SDP PREAMP
SDEC-4500P
SDA8300 #1
Configuration
SDA4600 #1
Configuration
Standard System [i.e., Syn-2-Array / Syn-3-Array / Syn-4 / or Similar]
Typical STANDARD system configuration. Factory Defaults. DO NOT
INSERT THE CONFIGURATION JUMPERS. Standard systems support 7.4
with the option to active bi-amplify the Center Channel.
3 |
J B L S y n t h e s i s S D A 8 3 0 0 / S D A 4 6 0 0 S y s t e m G u i d e
Expanded Systems [i.e., Syn-Everest / Syn-K2 / Syn-Atlas / Syn-1-Array]
Fully expanded system using Configuration 2 and Configuration 3 for 13.4
Channel system. Front Left-Center-Right have the option to be bi-wired or
actively bi-amplified.
SDP PREAMP
SDEC-4500P
SDA8300 #1
Configuration 2
SDA8300 #2
Configuration 3
SDA4600 #1
Configuration 2
SDA4600 #2
Configuration 3
