IMPORTANT SAFETY INSTRUCTIONS 13 Object and Liquid Entry – Never push objects of any kind into this product through openings as they may touch dangerous voltage points or short-out parts that could result in a fire or electric shock. CAUTION Never spill liquid of any kind on the product.
Page 4
FCC requirements. found to be the source of interference, which can be determined Modifications not expressly approved by Yamaha may void your by turning the unit “OFF” and “ON”, please try to eliminate the authority, granted by the FCC, to use the product.
Page 5
15 Do not clean this unit with chemical solvents; this might damage the finish. Use a clean, dry cloth. 16 Do not attempt to modify or fix this unit. Contact qualified Yamaha service personnel when any service is needed. 17 Condensation will form when the surrounding temperature changes suddenly.
Yamaha conference systems home page. ■ Using the Latest Features You can download the firmware (program to control the functions of this unit) to use the latest features. For details, please visit the Yamaha conference systems home page. Yamaha conference systems home page http://www.yamaha.co.jp/english/product/projectphone/...
• Specifications of this unit and contents of this document are subject to change without notice. • Yamaha does not accept any liability for any loss or damage resulting from any use of this unit. The warranty covers a repair of this unit only.
1-3. You shall not modify, remove or delete a copyright notice of YAMAHA contained in the SOFTWARE. 1-4. Except as expressly provided herein, no license or right, express or implied, is hereby conveyed or granted by YAMAHA to you for any intel- lectual property of YAMAHA.
Controls and Functions 1 LEDs 6 Speaker mute Light to indicate the status of this unit. Press to temporarily turn off (mute) the speakers. To cancel the mute function, press it 2 Microphones again. Pick up the talker's voice. 7 FUNC. 3 Speakers For future expansion.
Page 10
■ Functions of the LEDs Microphone LEDs Information LED Normal: 124 light up Microphone muted: 124 blink Waiting for firmware update: All blink During firmware update: 13 and 24 blink alternately Firmware update error: Off Speaker LED Normal: Off Waiting for firmware update: Blinks in red During firmware update: Off Firmware update error: Blinks in red Normal: Lights up...
Using this unit with Windows System Requirements Connection Use a PC that meets the following requirements. • OS: Windows 7 (32bit), Connect this unit to the PC Windows Vista SP1 or later (32bit), using the supplied USB cable. Windows XP SP2 or later (32bit), Windows 2000 SP4 (32bit) •...
Normally, "Yamaha PJP-10UR" is automatically Click the "start" menu and click selected when this unit is connected to the PC. If "Yamaha PJP-10UR" is not selected, select it "Control Panel". manually. Click "Sounds, Speech and Click the "Voice" tab.
Page 13
Normally, "Yamaha PJP-10UR" is automatically selected when this unit is connected to the PC. If set when this unit is connected to the PC. If "Yamaha PJP-10UR" is not selected, select it "Yamaha PJP-10UR" is not selected, select it manually.
Click the "Audio" tab and click "Volume" in "Sound recording". Normally, "Yamaha PJP-10UR" is automatically set when this unit is connected to the PC. If "Yamaha PJP-10UR" is not selected, select it manually. Click "OK" to close the "Sound" screen.
Page 15
■ When using Windows 7/ Adjust the microphone Windows Vista sensitivity in the "Microphone". Click the "Start" menu and click "Control Panel" - "Hardware and Sound" - "Sound". The "Sound" screen appears. Click the "Recording" tab. Select this unit and click "Properties".
Using this unit with Mac System Requirements • You do not need to install the USB driver separately because this unit is recognized as a Use a Mac that meets the following basic audio device by the Mac. requirements. • The microphones of this unit pick up audio •...
Page 17
Adjusting the microphone Select "Yamaha PJP-10UR" from sensitivity the device list. Click the Apple menu and select "System Preferences" - "Sound" - "Input" tab. Select Adjust the microphone sensitivity in the "Input volume". Click the "Input" tab. Click Select "Yamaha PJP-10UR" from the device list.
