Advanced Tabs There are four tabs providing advanced informaIon or controls: Data, Focus, Timer, and HDR. A Tripod or StackShot tab will appear as a fifh tap if the CamRanger is being used with the CamRanger PT Hub and a supported tripod head (the MP-360, Bescor, or Hague) or StackShot. Data The data tab shows an RGB histogram and meta-data associated with the captured image in the main image view. The following meta-data is provided: • ShuKer Speed • Aperture • MegaPixels (Note this is not file size, but image resoluIon) • ISO • Metering Mode • Exposure CompensaIon Value Within live view the histogram can be toggled on or off. Of note, the histogram will reduce the live view frame rate. Focus The focus tab is only enabled during live view and provides advanced focusing controls. Focus Adjust There are two sets of buKons to move the lens’ focal plane nearer or further from the camera. Each set has three buKons with different sized arrows to specify a large, medium, or small step in focus. Tap the buKon to move the focus by a single increment, holding down the buKon will have no affect. Focus Stacking Focus stacking is a process of taking mulIple captures with slight changes in focus and then post processing them to enhance the depth of field. This control allows the user to set the focus step size to take between in each shot and the number of shots to take. Each focus step will move the focal plane further from the camera. So the user will want to set the focus to the nearest plane desired to be in focus and start the stacking process from there. If too few captures were taken, the process can be restarted from where the iniIal stacking ended. Note:...
CamRanger device, the Windows computer does not need to remain on or connected once the intervalomiter command is iniIated. • The “Shot Delay” should not be used for precision Iming, parIcularly when the delay is only a few seconds or less. • Once an intervalometer sequence is begun, the Imer tab will provide a countdown of the current Imelapse as well as a buKon to cancel the Ime lapse. Bulb • The Bulb controls are only enabled when the camera is in bulb mode and the camera supports remote bulb shots. • The entry fields are used to specify the iniIal delay before the first shot and the length of the exposure. • Afer configuraIon, press the “Start” buKon to begin the bulb process. • The bulb commands are stored on the CamRanger device and the Windows does not need to remain on or connected. HDR The “HDR”, or Advanced BrackeIng, tab can be used to generate a series of photos with varying exposures. • Advanced BrackeIng is only enabled when the camera is in Manual exposure mode. • The Property field specifies the camera property to be varied. There are three opIons: ShuKer Speed, Aperture, and ISO. • The IniIal Delay field specifies the amount of delay, if any, to take before beginning the brackeIng sequence. • The iniIal value for the selected property is set with the Start Value field. • The total number of images to capture is specified by the...
Tips & Troubleshoo0ng Below are some Ips and troubleshooIng for common quesIons or issues arranged by category: Registra0on • If the CamRanger Windows applicaIon is re-installed, the computer may need to be re- registered. • Most registraIon issues are due to not having Internet connecIvity or entering the serial number incorrectly. • If you sIll have issues, please email support@CamRanger.com for assistance. Connec0on • Make sure CamRanger is fully powered on and iniIalized (it should take approximately 30 seconds). The power light and WiFi light should both be on. • The password to connect to the CamRanger WiFi is the CamRanger serial number in all CAPS. If there are sIll issues connecIng, turning the WiFi off on the Windows may help. • If the CamRanger applicaIon is connected to the CamRanger device, but no camera is connected, it will aKempt to connect to a camera approximately every 5 seconds. • If the computer is outside of or near the edge of the range of the CamRanger hardware there will be connecIon problems. • Disconnect and reconnect the CamRanger by selecIng “ConnecIon” on the Windows CamRanger menu bar then “Connect” to force a new session/connecIon. • Power cycling the camera and CamRanger as well as restarIng the applicaIon will completely refresh the connecIon. • When the camera baKery begins to get low, certain commands may start to fail or a connecIon may be refused. • The CamRanger hardware can only be connected to a single Windows computer at a Ime. • A second network connecIon, such as with an Ethernet cable, can cause connecIon failures. • If there is an inconsistent or intermiKent connecIon, the issue is ofen related to the USB connecIon. A different USB cable will ofen fix the problem.
Commands • Depending on the camera and the mode, capture can fail if the camera fails to acquire focus. • Intervalometer and Bulb commands are stored on the CamRanger hardware such that the Windows computer does not need to remain on and connected. • When an operaIon, command, or sehng is not available or not working the issue is ofen related to the camera setup. For example: • Toggling to AF is disabled if the camera lens switch is set to MF. • Live view will fail on Canon cameras if Live View ShooIng is disabled in the camera’s menu. • Capture fails because the removable media on the camera is full. • For Canon cameras, the Live View focus mode within the camera’s menu must be set to “Live View”. • AdjusIng or viewing the number of brackeIng shots is not currently supported. The display assumes three shots. However, if the number of shots is actually 2, 5, 7, 9, etc. the bracket amount is sIll correct it will just incorrectly display 3 shots. • Some features are simply not supported by some cameras. For example conInuous capture mode is not supported on the Canon 40D and many older Nikons do not support bulb shots. See the camera capability matrix at www.CamRanger.com for more detailed informaIon. • If touch focusing does not work on a Canon camera, the likely cause is that the rear AF buKon has been changed to some other funcIon and must be reset back to its default AF behavior. Images • The thumbnails are not downloaded unIl afer the image has been recorded to the camera’s card. On most cameras this is relaIvely quick. However, depending on the camera, speed of removable media and number of shots taken in succession, there can be a lag. • CamRanger can be used to view and download pictures captured through other means. So a photographer could be capturing images, or a RF or light trigger could capture images and the CamRanger applicaIon would automaIcally download the thumbnails. • If shooIng to mulIple cards, ensure the playback card is set to the memory card of interest.
