODE IMPORTANT: If the treadmill has been exposed to 1. Insert the key into the console. cold temperatures, allow it to warm to room tem- perature before you turn on the power. If you do See HOW TO TURN ON THE POWER at the left.
- Page 22 5. Change the incline of the treadmill as desired. The Calorie tab will show the approximate amount of calories you have burned. The height of each To change the incline of the treadmill, press the segment represents the amount of calories burned Incline increase and decrease buttons or one of the during that segment.
- Page 23 To measure your heart rate, stand on the foot HOW TO USE AN ONBOARD WORKOUT rails and hold the pulse bar with your palms on the metal contacts; avoid moving your hands. 1. Insert the key into the console. When your pulse is detected, your heart rate will be shown.
- Page 24 5. Follow your progress with the displays. 4. Start the workout. See step 6 on page 22. If you select an onboard Press the Start button to start the workout. A workout, the display will show the time remaining moment after you press the button, the walking belt instead of the elapsed time.
- Page 25 HOW TO CONNECT YOUR TABLET TO THE 5. Disconnect your tablet from the console if CONSOLE desired. The console supports BLUETOOTH connections To disconnect your tablet from the console, first to tablets via the iFit–Smart Cardio Equipment app select the disconnect option in the iFit–Smart and to compatible heart rate monitors.
- Page 26 THE OPTIONAL CHEST HEART RATE MONITOR THE SETTINGS MODE Whether your The console features a settings mode that keeps track goal is to of treadmill information and allows you to personalize burn fat or to console settings. strengthen your cardiovascular 1.
- Page 27 HOW TO USE THE TABLET HOLDER HOW TO ADJUST THE CUSHIONING SYSTEM IMPORTANT: The tablet holder is designed for use The treadmill features a cushioning system that with most full-size tablets. Do not place any other reduces the impact as you walk or run on the treadmill. electronic device or object in the tablet holder.
-
Page 28: Fcc Information
FCC INFORMATION This console has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. -
Page 29: How To Fold And Move The Treadmill
HOW TO FOLD AND MOVE THE TREADMILL HOW TO FOLD THE TREADMILL HOW TO MOVE THE TREADMILL To avoid damaging the treadmill, adjust the incline Before moving the treadmill, fold it as described at the to zero before you fold the treadmill. Then, remove left. -
Page 30: Maintenance And Troubleshooting
MAINTENANCE AND TROUBLESHOOTING MAINTENANCE c. Check the power switch located on the treadmill frame near the power cord. If the switch protrudes Regular maintenance is important for optimal perfor- as shown, the switch has tripped. To reset the mance and to reduce wear. Inspect and properly tighten power switch, wait for fi... - Page 31 SYMPTOM: The incline of the treadmill does not c. Your treadmill features a walking belt coated with change correctly high-performance lubricant. IMPORTANT: Never apply silicone spray or other substances to a. Hold down the Stop button and the Speed increase the walking belt or the walking platform unless button, insert the key into the console, and then instructed to do so by an authorized service...
- Page 32 b. If the walking belt slips when walked on, fi rst SYMPTOM: The tablet holder does not stay in place remove the key and UNPLUG THE POWER CORD. Using the hex key, turn both idler roller a. Rotate the tablet holder backwards. Then, tighten screws clockwise, 1/4 of a turn.
-
Page 33: Exercise Guidelines
EXERCISE GUIDELINES Burning Fat—To burn fat effectively, you must exer- WARNING: cise at a low intensity level for a sustained period of Before beginning this time. During the first few minutes of exercise, your or any exercise program, consult your physi- body uses carbohydrate calories for energy. -
Page 34: Part List
PART LIST Model No. 25049.5 R0218A Key No. Qty. Description Key No. Qty. Description #8 x 1/2" Screw #8 x 3/4" Pan Head Tek Screw #8 x 3/4" Screw #8 x 5/8" Screw 5/16" x 2 1/4" Bolt Storage Latch 1/4"... - Page 35 Key No. Qty. Description Key No. Qty. Description Speaker Hood Mount Left Speaker Cover Shipping Support Right Speaker Cover Electronics Bracket #6 x 1/2" Screw Tablet Holder #3 x 1/4" Screw 9/32" Plastic Bushing Left Rear Frame Cap 3/8" Plastic Bushing 1/4"...
-
Page 36: Exploded Drawing
EXPLODED DRAWING A Model No. 25049.5 R0218A... - Page 37 EXPLODED DRAWING B Model No. 25049.5 R0218A...
- Page 38 EXPLODED DRAWING C Model No. 25049.5 R0218A...
- Page 39 EXPLODED DRAWING D Model No. 25049.5 R0218A...
-
Page 40: Ordering Replacement Parts
ORDERING REPLACEMENT PARTS To order replacement parts, please see the front cover of this manual. To help us assist you, be prepared to provide the following information when contacting us: • the model number and serial number of the product (see the front cover of this manual) •...
