Video Watch with FullHD Camera TX-93
8GB Watch for video recordings with sound
The Declaration of Conformity for this device is under the Internet link:
www.technaxx.de/ (in bottom bar "Konformitätserklärung"). Before using the
device the first time, please read the user manual carefully.
This device has a rechargeable battery. It must be fully charged before
first use. NOTE: Charge the battery of the device every 2–3 month if it is
Service phone No. for technical support: 01805 012643 (14 cent/minute from
German fixed-line and 42 cent/minute from mobile networks).
Keep this user manual for future reference or product sharing carefully. Do the
same with the original accessories for this product. In case of warranty, please
contact the dealer or the store where you bought this product.
Features
Video watch with integrated 2MP FullHD camera and microphone
Inconspicuous camera lens in the dial
Video resolution 1920x1080 with sound
Separate sound recording (WAV)
WEB cam function
8GB flash memory
4x IR LED for night vision ~1m
Protection class IP65 (dust proof & water jet proof)
Easy transfer via USB cable to a PC
Plug & Play device
®
Technaxx
not used!
Free Email: support@technaxx.de
Warranty 2 years
* User Manual
Advertisement
Related Manuals for Technaxx TX-93
Summary of Contents for Technaxx TX-93
- Page 1 8GB Watch for video recordings with sound The Declaration of Conformity for this device is under the Internet link: www.technaxx.de/ (in bottom bar “Konformitätserklärung”). Before using the device the first time, please read the user manual carefully. This device has a rechargeable battery. It must be fully charged before first use.
-
Page 2: Technical Specifications
Working temperature –5°C up to 50°C Weight / Dimensions 83g / Dial (L) 5.5 x (W) 5.2 x (H) 1.8cm Package Video Watch with FullHD Camera TX-93, USB charging cable with contents 2.5mm jack, Replacement knob for microphone, CD, User Manual... - Page 3 Charging Status & Low Battery Status This watch has a built-in rechargeable (but not replaceable) Lithium ion battery which can be charged by connecting the USB interface of the watch with computer USB interface or an adapter** (**not included). 1. Charging: remove the knob (7) by screwing it apart and then insert the 2.5mm jack of the USB charging cable* (*included) to the watch.
- Page 4 Operation Modes 1. Turning camera ON Press and hold the Power/Video button (1) for two seconds. The BLUE LED lights up turns OFF and turns ON again. The BLUE LED is steady ON now (it indicates power on and standby time mode). 2.
- Page 5 6. Reset If the watch is not operating properly, press the Power/Video button (1) and the Voice record button (8) at the same time to reset it. Installation of the WEB camera driver 1. If the WEB cam functions does not work, install the driver. Copy the file onto your computer.
- Page 6 4. Disconnect the watch (USB watch) from the PC a. Right mouse click on the Windows interface "Safely Remove Hardware" icon (lower right corner on green arrow). b. Select "Stop" in "Safely Remove Hardware" dialog box. c. Choose the watch you want to disconnect, click "OK", watch quit safely. "Safely Remove Hardware"...
- Page 7 Cleaning: Protect the device from contamination and pollution (use a clean drapery). Avoid using rough, coarse-grained materials or solvents/aggressive cleaner. Wipe the cleaned device accurately. Distributor: Technaxx Deutschland GmbH & Co.KG, Kruppstr. 105, 60388 Frankfurt a.M., Germany...
