- Page 1 Thermo Scientific Orion 320, 350 and 370 PerpHecT LogR Meter ® ® User Guide...
- Page 2 ROSS and the COIL trade dress are trademarks of Thermo Fisher Scientific Inc. AQUAfast, Cahn, ionplus, KNIpHE, No Cal, ORION, perpHect, PerpHecT, PerpHecTion, pHISA, pHuture, Pure Water, Sage, Sensing the Future, SensorLink, ROSS, ROSS Ultra, Sure-Flow, Titrator PLUS and TURBO2 are registered trademarks of Thermo Fisher. 1-888-pHAX-ION, A+, All in One, Aplus, AQUAsnap, AssuredAccuracy, AUTO-BAR, AUTO-CAL, AUTO DISPENSER, Auto-ID, AUTO-LOG, AUTO-READ, AUTO-STIR, Auto-Test, BOD AutoEZ, Cable-Free, CERTI-CAL, CISA, DataCOLLECT, DataPLUS, digital LogR, DirectCal, DuraProbe, Environmental Product Authority, Extra Easy/Extra Value, FAST QC, GAP, GLPcal, GLPcheck, GLPdoc, ISEasy, KAP, LabConnect, LogR, Low Maintenance Triode, Minimum Stir...
-
Page 3: Table Of Contents
Table of Contents Chapter 1 Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1 General Information . - Page 4 Chapter 5 Operating .the .370 .Meter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-1 Meter Power Up .
-
Page 5: Introduction
Introduction Chapter 1 General Information Thermo Scientific Orion pH and ISE meters are designed for every application, from basic pH measurements to advanced concentration analysis using ion selective electrodes . This user guide contains information on the preparation, operation and maintenance for the 320, 350 and 370 PerpHecT LogR meters . - Page 6 Figure .1 .– . .370 .PerpHecT .LogR .Meter Thermo Scientific Orion 320, 350 and 370 PerpHecT LogR Meter User Guide ® ®...
-
Page 7: Meter Overview
. The buffers used during the last pH calibration are designated by the indicators along the left side of the display . See Figure .2 . Figure .2 .– . .370 .PerpHecT .Meter .Display Thermo Scientific Orion 320, 350 and 370 PerpHecT LogR Meter User Guide ®... -
Page 8: 320 Meter Keypad
Press to initiate pH calibration. setup Press to enter setup menu. Setup menu is entered to change meter operating parameters and to enter manual calibration buffer values. Thermo Scientific Orion 320, 350 and 370 PerpHecT LogR Meter User Guide ® ®... -
Page 9: 350 And 370 Meter Keypad
Press to enter setup menu. Setup menu is entered to change meter operating parameters and to enter manual calibration buffer values. Press to change display resolution. Figure .3 .– . .PerpHecT .Meter .Keypad Thermo Scientific Orion 320, 350 and 370 PerpHecT LogR Meter User Guide ® ®... -
Page 10: Meter Connections
. Use only Thermo Scientific Orion ATC probes that are designed for PerpHecT meters, Cat . No . 927005 (epoxy body), Cat . No . 927006 (glass body) or Cat . -
Page 11: Logr Temperature Measurements
0.016 0.003 0.006 0.009 0.012 0.015 0.003 0.006 0.009 0.012 0.015 0.003 0.006 0.009 0.012 0.015 0.003 0.006 0.008 0.011 0.014 0.003 0.006 0.008 0.011 0.014 Thermo Scientific Orion 320, 350 and 370 PerpHecT LogR Meter User Guide ® ®... - Page 12 . To maximize system performance and accuracy, use a PerpHecT or PerpHecT ROSS pH electrode . Figure .5 .– . .LogR .Resistance .vs . . T emperature .Graph Thermo Scientific Orion 320, 350 and 370 PerpHecT LogR Meter User Guide ®...
