Technaxx
The Declaration of Conformity for this device is under the Internet link: www.technaxx.de/ (in bottom bar
"Konformitätserklärung"). Before using the device the first time, read the user manual carefully.
Service phone No. for technical support: 01805 012643 (14 cent/minute from German fixed-line and 42
cent/minute from mobile networks). Free Email: support@technaxx.de

1. Charging

1.1. Charging the built-in Lithium battery either by connecting the USB interface of the watch with
the USB port of a computer/notebook or with the AC adapter.
1.2. If the watch is connected, the red LED lights up briefly.
1.3. During charging, the red LED lights constantly and the blue LED flashes. [Therefore both
LEDs are located next to each other, it looks for the viewer as if a violet LED flashes. However,
this is a colour mix only.]
1.4. When the watch is fully charged after approx. 2 – 2,5 hours, the red LED and blue LED are
lighting constantly. [Therefore both LEDs are located next to each other, it looks for the viewer as
if a violet LED flashes. However, this is a colour mix only.]

2. Low battery power

If the battery power is too low while recording a video or taking pictures, the blue LED flashes
quickly. Before the camera turns off automatically, the files will be saved.

3. Buttons

4. Turning ON the camera

Press and hold down the Power/Video button for 2 seconds. The red LED lights up briefly. Then
the red LED turns off while the blue LED is lighting. That indicates power on and standby mode
of the watch.
Video Watch Actionmaster 8GB

User Manual

1
2
3
4
5
6
7
Power
Press and hold down the button to
button
turn on / to turn off
Video button
Press shortly the button to take a
video
Photo button Press shortly the button to take a
USB interface
Camera lens
Microphone
LED indicator (small window)
Time setting

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TXX3233 and is the answer not in the manual?

Questions and answers

Summary of Contents for Technaxx TXX3233

  • Page 1: User Manual

    Technaxx User Manual The Declaration of Conformity for this device is under the Internet link: www.technaxx.de/ (in bottom bar “Konformitätserklärung”). Before using the device the first time, read the user manual carefully. Service phone No. for technical support: 01805 012643 (14 cent/minute from German fixed-line and 42 cent/minute from mobile networks).
  • Page 2 5. Turning OFF the camera In the standby/video mode press and hold down the Power/Video button. The red LED flashes for 3 times and then turns off. When the watch is not used 3 minutes after powered on, it will power off automatically.
  • Page 3: Technical Specifications

    (use a clean drapery). Avoid using rough, coarse-grained materials/solvents/other aggressive cleaner. Wipe the cleaned device. Important Notice: Should battery fluid leak from a battery, wipe the battery-case with a soft cloth dry. Distributor: Technaxx Deutschland GmbH & Co.KG, Kruppstr. 105, 60388 Frankfurt a.M., Germany...
