Bakers Pride STUBBY 4151 Specifications

STUBBY SERIES
GAS DECK OVENS
BAKERS
PRIDE
Model 4151
with optional casters
SPECIFICATIONS
BAKERS PRIDE Stubby Series gas Deck Ovens are designed for
high volume pizza and all-purpose operations and are only 33" deep
(838mm) to fit in line with other kitchen equipment.
Ovens may be stacked three high. Oven exteriors are all heavy-
gauge, type 403 stainless steel and are fully insulated for cooler
outer temperatures and consistent interior temperatures.
Interior oven frame is constructed of 1/4" (6mm) heavy-duty angle
iron frame, completely welded to form a single, unitized section.
The oven body and lining are then welded to the framework.
Oven interiors are manufactured of high-heat resistant 16-gauge
aluminized steel. Doors are fully insulated, spring balanced with
tubular steel handles and will remain open or closed until moved.
All models feature independent, operator-controlled top & bottom
heat control damper.
Stubby Series features a 300°-650° F (149°-343°C)
thermostat, 8" (203mm) interior deck height with
thick Cordierite hearth decks (steel decks optional) and are
supported by a 1/4" (6mm) angle iron frame.
Combination gas control incorporates a manual gas valve, pilot
safety and pressure regulator. Easily removable, slide-out, heavy-
duty flame diverters distribute the burner flame uniformly in the
burner chamber. A 3/4" (19mm) NPT gas connection is located on
the left side and left rear of oven - operator/installer may choose.
Heavy-duty, 7-gauge hot rolled steel legs are standard and finished
with durable Bakertone.
1 Year limited parts and labor warranty standard.
BAKERS PRIDE OVEN COMPANY, INC.
30 Pine Street, New Rochelle, NY 10801
BAKERS
914/576-0200 • 1-800-431-2745 • fax 914/576-0605
PRIDE
www.bakerspride.com
q
q
q
q
q
q
q
q
q
q
q
q
q
q
q
throttling
q
1 1/2" (38mm)
q
q
q
q
q
Job ____________ Item # ___________
GAS DECK OVENS
Single Double
151 152
3151 3152
4151 4152
STANDARD FEATURES
48,000 to 70,000 BTUH per deck, natural or LP gas (LP not
CE approved
300°-650° F (149°-343°C) throttling thermostat
Top & bottom heat control damper
Combination gas controls with valve, regulator & pilot safety
Heavy-duty, slide-out flame diverters
8" (203mm) interior deck heights with 1 1/2" (38mm) thick
Cordierite hearth decks
All stainless steel exteriors
Aluminized steel interiors
Spring balanced, fully insulated doors
Side or rear gas connections
7-Gauge legs
Fully insulated throughout
1 Year limited part and labor warranty
OPTIONS & ACCESSORIES
Steel decks
150°-550° F (65°-288°C) thermostat
Set of 4 casters - two with locks
Stainless steel leg covers
Special height legs
Steam Injection
Automatic oven starter
Draft flue for direct vent (not available on CE units)
CERTIFICATIONS
®
Continuous product improvement is a policy of Bakers Pride Oven Company.
Therefore, specifications and design are subject to change without notification
G
Triple
153
3153
4153
CERTIFIED