-
Page 13: Operating The 320 Meter
0 to 14 pH range . If SET is selected, the meter will advance to setting the manual buffer values . Buffer values must be at least 1 and not more than 4 pH units apart . Thermo Scientific Orion 320, 350 and 370 PerpHecT LogR Meter User Guide ®... -
Page 14: Ph Calibration
. Note: When making measurements in the LogR mode, you must calibrate for temperature before attempting a pH calibration . Thermo Scientific Orion 320, 350 and 370 PerpHecT LogR Meter User Guide ®... -
Page 15: Two Point Autocalibration
9 . Rinse the electrode with distilled water and place it into the sample . Record the pH and temperature directly from the meter display when the ready icon is displayed or when the electrode signal is stable . Thermo Scientific Orion 320, 350 and 370 PerpHecT LogR Meter User Guide ®... -
Page 16: One Point Autocalibration
8 . Rinse the electrode with distilled water and place it into the sample . Record the pH and temperature directly from the meter display when the ready icon is displayed or when the electrode signal is stable . Thermo Scientific Orion 320, 350 and 370 PerpHecT LogR Meter User Guide ®... -
Page 17: Manual Calibration
Record the pH directly from the main meter display and temperature from upper field when the ready icon is displayed or when the electrode signal is stable . Thermo Scientific Orion 320, 350 and 370 PerpHecT LogR Meter User Guide ®... -
Page 18: Logr Temperature Calibration
LogR mode, a LogR temperature calibration must be performed . It is recommended that at least a two-point temperature calibration be performed to meet optimum system accuracy . Refer to the Appendix for additional information . Thermo Scientific Orion 320, 350 and 370 PerpHecT LogR Meter User Guide ®... -
Page 19: Logr Calibration
. This will cause the system to display ESC, proceed to pH mode and retain to the previous LogR temperature calibration data . Thermo Scientific Orion 320, 350 and 370 PerpHecT LogR Meter User Guide ®... -
Page 20: Mv/Orp Measurements
. In the measurement mode, use the scroll (▲ ▼) keys to manually set the temperature value . This temperature will be used to calculate temperature-corrected pH values . Thermo Scientific Orion 320, 350 and 370 PerpHecT LogR Meter User Guide ®... -
Page 21: Operating The 350 Meter
( ) keys until 01 is displayed . Press the yes key ▲ ▼ when the desired setting is displayed . Thermo Scientific Orion 320, 350 and 370 PerpHecT LogR Meter User Guide ® ®... - Page 22 The display will read LO . Use the scroll ( ) keys to set the last 4 digits . ▲ ▼ Press the yes key to accept . Thermo Scientific Orion 320, 350 and 370 PerpHecT LogR Meter User Guide ®...
-
Page 23: Ph Calibration
. Note: When making measurements in the LogR mode, you must calibrate for temperature before attempting a pH calibration . Thermo Scientific Orion 320, 350 and 370 PerpHecT LogR Meter User Guide ®... -
Page 24: Three Point Autocalibration
10 . Rinse the electrode with distilled water and place it into the sample . Record the pH and temperature directly from the meter display when the ready icon is displayed or when the electrode signal is stable . Thermo Scientific Orion 320, 350 and 370 PerpHecT LogR Meter User Guide ®... -
Page 25: Two Point Autocalibration
9 . Rinse the electrode with distilled water and place it into the sample . Record the pH and temperature directly from the meter display when the ready icon is displayed or when the electrode signal is stable . Thermo Scientific Orion 320, 350 and 370 PerpHecT LogR Meter User Guide ®... -
Page 26: One Point Autocalibration
8 . Rinse the electrode with distilled water and place it into the sample . Record the pH and temperature directly from the meter display when the ready icon is displayed or when the electrode signal is stable . Thermo Scientific Orion 320, 350 and 370 PerpHecT LogR Meter User Guide ®... -
Page 27: Manual Calibration
Record the pH directly from the main meter display and temperature from upper field when the ready icon is displayed or when the electrode signal is stable . Thermo Scientific Orion 320, 350 and 370 PerpHecT LogR Meter User Guide ®... -
Page 28: Logr Temperature Calibration
LogR mode, a LogR temperature calibration must be performed . It is recommended that at least a two-point temperature calibration be performed to meet optimum system accuracy . Refer to the Appendix for additional information . Thermo Scientific Orion 320, 350 and 370 PerpHecT LogR Meter User Guide ®... -
Page 29: Logr Calibration
. This will cause the system to display ESC, proceed to pH mode and retain to the previous LogR temperature calibration data . Thermo Scientific Orion 320, 350 and 370 PerpHecT LogR Meter User Guide ®... -
Page 30: Mv/Orp Measurements
3 . Press the cal key to initiate a calibration sequence . The display will show CAL for the entire calibration . The displayed reading will be the absolute mV reading . If using the Thermo Scientific Orion ORP standard and Thermo Scientific Orion ORP electrode with Cat . No . -
Page 31: Glpcheck Electrode Diagnostic Procedure
E-23 Bad Slope being printed . Clean the pH electrode as direct in the pH electrode user guide, use fresh buffers and repeat the calibration sequence . If problems persist, or refer to the Troubleshooting section for troubleshooting procedures . Thermo Scientific Orion 320, 350 and 370 PerpHecT LogR Meter User Guide 4-11 ®... - Page 32 Notes 4-12 Thermo Scientific Orion 320, 350 and 370 PerpHecT LogR Meter User Guide ® ®...
