with body temperature measurement
The manufacturer Technaxx Deutschland GmbH & Co.KG hereby declares that
this device, to which this user manual belongs, complies with the essential
requirements of the standards referred to the Directive RED 2014/53/EU. The
Declaration of Conformity you find here: www.technaxx.de/ (in bar at the bottom
"Konformitätserklärung"). Before using the device the first time, read the user
manual carefully.
Service phone No. for technical support: 01805 012643 (14 cent/minute from
German fixed-line and 42 cent/minute from mobile networks). Free Email:
The support hotline is available Mon-Fri from 9 am to 1 pm & 2 pm to 5 pm
This device has a rechargeable battery. It must be fully charged before first
use. NOTE: Charge the battery of the device every 2–3 month if it is not
Keep this user manual for future reference or product sharing carefully. Do the
same with the original accessories for this product. In case of warranty, please
contact the dealer or the store where you bought this product.
Enjoy your product * Share your experience and opinion on one of the
Features
⚫ Smartwatch to monitor your body temperature, Blood oxygen, sport
activities, heart rate, your fitness and your sleep activities
⚫ Displays heart rate, steps, distances, burned calories, sleep time,
time & date
⚫ Notification reminder: calls, SMS, WhatsApp, social media, achieved
goals, activity reminder, drink reminder
⚫ Full touch display 1.69" (4.3cm)
⚫ Free FunHealth APP in Google Play Store and Apple AppStore
⚫ Anti-lost function: find your mobile phone or the Smartwatch
⚫ IP67 Waterproof
⚫ 5-7 working days
⚫ Wake up screen by turning your wrist
⚫ Connection to Apple Health and Google Fit
®
Technaxx
TX-SW7HR Smartwatch
support@technaxx.de
Warranty 2 years
well-known internet portals.
* User Manual
used!
1
Advertisement
Table of Contents
Related Manuals for Technaxx TX-SW7HR
Summary of Contents for Technaxx TX-SW7HR
- Page 1 Directive RED 2014/53/EU. The Declaration of Conformity you find here: www.technaxx.de/ (in bar at the bottom “Konformitätserklärung”). Before using the device the first time, read the user manual carefully.
-
Page 2: Technical Specifications
Weight / Dimensions min. wrist size: 15cm max. wrist size: 21cm Storage temperature / Operation temperature –10°C up to 45°C Technaxx ® Smartwatch TX-SW7HR, charging Package Contents cable, user manual Charging Plug the magnetic USB charger in a USB-port with power source... -
Page 3: Product Overview
Product overview 1 Display Thermometer sensor 2 Button Charging pins 3 Heart rate sensor NOTE: The device should be charged at least 1 hour before use. Start up Connect the Smartwatch with the magnet charger or press down the button (2) for 3 seconds. Install FunHealth APP on your smart phone Search for the "FunHealth"... - Page 4 3. Scan the QR code on your watch. Info: You can hide the QR code by tapping the display 5 times. Do not now where to find it? Go to the point QR-Code in the manual below. 4. Now the Smartwatch is connected with your Smartphone and the APP.
- Page 5 today, the current measured body temperature and the blood oxygen. Info: During the measurement, the app must be synchronized to display body temperature and blood oxygen in the app. Watch interface ⚫ Incoming call notification: Enable/disable to get a notification of a call on your watch. You even can decline the call on your watch.
- Page 6 Start using When the Smart watch is connected to the APP successfully, it will synchronize the time, the date and the language. It counts steps, distance and calories automatically. Press the button to activate the LCD screen. → Swipe up on the start screen to see the main settings. Like: Do not disturb mode (moon), change brightness (sun), lock your screen (lock), go to the settings (gear) and find your phone (phone).
-
Page 7: Heart Rate
Health Swipe left from the start screen. Tap this icon to enter this option. Now you can choose between Heart rate, Blood oxygen and Body temperature measurement. - Heart rate Tap this icon to measure your heart rate now. You will see your current heart rate and a rating like “Comfortable”. -
Page 8: Find Phone
Notifications Short way: Swipe down from the start screen. Long way: Swipe left from the start screen and then down, until you see this icon. Tap this icon to enter this option. Here you can see the notifications. Alarm Swipe left from the start screen and then down, until you see this icon. - Page 9 Stopwatch Swipe left from the start screen and then down twice, until you see this icon. Tap this icon to enter this option. Press play button to begin. Press the round arrow for a lap time. To zero the stopwatch press the pause and round arrow button. Swipe left before pressing round arrow button for reset to see the lap counter and every single laptime.
-
Page 10: Safety Instructions
Safety instructions ⚫ Rebuilding or modifying the product impairs product safety. ⚫ All modifications and repairs of the device or accessories must be performed by the manufacturer or by persons expressly authorized by the manufacturer. ⚫ Never open the product by yourself or perform repairs by yourself! ⚫... - Page 11 Products marked with this symbol meet all applicable community regulations of the European Economic Area. Technaxx Deutschland GmbH & Co KG has issued a "declaration of conformity" in accordance with the applicable directives and relevant standards. has been created. This can be viewed at any time upon request.
