    Conference Microphone Speaker User's Manual...

  • Page 2

    IMPORTANT SAFETY INSTRUCTIONS Power Sources – This product should be operated only from the type of power source indicated on the mark. CAUTION Grounding or Polarization – This product may be equipped with a polarized alternating current line plug (a plug having RISK OF ELECTRIC SHOCK one blade wider than the other).

  • Page 3

    “ON”, please try to eliminate the problem by using requirements. Modifications not expressly approved by one of the following measures; Yamaha may void your authority, granted by the FCC, to use the product. Relocate either the product generating the interference 2 IMPORTANT: When connecting this product to or the device that is being affected by the interference.

  • Page 4

    Yamaha will not Avoid installing this unit where foreign object may fall onto this...

  • Page 5: Table Of Contents

    Accepting an incoming call............11 Rejecting an incoming call .............11 Listening to Music (Speaker Mode)........12 Using the PJP-25URS Controller ...........13 Basic operations of the PJP-25URS Controller......13 About the "PJP-25URS Controller" screen ......14 Switching the USB bandwidth usage ........15 Switching the operation mode..........15 Uninstalling the PJP-25URS Controller.........15...

  • Page 6: Introduction

    Introduction Thank you for purchasing Yamaha PJP-25URS. This product is a USB microphone/speaker unit to be connected to a PC with the USB cable for use as its audio terminal. Before operating this unit, please read this manual carefully. ■Communication You can use this unit as a microphone speaker for Skype.

  • Page 7: Confirmation Software License Agreement

    1-1 herein, into the PRODUCT or personal computer owned by you. 1. GRANT OF LICENSE: 1-1. YAMAHA grants you a personal non-exclusive license to install the SOFTWARE and use the SOFTWARE on the PRODUCT or other devices, including but not limited to the personal computer, which you own.

  • Page 8

    Government End Users shall acquire the Software with only those rights set forth herein. 9. ACKNOWLEDGMENT: You agree that this AGREEMENT is the complete and exclusive statement of agreement between you and YAMAHA concerning the subject matter hereof and supersedes all proposals or prior agreements, verbal or written, and any other communications between you and the parties relating to the subject matter hereof.

  • Page 9: Controls And Functions

    Press to reject or end a Skype call. Connect the AC adapter (sold separately). Note Note This key does not work unless the PJP-25URS Controller is installed. This connection is not required when a USB connection is used. 4 Off-hook 9 AUDIO OUT jack Press to make or accept a Skype call.

  • Page 10

    ■Other 1 Label 2 Tripod socket Provides the following information. Use to connect a commercially available tripod. • MODEL No.: Model number of this unit • SER.: Serial number of this unit ■Functions of the LEDs 1 Microphone LEDs 3 Information LED •...

  • Page 11: Communication (mic & Speaker Mode)

    Skype Press (on-hook). from the PJP-25URS Controller. To use this unit with Skype, The call ends. permit access from the PJP-25URS Controller on Skype. • In case this unit's microphones do not pick up any sounds or if...

  • Page 12: Listening To Music (speaker Mode)

    Listening to Music (Speaker Mode) Connect this unit to the PC using the supplied USB cable. On PJP-25URS Controller, set the operation mode of this unit to the "Speaker" mode. Now you can use this unit as a speaker. If you want to use this unit as a stereo speaker, set "USB bandwidth...

  • Page 13: Using The Pjp-25urs Controller

    Using the PJP-25URS Controller By using the PJP-25URS Controller, you can adjust the unit's settings which cannot be controlled with key operations. Basic operations of the PJP-25URS To quit the PJP-25URS Controller Controller Follow the procedure below to quit the PJP-25URS Controller.

  • Page 14: About The "pjp-25urs Controller" Screen

    About the "PJP-25URS Controller" screen "Home" screen "Detail" screen To switch between "Home" and "Detail" screens, click ■ Items in the "Home" screen 5 Shows the electrical power which this unit can use for audio output. 1 Turn off (mute) the microphones of this unit Level 3 (lights in green): normal temporarily.

  • Page 15: Switching The Usb Bandwidth Usage

    • The reset operation will change all the settings to the default Controller value (if available). • You cannot restore the settings to the previous status after the To uninstall the PJP-25URS Controller from the PC, select reset operation. [Start] - [All Programs] - [Yamaha PJP-25URS] - [Uninstall PJP-25URS Controller].

  • Page 16: Using The Latest Features

    Check the latest firmware version and then repairs. click "OK". The firmware update starts. In the "PJP-25URS Controller" screen, click "Home". To specify the firmware download URL This feature is useful in managing the firmware versions Click "Firmware update".

  • Page 17: Updating The Firmware Using A Local File

    Checking the firmware release local file note If the PC connecting to the PJP-25URS cannot be You can check the firmware release note by clicking connected to the Internet, follow the procedure below to "Release note" in the "PJP-25URS Firmware update"...

  • Page 18: Checking The Connection

    • "Speakers": Yamaha PJP-25URS • "Ringing": Yamaha PJP-25URS Check Normally, "Yamaha PJP-25URS" is automatically selected Check when this unit is connected to the PC. If "Yamaha PJP- 25URS" is not selected, select it manually. Check Click the "Voice" tab. Click...

  • Page 19

    "Default device" in "Voice playback": Yamaha PJP-25URS Check Normally, "Yamaha PJP-25URS" is automatically selected when this unit is connected to the PC. If "Yamaha PJP- 25URS" is not selected, select it manually. Click "OK" to close the "Sounds and Audio Devices Properties" screen.

  • Page 20: Troubleshooting

    Select this unit in the Audio settings of Skype. There is a problem with the equipment – configuration on another unit. In the PJP-25URS Controller, "Environment" is Set "Environment" to "Conference room" in the set to "Standard". PJP-25URS Controller. The unit generates noises.

  • Page 21: Q2: Have A Playback Problem

    Q2: Have a playback problem Problem Cause Remedy The audio is interrupted. Because the speaker volume is too high, the Turn the speaker volume down. speaker mute function is automatically turned on for system protection. This unit does not output This unit is not selected in the Audio device Select this unit.

  • Page 22: Support Information

    Support Information Please visit the following website for the latest or detailed information. ■ PJP-25URS support website http://www.yamaha.co.jp/english/product/projectphone/products/25urs/...

  • Page 23: Specifications

    Specifications General Audio Interface: Arrayed microphones: USB 2.0 (full speed), Analog I/O (stereo-mini), 4 units x 3 lines AC adapter (DC 5V IN) Speaker: Power consumption (max): 2 units, monaural output, stereo output (when using the USB bus power: 2.5 W or less, Self power: 3.0 W or less speaker only) Radio interference standard: Frequency bandwidth for sound pickup:...