-
Page 33: Operating The 370 Meter
( ) keys until 01 is displayed . Press the yes key ▲ ▼ when the desired setting is displayed . Thermo Scientific Orion 320, 350 and 370 PerpHecT LogR Meter User Guide ® ®... - Page 34 The display will read LO . Use the scroll ( ) keys to set the last 4 digits . ▲ ▼ Press the yes key to accept . Thermo Scientific Orion 320, 350 and 370 PerpHecT LogR Meter User Guide ®...
-
Page 35: Ph Calibration
. Note: When making measurements in the LogR mode, you must calibrate for temperature before attempting a pH calibration . Thermo Scientific Orion 320, 350 and 370 PerpHecT LogR Meter User Guide ®... -
Page 36: Three Point Autocalibration
10 . Rinse the electrode with distilled water and place it into the sample . Record the pH and temperature directly from the meter display when the ready icon is displayed or when the electrode signal is stable . Thermo Scientific Orion 320, 350 and 370 PerpHecT LogR Meter User Guide ®... -
Page 37: Two Point Autocalibration
9 . Rinse the electrode with distilled water and place it into the sample . Record the pH and temperature directly from the meter display when the ready icon is displayed or when the electrode signal is stable . Thermo Scientific Orion 320, 350 and 370 PerpHecT LogR Meter User Guide ®... -
Page 38: One Point Autocalibration
8 . Rinse the electrode with distilled water and place it into the sample . Record the pH and temperature directly from the meter display when the ready icon is displayed or when the electrode signal is stable . Thermo Scientific Orion 320, 350 and 370 PerpHecT LogR Meter User Guide ®... -
Page 39: Manual Calibration
Record the pH directly from the main meter display and temperature from upper field when the ready icon is displayed or when the electrode signal is stable . Thermo Scientific Orion 320, 350 and 370 PerpHecT LogR Meter User Guide ®... -
Page 40: Logr Temperature Calibration
LogR mode, a LogR temperature calibration must be performed . It is recommended that at least a two-point temperature calibration be performed to meet optimum system accuracy . Refer to the Appendix for additional information . Thermo Scientific Orion 320, 350 and 370 PerpHecT LogR Meter User Guide ®... -
Page 41: Logr Calibration
. This will cause the system to display ESC, proceed to pH mode and retain to the previous LogR temperature calibration data . Thermo Scientific Orion 320, 350 and 370 PerpHecT LogR Meter User Guide ®... -
Page 42: Ise (Concentration) Calibration
Note: The LogR function must be disabled when using the ISE mode . Note: The 370 meter can only perform a two point ISE calibration . 5-10 Thermo Scientific Orion 320, 350 and 370 PerpHecT LogR Meter User Guide ®... -
Page 43: Two Point Ise Calibration
. 10 . Record the concentration and temperature directly from the meter when the ready icon is displayed or when the electrode signal is stable . Thermo Scientific Orion 320, 350 and 370 PerpHecT LogR Meter User Guide 5-11 ®... -
Page 44: Mv/Orp Measurements
3 . Press the cal key to initiate a calibration sequence . The display will show CAL for the entire calibration . The displayed reading will be the absolute mV reading . If using the Thermo Scientific Orion ORP standard and Thermo Scientific Orion ORP electrode with Cat . No . -
Page 45: Glpcheck Electrode Diagnostic Procedure
E-23 Bad Slope being printed . Clean the pH electrode as direct in the pH electrode user guide, use fresh buffers and repeat the calibration sequence . If problems persist, or refer to the Troubleshooting section for troubleshooting procedures . Thermo Scientific Orion 320, 350 and 370 PerpHecT LogR Meter User Guide 5-13 ®... - Page 46 Notes 5-14 Thermo Scientific Orion 320, 350 and 370 PerpHecT LogR Meter User Guide ® ®...
- Page 47 SIG GND SIG GND Jumper pins 4 and 6 together . The RS232 port on the meter is a nine pin D- shell male connector (DB-9 style) . Thermo Scientific Orion 320, 350 and 370 PerpHecT LogR Meter User Guide ®...
- Page 48 Figure .6 .– . .Printer . W iring .Diagram Thermo Scientific Orion 320, 350 and 370 PerpHecT LogR Meter User Guide ® ®...
-
Page 49: Customer Services
. These procedures verify the proper operation of the 320, 350 and 370 PerpHecT meters . Thermo Scientific Orion 320, 350 and 370 PerpHecT LogR Meter User Guide ®... - Page 50 If no keys are pressed or there is a problem with a key, the meter will recognize an error and display E-07. Press the yes key to continue. Thermo Scientific Orion 320, 350 and 370 PerpHecT LogR Meter User Guide ®...
