TIMETRAX™ SYNC 5300 BELL RINGER
Installation Instructions
WALL MOUNTING
1
Select a location for mounting. Power outlet should be within 5 feet of mounting location.
2
Hold the case in desired location and mark holes for drilling. Drill holes for mounting.
3
For sheet rock walls, use plastic anchors.
3
WALL MOUNTING
pyramidtimesystems.com
5300
SINGLE BELL RINGER
POWER
RJ45
BELL
IN
SIGNAL
IN
OUT
POWER
24VDC
888.479.7264
