INSTALLATION AND OPERATING INSTRUCTIONS
ELECTRIC CONVECTION OVENS
OVEN MUST BE KEPT CLEAR OF COMBUSTIBLES AT ALL TIMES
!
!
Improper installation, adjustment, alteration, service or maintenance
can cause property damage, injury or death. Read the Installation,
Operating and Maintenance Instructions thoroughly before installing or
servicing this equipment.
!
Initial heating of oven may generate smoke or fumes and must be done in
a well-ventilated area. Overexposure to smoke or fumes may cause
nausea or dizziness.
This equipment has been engineered to provide you with year round dependable service when used
according to the instructions in this manual and standard commercial kitchen practices.
(914) 576-0200 Phone
(914) 576-0605 Fax
BAKERS
PRIDE
Cyclone
Models: BCO-E and GDCO-E
INTENDED FOR OTHER THAN HOUSEHOLD USE
RETAIN THIS MANUAL FOR FUTURE REFERENCE
FOR YOUR SAFETY
Do not store or use gasoline or other flammable vapors
and liquids in the vicinity of this or any other appliance.
WARNING
WARNING
BAKERS PRIDE OVEN CO., INC.
30 Pine Street
New Rochelle, NY 10801
5-41-5
(800) 431-2745 US & Canada
www.bakerspride.com Web Address
1
!
!
!
Form # 8898400 1-05
Advertisement
Table of Contents
Related Manuals for Bakers Pride Cyclone SERIES
Summary of Contents for Bakers Pride Cyclone SERIES
- Page 1 This equipment has been engineered to provide you with year round dependable service when used according to the instructions in this manual and standard commercial kitchen practices. Form # 8898400 1-05 BAKERS PRIDE OVEN CO., INC. 30 Pine Street New Rochelle, NY 10801 (914) 576-0200 Phone (800) 431-2745 US &...
-
Page 2: Table Of Contents
INDEX I. INSTALLATION INSTRUCTIONS SECTION ITEM PAGE Receiving Set-up/Mounting Installation with Casters Location & Minimum Clearances Electrical Connections Flue Connection Ventilation Initial Cleaning System Check - Rotary Controls II. OPERATING INSTRUCTIONS SECTION ITEM PAGE General Instructions Operation Sequence For Rotary Controls Cook Only Timed Cooking Cook &... -
Page 3: A Receiving
I. INSTALLATION INSTRUCTIONS A. RECEIVING Read the notice on the outside carton regarding damage in transit. Damage discovered after opening the carton is “CONCEALED DAMAGE.” Carrier must be notified immediately to send an inspector and to furnish forms for claims against the carrier. When the oven arrives, it should consist of: A crate or carton containing your new oven (two for a stacked unit). -
Page 4: C Installation With Casters
C. INSTALLATION WITH CASTERS (OPTIONAL): Four casters (two with wheel brakes) and the mounting hardware are packed and included in the shipment if ordered. Install casters with wheel brakes on the front of the unit. Installation must conform UL 197: Electrical Supply Connections For Permanently Connected Appliances. It requires that permanently connected appliances with casters be provided with a means for securing the appliance to the building structure to limit the movement of the appliance. -
Page 5: F Flue Connection Ventilation
The oven, when installed, must be electrically grounded in accordance with local codes and/or the latest edition of the National Electrical Code ANSI/NFPA No. 70 in the USA (Canadian Electrical Code CSA Standard C22.1, Part 1 in Canada). In Europe, the appliance must be connected by an earthen cable to all other units in the complete installation and, thence, to an independent earth connection in compliance with EN 60335-1 and/or local codes. -
Page 6: A General Instructions
IN THE EVENT OF POWER FAILURE, THE OVEN WILL NOT OPERATE. PROGRAMMING MENUS: See Operating/Programming Instruction Booklet for Programmable Oven Control with Bakers Pride Software for Cyclone Series Convection Ovens supplied with this option. II. OPERATING INSTRUCTIONS A. GENERAL INSTRUCTIONS: (1) This equipment has an Electronic Temperature Control. -
Page 7: Cook & Hold
(7) When timer reaches zero, a buzzer will sound. (8) Turn the timer knob to “O” position. (9) Remove the product from the oven. NOTE: TIMER DOES NOT CONTROL THE OVEN. Cook and Hold Rotary Control: (1) Close the oven doors. (2) Turn Selector Switch to “HI”... -
Page 8: D Servicing
Cleaning The Blower Wheel Figure 1 Blower Wheel Set Screws (2) Motor Wheel Puller Bolt 3/8”-Hex D. SERVICING: NOTE: THIS APPLIANCE MUST BE SERVICED BY AN AUTHORIZED SERVICE AGENT. (1) Power supply to the unit must be disconnected before any service is performed. (2) Most of the service on the unit can be performed from the front and/or control panel side. -
Page 9: Stacking Instructions
Figure 3 STACKING INSTRUCTIONS FOR: BCO-E & GDCO-E CONVECTION OVENS Remove flue from top oven and replace with item 1 Attach part # 21818062 with 6 each 8-32 stainless screws Remove flue from bottom oven, and re-install after top oven is in place. Material: 14 ga 201 Stainless Item 1... -
Page 10: Leg Assembly Instructions
Figure 4 LEG ASSEMBLY INSTRUCTIONS-MODEL: BCO-E & GDCO-E WITH PLATE CASTER Description Item 21818092 Leg, 25" SS Weldment Assy 8633102 Caster, 5” Swivel W/Top Plate 8227700 Hex Hd 5/16-18 X ¾ Bolt #5 Zn 8509300 Washer, Flat SAE, 5/16 8435000 Hex-nut 5/16-18 82447-00 Hex Hd. -
Page 12: Single Phase 208V Or 240V Wiring Diagram
Single Phase 208V or 240V Wiring Diagram (CH-100 Control) CENTRIFUGAL SWITCH HIGH MOTOR MOTOR FUSE BOX CENTRIFUGAL SWITCH RELAY T1 TOT4 PROBE T1 TOT2 T3TOT2 DOOR FRONT ELEMENT HEAT 4 POLES, 40 AMPS CONTACTOR LIGHTS Ground Stud POWER L1 L3 L2 SINGLE PHASE 208/ 240V DOORS ACTIVATE... - Page 13 IMPORTANT FOR FUTURE REFERENCE Please complete this information and retain this manual for the life of the equipment. For Warranty Service and/or Parts, this information is required. Model Number Serial Number Date Purchased Notes:...
- Page 14 Notes:...
-
Page 15: Warranty
BAKERS PRIDE Factory Authorized Service Center. This Warranty is in lieu of all other warranties, expressed or implied, and all other obligations or liabilities on the manufacturers part. BAKERS PRIDE shall in no event be liable for any special, indirect or consequential damages, or in any event for damages in excess of the purchase price of the unit. The repair or replacement of proven defective parts shall constitute a fulfillment of all obligations under the terms of this warranty. - Page 16 BAKERS PRIDE BAKERS PRIDE OVEN CO., INC. 30 Pine Street New Rochelle, NY 10801 +1 (800) 431-2745 US & Canada +1 (914) 576-0200 Phone sales@bakerspride.com E-Mail +1 (914) 576-0605 Fax www.bakerspride.com Web Address...
