  • Page 1 DDCC-ChungLi Document is Released 2011.06.30 13:31:41 +08'00'...
  • Page 2 Use pursuant to applicable agreements <附件> Title page Alcatel-Lucent 9363 Metro Cell - Indoor V2 2100MHz and 1900/850MHz Installation and commissioning 401-387-097 Alcatel-Lucent – Proprietary Issue 1 Use pursuant to applicable agreements May 2011...
  • Page 3 The information presented is subject to change without notice. Alcatel-Lucent assumes no responsibility for inaccuracies contained herein. Copyright © 2011 Alcatel-Lucent. All rights reserved. Contains proprietary/trade secret information which is the property of Alcatel-Lucent and must not be made available to, or copied or used by anyone outside Alcatel-Lucent without its written authorization.

  • Page 4: Table Of Contents

    Safety statements Overview ...................................... Structure of safety statements ............................... Safety ......................................Safety - specific hazards ................................. Product safety ..................................... Product overview Overview ..................................................................................Alcatel-Lucent 9363 MC Alcatel-Lucent – Proprietary 401-387-097 Use pursuant to applicable agreements Issue 1 May 2011...
  • Page 5 Metro Cell - Indoor wall mount spacer Overview ..................................... Wall mount spacer ................................... Product conformance statements Overview ..................................... European Union ..................................United States ....................................Glossary Index ..............................................Alcatel-Lucent – Proprietary Alcatel-Lucent 9363 MC Use pursuant to applicable agreements 401-387-097 Issue 1 May 2011...
  • Page 6 List of figures Alcatel-Lucent 9363 Metro Cell - Indoor ......................Alcatel-Lucent 9363 Metro Cell - Indoor (2100 MHz variant) ............................................................ Alcatel-Lucent 9363 MC Alcatel-Lucent – Proprietary 401-387-097 Use pursuant to applicable agreements Issue 1 May 2011...

  • Page 7: About This Document

    • None Other changes: • None Intended audience The audience for this document is Installation personnel. Supported systems This document applies to the Alcatel-Lucent 9363 Metro Cell - Indoor V2 2100MHz and 1900/850MHz ..............................................Alcatel-Lucent 9363 MC Alcatel-Lucent – Proprietary 401-387-097...

  • Page 8: How To Use This Document

    Cell Indoor and Outdoor com. for the Metro Cell Indoor Troubleshooting, 401-387-076 Standard for Installation of Lightning protection systems Lightning Protection Systems, NFPA ..............................................viii Alcatel-Lucent – Proprietary Alcatel-Lucent 9363 MC Use pursuant to applicable agreements 401-387-097 Issue 1 May 2011...

  • Page 9: Document Support

    Voltage AC Power Circuits, IEEE C62.41 (Latest Edition) Document support For support in using this or any other Alcatel-Lucent document, contact Alcatel-Lucent at one of the following telephone numbers: • 1-888-582-3688 (for the United States) • 1-317-377-8618 (for all other countries) Technical support For technical support, contact your local Alcatel-Lucent customer support team.
  • Page 10 About this document ............................................................................................Alcatel-Lucent – Proprietary Alcatel-Lucent 9363 MC Use pursuant to applicable agreements 401-387-097 Issue 1 May 2011...

  • Page 11: Safety Statements

    However, hazards may arise if procedures are not followed correctly or safe working practices are not complied with. Contents Structure of safety statements Safety Safety - specific hazards Product safety ..............................................Alcatel-Lucent 9363 MC Alcatel-Lucent – Proprietary 401-387-097 Use pursuant to applicable agreements Issue 1 May 2011...

  • Page 12: Overview

    Structure of safety statements Overview Safety statements describe the safety risks relevant while performing tasks on Alcatel-Lucent products during deployment and/or use. Failure to avoid the hazards may have serious consequences. General structure Safety statements include the following structural elements:...
  • Page 13 Indicates a hazardous situation which, if not avoided, could result in minor or moderate injury. NOTICE Indicates a hazardous situation not related to personal injury..............................................Alcatel-Lucent 9363 MC Alcatel-Lucent – Proprietary 401-387-097 Use pursuant to applicable agreements Issue 1 May 2011...

