Navigation system, portable, installation kit TMC
Navigation system, portable, installation kit TMC
© Volvo Car Corporation
Installation instructions, accessories
Volvo Car Corporation Gothenburg, Sweden
Part. No.
Part. No.
31330255, 31334558
31330255, 31334558
Navigation system, portable, installation kit TMC- 31339077 - V1.0
5
5
5
5
Side 1 / 16
Advertisement
Related Manuals for Volvo 31330255
Summary of Contents for Volvo 31330255
- Page 1 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Instruction No Instruction No Version Version Part. No. Part. No. 31339077 31339077 31330255, 31334558 31330255, 31334558 Navigation system, portable, installation kit TMC Navigation system, portable, installation kit TMC © Volvo Car Corporation Navigation system, portable, installation kit TMC- 31339077 - V1.0...
-
Page 2: Special Tools
Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Special tools 951 2932 Tension spring Tool number:951 2932 Tool description:Tension spring Tool boards:80 Materials Designation Part number Melting adhesive 1161656 Equipment IMG-239667 IMG-239664 IMG-327738 © Volvo Car Corporation Navigation system, portable, installation kit TMC- 31339077 - V1.0... - Page 3 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden IMG-347971 © Volvo Car Corporation Navigation system, portable, installation kit TMC- 31339077 - V1.0 Side 3 / 16...
- Page 4 Certain steps in the instructions are only presented in the form of images. Explanatory text is also given for more complicated steps. In the event of any problems with the instructions or the accessory, contact your local Volvo dealer. Conditions Set the ignition key to position 0. IMG-332193 Removal ©...
- Page 5 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Remove the panel. IMG-338119 Release the lock. IMG-344717 © Volvo Car Corporation Navigation system, portable, installation kit TMC- 31339077 - V1.0 Side 5 / 16...
-
Page 6: Remove The Panel
Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden IMG-344721 Remove the panel. IMG-344722 © Volvo Car Corporation Navigation system, portable, installation kit TMC- 31339077 - V1.0 Side 6 / 16... - Page 7 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Remove the screws. IMG-341879 Disconnect the connector. IMG-341941 © Volvo Car Corporation Navigation system, portable, installation kit TMC- 31339077 - V1.0 Side 7 / 16...
- Page 8 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Remove the cable tie(s). IMG-353027 IMG-353028 © Volvo Car Corporation Navigation system, portable, installation kit TMC- 31339077 - V1.0 Side 8 / 16...
- Page 9 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Disconnect the connectors. IMG-353029 IMG-341940 © Volvo Car Corporation Navigation system, portable, installation kit TMC- 31339077 - V1.0 Side 9 / 16...
-
Page 10: Remove The Screws
Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Remove the screws. IMG-341880 IMG-341942 © Volvo Car Corporation Navigation system, portable, installation kit TMC- 31339077 - V1.0 Side 10 / 16... - Page 11 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Pull the wiring through. IMG-353037 IMG-353038 © Volvo Car Corporation Navigation system, portable, installation kit TMC- 31339077 - V1.0 Side 11 / 16...
- Page 12 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden IMG-353035 Use: 1161656, Melting adhesive IMG-353036 © Volvo Car Corporation Navigation system, portable, installation kit TMC- 31339077 - V1.0 Side 12 / 16...
- Page 13 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden IMG-353291 Use special tool: T9512932, Tension spring Pull the wiring through. IMG-353034 © Volvo Car Corporation Navigation system, portable, installation kit TMC- 31339077 - V1.0 Side 13 / 16...
- Page 14 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden IMG-345918 Reinstall the screw. IMG-345647 © Volvo Car Corporation Navigation system, portable, installation kit TMC- 31339077 - V1.0 Side 14 / 16...
- Page 15 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden IMG-345771 Connect the connectors. IMG-349476 © Volvo Car Corporation Navigation system, portable, installation kit TMC- 31339077 - V1.0 Side 15 / 16...
- Page 16 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Tear off the excess foam tape. IMG-349477 Clamp the cables and connectors to the existing cables to prevent noise. Reinstall the removed parts in reverse order. IMG-353033 © Volvo Car Corporation Navigation system, portable, installation kit TMC- 31339077 - V1.0...
