TIMETRAX™ SYNC 5300 BELL RINGER
Installation Instructions
INSTALLATION
The 5300 Bell Ringer requires one of the following Pyramid interface products for operation; 4000, 4000HD, 5000HD,
1
PSDLAUBKK, TTPROXEK, TTELITEEK, 9T1WI, S9DWXSLAUB. Prior to installation, make sure the time is set on the time
clock or transmitter from which bell/horn signal will be sent.
Plug the end of the power supply into the power port located on the far left side of the
2
bottom of the 5300 case.
Plug power supply into standard electrical wall outlet. The bottom light will
3
turn green upon power connection.
pyramidtimesystems.com
2
3
INSTALLATION
4