  • Page 14: Safety

    Opening and removing covers and/or circuit boards may expose you to dangerous voltages or other risks. Incorrect reassembly can cause electrical shock when the unit is subsequently used..............................................Alcatel-Lucent – Proprietary Alcatel-Lucent 9363 MC Use pursuant to applicable agreements 401-387-097 Issue 1 May 2011...

  • Page 15: Safety - Specific Hazards

    Open and lockout the load disconnect switch in the distribution box to completely de-energize the network element..............................................Alcatel-Lucent 9363 MC Alcatel-Lucent – Proprietary 401-387-097 Use pursuant to applicable agreements...
  • Page 16 Operating the unit when condensation moisture is present can destroy the unit. Units which show signs of condensation must be dried before installation..............................................Alcatel-Lucent – Proprietary Alcatel-Lucent 9363 MC Use pursuant to applicable agreements 401-387-097 Issue 1 May 2011...
  • Page 17 Falls can occur when working at heights resulting in serious personal injury or death. To prevent a fall when working at heights (ladder, scaffold, manlift, roof etc.) follow safe work practices and wear appropriate fall protection equipment..............................................Alcatel-Lucent 9363 MC Alcatel-Lucent – Proprietary 401-387-097 Use pursuant to applicable agreements...

  • Page 18: Product Safety

    ..............................................Alcatel-Lucent – Proprietary Alcatel-Lucent 9363 MC Use pursuant to applicable agreements 401-387-097 Issue 1 May 2011...

  • Page 19: Product Overview

    P roduct overview Overview Purpose This chapter provides an overview of the Alcatel-Lucent 9363 Metro Cell - Indoor. Contents Functional description Physical description ..............................................Alcatel-Lucent 9363 MC Alcatel-Lucent – Proprietary 401-387-097 Use pursuant to applicable agreements Issue 1 May 2011...

  • Page 20: Functional Description

    The 9360 Small Cell solution has been developed to handle the increased demand of solutions to efficiently address the residential fixed and mobile market. The Alcatel-Lucent 9363 Metro Cell - Indoor is a public area wireless access node that collapses the traditional 3G Node B and RNC functions into a single small unit.
  • Page 21 900/1800 MHz Temperature range: -5 L1 HSUPA and typically 20W to +45 bearer) Wall mounted or false ceiling installation options, vertically or horizontally ..............................................Alcatel-Lucent 9363 MC Alcatel-Lucent – Proprietary 401-387-097 Use pursuant to applicable agreements Issue 1 May 2011...
  • Page 22 Wall mounted or false ceiling installation options, vertically or horizontally Installation options The Alcatel-Lucent 9363 Metro Cell - Indoor is designed to be used indoors can be installed using the following options: • wall mounted • in a false ceiling ..............................................

  • Page 23: Physical Description

    ..............................................Physical description Product overview The Alcatel-Lucent 9363 Metro Cell - Indoor is housed in an Alcatel-Lucent generic metallic case with a pair of antenna connectors located at the top of the device for external antennas, as shown below: Figure 2-2 Alcatel-Lucent 9363 Metro Cell - Indoor (2100 MHz variant)
  • Page 24 Metro Cell - Indoor. Debug interface A number of LEDs and a reset button are hidden behind a removable cover for debugging purposes..............................................Alcatel-Lucent – Proprietary Alcatel-Lucent 9363 MC Use pursuant to applicable agreements 401-387-097 Issue 1 May 2011...
  • Page 25 Three LEDs provide status indication for: • Power • System • Phone (Device) The Alcatel-Lucent 9363 Metro Cell - Indoor 1900/850 MHz variant will have additional LEDs providing status indication for: • GPS • Second Ethernet port Additional LEDs for Ethernet connectivity status are available at the Ethernet Port.
  • Page 26 – +2dBi ceiling or +4dBi ceiling • PoE+ injector • A pair of RF jumpers (2 meters) • Spare Power Supply, 48V DC ..............................................Alcatel-Lucent – Proprietary Alcatel-Lucent 9363 MC Use pursuant to applicable agreements 401-387-097 Issue 1 May 2011...

