- Page 1 R SERIES Installation and Operation Manual Model R.35-3896-EN communitypro.com...
-
Page 2: Important Safety Instructions
If you have any questions or do not understand the meaning of companies have a short time limit within which these terms, do not proceed with installation. Contact your local dealer, distributor, or call Community they will investigate claims. Be sure to save directly for assistance. -
Page 3: Product Representation
PRODUCT REPRESENTATION R.35-3896-EN FULL RANGE MODEL 3-Layer WeatherStop™ Grille 8mm Rigging Points (2 sides) FRONT Bracket / Yoke 8mm Rigging Points (2 sides) Weather Cover Gland Nut 13.5mm (.5") ID Safety Attachment Point (user must supply appropriate fastener and safety cable) Internal Transformer Mounting 3.5 x 19mm Pan... -
Page 4: Rigging / Suspension And Safety
Community loudspeakers Loudspeaker rigging should be performed may be safely suspended when each loudspeaker model is suspended with Community- only by certified rigging professionals using manufactured mounting and rigging brackets or yokes specifically designed for use certified rigging hardware chosen for the with that particular model of loudspeaker. -
Page 5: Installation
Pan-tilt and full rotation yokes 8mm SS Flat Washer are available for multi-angled and down- fire applications. 8 x 32 mm SS Stud (leave 3/4" sticking out) Figure 3. Mount the loudspeaker to the yoke R.35-3896-EN Installation and Operation Manual Page 5... - Page 6 Important Note: If the NL4 connection is used then the weatherproof cover cannot be attached. Direct connection to the Spade terminal terminal strips is the preferred connection method for all permanent or outdoor applications. Wire Connectors Page 6 Installation and Operation Manual R.35-3896-EN...
-
Page 7: Input Panel Connections
8. All provided hardware (or other approved replacement) must be installed in order to maintain weather-resistance and preserve the product warranty. 9. Power and test the system. Pan Head Screws Wire Input panel Figure 6. Weather cover attachment R.35-3896-EN Installation and Operation Manual Page 7... -
Page 8: Maintenance
(in the same corner locations). Remove any screws securing the grille Remove grille Insert thin blade of screwdriver between frame and enclosure and move down seam while twisting to loosen grille Figure 7. Remove grille Page 8 Installation and Operation Manual R.35-3896-EN... -
Page 9: Maintaining Weather Resistance
EC STATEMENT OF CONFORMITY This document confirms that the range of products of Community Professional Loudspeakers bearing the CE label meet all the requirements laid down by the Member States Council for adjustment of legal requirements, furthermore the products comply with the rules and regulations referring to the electromagnetic compatibility of devices from 16 April 2016. -
Page 10: Specifications
6. Nominal Max SPL @ 1m: Calculated from continuous power handling and sensitivity @ 1m 7. Rated Noise Power (per EN54-24): The 100W/ 100V and 50W/100V taps are certified for EN54-24 use. Low impedance, all 70V inputs, and 200W/100V tap are not rated for EN54-24 use. Page 10 Installation and Operation Manual R.35-3896-EN... -
Page 11: Axes And Planes
Vertical Plane (blue) intersects the reference plane at a right angle including the reference axis and the center point of the cabinet's front radius Horizontal Plane (green) intersects the reference plane at a right angle and includes the reference axis R.35-3896-EN Installation and Operation Manual Page 11... -
Page 12: Use A Digital Signal Processor
For best performance, loudspeaker protection and system longevity, a digital signal to insure that the information processor (DSP ) should be used with all R SERIES loudspeakers. Community's dSPEC226 contained in this manual was processor(s) and Resyn® software contain all of the information (high pass filters, limiters, complete and accurate at the factory tunings) and DSP settings to fully optimize your system.