-
Page 51: Meter Self-Test
. The display should read 0 ± 1 mV . If the meter does not read 0 ± 1 mV with the BNC shorting cap attached to the BNC input, contact Technical Support . Thermo Scientific Orion 320, 350 and 370 PerpHecT LogR Meter User Guide ®... -
Page 52: 350 Meter Check-Out
. The display should read 0 ± 1 mV . If the meter does not read 0 ± 1 mV with the BNC shorting cap attached to the BNC input, contact Technical Support . Thermo Scientific Orion 320, 350 and 370 PerpHecT LogR Meter User Guide ®... -
Page 53: 370 Meter Check-Out
. The display should read 0 ± 1 mV . If the meter does not read 0 ± 1 mV with the BNC shorting cap attached to the BNC input, contact Technical Support . Thermo Scientific Orion 320, 350 and 370 PerpHecT LogR Meter User Guide ®... -
Page 54: Operator Assistance Codes
• Refer to the electrode user guide for instructions on how to clean and condition the electrode. • Recalibrate the meter system using fresh buffers/ standards. Thermo Scientific Orion 320, 350 and 370 PerpHecT LogR Meter User Guide ® ®... - Page 55 • If the serial number was being changed, exit the setup menu and then re-enter the serial number in the setup menu. Thermo Scientific Orion 320, 350 and 370 PerpHecT LogR Meter User Guide ®...
-
Page 56: Assistance
. Note: To meet or exceed FCC regulations the Thermo Scientific Orion power supply must be used . This digital apparatus does not exceed the Class A limits for radio noise emissions from digital apparatus set out in the Radio Interference Regulations of the Canadian Department of Communications . -
Page 57: Certificate Of Conformity
IEC 801-2 ESD Susceptibility IEC 801-3 Radiated Susceptibility IEC 801-4 Conducted Susceptibility These Thermo Scientific Orion products have been manufactured in compliance with the provisions of the relevant Thermo Fisher Scientific manufacturing and test documents and processes . Further, these documents and processes are recognized as complying with ISO 9000:2000 by QMI, listed as File # 001911 . - Page 58 Notes 7-10 Thermo Scientific Orion 320, 350 and 370 PerpHecT LogR Meter User Guide ® ®...
-
Page 59: Ordering .Information .And .Specifications
4.01 buffer, pH 7.00 buffer, pH 10.01 buffer and ROSS storage solution 0350A9 350 PerpHecT meter (110 V) 0350A8 350 PerpHecT meter (220 V) 0350A7 350 PerpHecT meter (240 V) Thermo Scientific Orion 320, 350 and 370 PerpHecT LogR Meter User Guide ® ®... - Page 60 BNC connector PerpHecT ROSS combination pH electrode with epoxy body and BNC 8256BN connector 8272BN PerpHecT ROSS Sure-Flow combination pH electrode with glass body and BNC connector Thermo Scientific Orion 320, 350 and 370 PerpHecT LogR Meter User Guide ® ®...
- Page 61 10.01 buffer, 475 mL 911010 pH 10.01 buffer, 10 PerpHecT individual buffer pouches 911025 pH 10.01 buffer, 25 PerpHecT individual buffer pouches 910112 pH 12.46 buffer, 475 mL Thermo Scientific Orion 320, 350 and 370 PerpHecT LogR Meter User Guide ® ®...
-
Page 62: Specifications
Battery Backup Environmental Indoor use only Specifications Altitudes up to 2000 meters (all meters): Temperature between 5 °C and 45 °C Relative humidity between 5% and 85% Thermo Scientific Orion 320, 350 and 370 PerpHecT LogR Meter User Guide ® ®... - Page 63 0.06 0.003 0.001 9207BN 0.16 0.07 0.002 0.001 9256BN 0.27 0.07 0.003 0.001 9272BN 0.22 0.06 0.003 0.001 * For 20 °C temperature compensation spans . Thermo Scientific Orion 320, 350 and 370 PerpHecT LogR Meter User Guide ® ®...
- Page 64 0.02 0.000 0.000 9207BN 0.07 0.07 0.001 0.001 9256BN 0.02 0.00 0.001 0.000 9272BN 0.22 0.06 0.003 0.001 * For 20 °C temperature compensation spans . Thermo Scientific Orion 320, 350 and 370 PerpHecT LogR Meter User Guide ® ®...
- Page 65 Notes Thermo Scientific Orion 320, 350 and 370 PerpHecT LogR Meter User Guide ® ®...
- Page 66 Notes Thermo Scientific Orion 320, 350 and 370 PerpHecT LogR Meter User Guide ® ®...
- Page 67 Thermo Fisher Scientific Environmental Instruments Water Analysis Instruments 166 Cummings Center Beverly, MA 01915 USA Tel: 978-232-6000 Toll Free: 800-225-1480 Dom. Fax: 978-232-6015 Int’l. Fax: 978-232-6031 www.thermo.com/water 255007-001 Rev A...