  • Page 27: Metro Cell Installation And Commissioning

    M etro Cell installation and commissioning Overview Purpose This chapter provides the installation and commissioning procedures for the Alcatel-Lucent 9363 Metro Cell - Indoor. Contents Pre-installation information To mount the hardware to a wall or ceiling Metro Cell - Indoor cabling...

  • Page 28: Pre-Installation Information

    – 4dBi ceiling antenna • RF jumper, 2 meters • A PoE+ power injector, with user guide • Spare power supply, 48V DC ..............................................Alcatel-Lucent – Proprietary Alcatel-Lucent 9363 MC Use pursuant to applicable agreements 401-387-097 Issue 1 May 2011...
  • Page 29 • Marker, to mark wall mounting holes • Vacuum cleaner or equivalent (required for clearing debris from wall mounting holes) • Spirit level ..............................................Alcatel-Lucent 9363 MC Alcatel-Lucent – Proprietary 401-387-097 Use pursuant to applicable agreements Issue 1 May 2011...

  • Page 30: To Mount The Hardware To A Wall Or Ceiling

    To prevent a fall when working at heights (ladder, scaffold, manlift, roof etc.) follow safe work practices and wear appropriate fall protection equipment..............................................Alcatel-Lucent – Proprietary Alcatel-Lucent 9363 MC Use pursuant to applicable agreements 401-387-097 Issue 1 May 2011...
  • Page 31 Note: Depending on the wall or ceiling the device must be mounted to, different screw fixings might be needed. After site survey these mounting accessories must be procured locally..............................................Alcatel-Lucent 9363 MC Alcatel-Lucent – Proprietary 401-387-097 Use pursuant to applicable agreements...
  • Page 32 Metro Cell installation and commissioning To mount the hardware to a wall or ceiling ..............................................Device attach Device attach points points S T E P S ....................................................................................... Alcatel-Lucent – Proprietary Alcatel-Lucent 9363 MC Use pursuant to applicable agreements 401-387-097 Issue 1 May 2011...
  • Page 33 After mounting the Metro Cell - Indoor to the wall or ceiling, the cables must be connected. Continue with, “Metro Cell - Indoor cabling” (p. 3-8)..............................................Alcatel-Lucent 9363 MC Alcatel-Lucent – Proprietary 401-387-097 Use pursuant to applicable agreements Issue 1 May 2011...

  • Page 34: Metro Cell - Indoor Cabling

    Before you begin Connect the pair of omnidirectional antennas to the antenna connectors on the device. Important! Alcatel-Lucent recommends that the antenna connection nuts are torqued to between 0,7 N.m minimum and 1,1 N.m maximum in order to avoid a potential loose connection.
  • Page 35 Clean the contact surface area and use antioxidant to avoid oxidation........................................Connect the ground cable to the grounding point on the Metro Cell - Indoor..............................................Alcatel-Lucent 9363 MC Alcatel-Lucent – Proprietary 401-387-097 Use pursuant to applicable agreements Issue 1 May 2011...
  • Page 36 S T E P S ........................................Ethernet cable lengths The following diagram outlines the maximum cable length of the Metro Cell - Indoor Ethernet cable connection..............................................3-10 Alcatel-Lucent – Proprietary Alcatel-Lucent 9363 MC Use pursuant to applicable agreements 401-387-097 Issue 1 May 2011...
  • Page 37 Note: 48V PoE+ injector is not used when power is supplied via an external power adaptor........................................Plug one end of the Ethernet cable into the Ethernet connection port on the device..............................................Alcatel-Lucent 9363 MC Alcatel-Lucent – Proprietary 3-11 401-387-097 Use pursuant to applicable agreements...
  • Page 38 S T E P S ........................................A-GPS antenna cable connection (1900/850 MHz only) The Alcatel-Lucent 9363 Metro Cell - Indoor 1900/850 MHz has Assisted GPS capability for localization of the unit. 1 SMA connector is provided for the connection of an external GPS antenna.
  • Page 39 GPS antenna connector (SMA) How to continue After antenna and cable connections are completed continue with “To commission the Metro Cell - Indoor”..............................................Alcatel-Lucent 9363 MC Alcatel-Lucent – Proprietary 3-13 401-387-097 Use pursuant to applicable agreements Issue 1 May 2011...

