I/Q SIGNAL
■ Control commands relative to I/Q port setting (Continued)

D I/Q Output setting

Command: 1A 13 01
PC to IC-R8600 (Write data format):
Sets the I/Q output setting to ON or OFF.
• Turning OFF the I/Q signal output
I/Q output setting
0 0
0 =OFF
0 (Fixed)
• Turning ON the I/Q signal output
Also sends the bit depth and sampling frequency data.
I/Q output setting
Sampling frequency
0 1 0 X 0 X
Bit depth
1=ON
0 (Fixed)
You can set the I/Q signal output setting by sending the command through the [I/Q OUT] port.
Only when the I/Q mode is set to "ON," you can set the I/Q output to ON.
When the sent command is valid and accepted by the IC-R8600, the acknowledgement "OK (FB)" will be
returned. "NG (FA)" will be returned if invalid.
I/Q Output Bit depth
00: OFF 00: 16-bit
01: ON 01: 24-bit
– –
NOTE: The combination of 5.12 MHz and 24 bit is invalid, and "NG (FA)" will be returned.
Sampling frequency
01 5.12 MHz 04 960 kHz
02 3.84 MHz 05 480 kHz
03 1.92 MHz 06 240 kHz