  • Page 40: Metro Cell - Indoor Commissioning Process

    System and Phone (device) indicators will blink........................................Once the software update has completed the 9363 Metro Cell - Indoor will carry out an automatic reboot. During reboot the Power and System indicators will be on.

  • Page 41: Post Installation Activities And Checks

    Post installation activities and checks ..............................................Post installation activities and checks Connection cover attachment Once the 9363 Metro Cell Indoor is commissioned and ready for use attach the connection cover: ........................................Check all cable connections are secure and correctly routed.
  • Page 42 Inspect the site for loose tools, materials, and parts. Remove all such loose tools, materials, and parts. S T E P S ....................................................................................... 3-16 Alcatel-Lucent – Proprietary Alcatel-Lucent 9363 MC Use pursuant to applicable agreements 401-387-097 Issue 1 May 2011...

  • Page 43: Overview

    P roduct specifications Overview Purpose This chapter details the Alcatel-Lucent 9363 Metro Cell - Indoor product environmental specifications. Contents Environmental and regulatory specifications ..............................................Alcatel-Lucent 9363 MC Alcatel-Lucent – Proprietary 401-387-097 Use pursuant to applicable agreements Issue 1 May 2011...
  • Page 44 Environmental and regulatory specifications Overview The 9363 Metro Cell Indoor conforms to 3GPP Release 8, including TS 25.101, TS 25.113, TS 45.005-1 and TS 25.104 on radio transmission and reception. The solution meets the basic requirements of Directive 1999/5/EC on telecommunications terminal equipment, regarding electromagnetic interference and also safety and health.
  • Page 45 The Metro Cell Indoor tolerates Electrical Fast Transients on the AC mains, as specified in EN 61000-4-4, Test Level 3. For the 1900/850 MHz model only, all cables uses UL 758 (Appliance Wiring Material) verified materials ..............................................Alcatel-Lucent 9363 MC Alcatel-Lucent – Proprietary 401-387-097 Use pursuant to applicable agreements Issue 1 May 2011...
  • Page 46 This section details the hole spacing to be drilled when the Metro Cell - Indoor is mounted onto a wall or flat surface. Contents Wall mount spacer ..............................................Alcatel-Lucent 9363 MC Alcatel-Lucent – Proprietary 401-387-097 Use pursuant to applicable agreements Issue 1 May 2011...

  • Page 47: Wall Mount Spacer

    Wall drill position for screws (Note: Use screws suitable for a 8mm bolt hole) Max tightening torque: 3 Nm Washer (serial large) are advised ..............................................Alcatel-Lucent – Proprietary Alcatel-Lucent 9363 MC Use pursuant to applicable agreements 401-387-097 Issue 1 May 2011...
  • Page 48 Overview Purpose This section presents the product conformance statements that apply to the Alcatel-Lucent Metro Cell - Indoor equipment. The statements that are required are determined primarily by national or multinational regulations. However, in some regions, contract terms determine which statements are required.

  • Page 49: Product Conformance Statements

    Directive 1999/5/EC. The technical documentation as required by the Conformity Assessment procedure is kept at the Alcatel-Lucent location which is responsible for this product. For more information please contact your local Alcatel-Lucent Customer Service Organization. CE marking This product has been CE-marked in accordance with the following European Directives: •...
  • Page 50 Health (Article 3.1(a) of the R&TTE Directive) Antenna exposure Antenna attachment for the Alcatel-Lucent Metro Cell Access Point equipment shall be performed in accordance with all applicable manufacturer's recommendations, and national laws and regulations. To ensure correct antenna installation, the antenna installer shall perform all necessary calculations and/or field measurements to evaluate compliance with applicable national laws or regulations regarding exposure to electromagnetic fields.
  • Page 51 Product conformance statements European Union ..............................................The following information on Alcatel-Lucent supplied equipment is available from customer representatives: • Output power and antenna characteristic, if the product is equipped with an integral antenna • A detailed description of at least one typical normal configuration, including antenna system (feeders, connectors, combiners, antennas, etc.), if the product is intended to...
  • Page 52 Moreover, in compliance with legal requirements and contractual agreements, where applicable, Alcatel-Lucent will offer to provide for the collection and treatment of Alcatel-Lucent products bearing the logo at the end of their useful life, or products displaced by Alcatel-Lucent equipment offers.
  • Page 53 United States Introduction The statements that follow are the product conformance statements that apply to the Alcatel-Lucent Metro Cell Access Point equipment when deployed in the United States. Federal Communications Commission Important! Changes or modifications not expressly approved by Alcatel-Lucent, Inc.
  • Page 54 This equipment complies with Part 2, Subpart J - Equipment Authorization Procedures, of the FCC Rules. This device complies with Part 22 – Public Mobile Services, Subpart H – Cellular Radiotelephone Services..............................................Alcatel-Lucent 9363 MC Alcatel-Lucent – Proprietary 401-387-097 Use pursuant to applicable agreements Issue 1 May 2011...
  • Page 55 This equipment complies with Part 90 – Private Land Mobile Radio Services. Product safety conformance The Alcatel-Lucent Metro Cell Access Point equipment is Safety Certified ITE by CSA International. This Certification is marked on the equipment main nameplate label. Should the local...
  • Page 56 Alcatel-Lucent Environment, Health and Safety organization or Alcatel-Lucent Hazardous Waste Center technical support at (888) 539-2783. Material content compliance The following notification applies to Alcatel-Lucent products distributed for sale, resale, or use. This product, part, or both may include a lithium-manganese dioxide battery, which contains very small amounts of a perchlorate substance.
  • Page 57 A protocol that determines how devices will share resources on a local area network. Mbps Megabits per second ..............................................NEMA National Electrical Manufacturers Association..............................................Alcatel-Lucent 9363 MC Alcatel-Lucent – Proprietary GL-1 401-387-097 Use pursuant to applicable agreements Issue 1 May 2011...
  • Page 58 ..............................................Radio Network Controller RoHS Restriction of Hazardous Substances Directive ..............................................Uniform Building Code ..............................................WEEE Waste Electrical and Electronic Equipment Directive ..............................................GL-2 Alcatel-Lucent – Proprietary Alcatel-Lucent 9363 MC Use pursuant to applicable agreements 401-387-097 Issue 1 May 2011...
  • Page 59 Metro Cell - Indoor, EMC, .......................... environmental operating physical data conditions, Installation options Metro Cell - Indoor, health, Metro Cell - Indoor, ..............................................Alcatel-Lucent 9363 MC Alcatel-Lucent – Proprietary IN-1 401-387-097 Use pursuant to applicable agreements Issue 1 May 2011...
  • Page 60 Index ..............................................safety, surge immunity, ............. tools Metro Cell - Indoor, ..............................................IN-2 Alcatel-Lucent – Proprietary Alcatel-Lucent 9363 MC Use pursuant to applicable agreements 401-387-097 Issue 1 May 2011...