Troubleshooting Refer to the following tables when this unit does not function properly. If the problem you are experiencing is not listed or the instruction does not solve, please contact the retailer or dealer who you purchased the product from. Q1: LED indicator does not light up Problem Cause...
Support Information Please visit the Yamaha conference systems home page. ■ Yamaha conference systems home page http://www.yamaha.co.jp/english/product/projectphone/ English 19...
Specifications General Audio Interface: Microphones: USB2.0 Full Speed 4 units (Array microphone) Power consumption (max): Speakers: Approx. 2.5W 2 units Radio interference standard: Frequency bandwidth for sound pickup: FCC Part 15 (US) 300 to 7,000 Hz EN55022 (EU) Frequency bandwidth for playback: Operating environment: 300 to 20,000 Hz Temperature: 0 to 40°C (32 to 104°F)
Page 43
关于本手册 ■ 关于缩写词 在本手册中,产品名称的表述如下: • Yamaha PJP-10UR:本设备 ® ® • Microsoft Windows : Windows ® ® • Microsoft Windows 7: Windows 7 ® ® • Microsoft Windows Vista : Windows Vista ® ® • Microsoft Windows XP : Windows XP ®...
Page 44
1-3. You shall not modify, remove or delete a copyright notice of YAMAHA contained in the SOFTWARE. 1-4. Except as expressly provided herein, no license or right, express or implied, is hereby conveyed or granted by YAMAHA to you for any intellectual property of YAMAHA.
Page 56
规格一览表 一般资料 音频 接口: 麦克风: USB2.0 全速接口 4 个 (阵列麦克风) 功耗 (最大) : 扬声器: 约 2.5W 2 个 运行环境: 收音的频带宽度: 温度:0 至 40 ℃ 300 至 7,000 Hz 湿度:20 至 85% (无冷凝) 播放的频带宽度: 尺寸: 300 至 20,000 Hz 主体 (W x H x D):49 x 121 x 38 mm 信号处理:...
Page 57
니다 . 깨끗한 마른 천을 사용하십시오 . 16 본 장치를 개조하거나 수리하지 마십시오. 서비스가 필요할 경우 Yamaha 의 전문 서비스 기사에게 문의하십시오 . 17 주변 온도가 갑작스럽게 변할 경우 응결이 발생될 수 있습니 다 . PC 에서 USB 케이블을 분리 후 그대로 방치하십시오 .
Page 58
PJP-10UR ( 본체 ) x 1, USB 케이블 (1.2 m) x 1, 캐링 케이스 x 1, 본 책자 x 1 ■ 최신 정보 확인 본 책자의 설명은 현재 (2009 년 11 월 ) 의 최신 펌웨어를 기반으로 한 것입니다 . 최신 정보는 Yamaha 회의 시스템 홈페이지를 참 조하십시오 . ■...
Page 59
• Yamaha 의 허가 없이는 본 문서를 복사하거나 사용할 수 없습니다 . • 본 장치 사양 및 매뉴얼의 내용은 통지 없이 변경될 수 있습니다 . • Yamaha 는 본 장치 사용으로 인한 어떠한 손실 혹은 파손에 대해서도 법적 책임을 지지 않습니다 . 보증서는 본 장치의 수리에 한 하여 보장합니다 .
Page 60
1-3. You shall not modify, remove or delete a copyright notice of YAMAHA contained in the SOFTWARE. 1-4. Except as expressly provided herein, no license or right, express or implied, is hereby conveyed or granted by YAMAHA to you for any intellectual property of YAMAHA.
Page 61
제어장치 및 기능 1 LED 6 스피커 음소거 본 장치의 상태를 나타내는 표시등 . 일시적으로 스피커를 끌 때 ( 음소거 ) 누릅 니다 . 음소거 기능을 취소하려면 다시 한번 2 마이크 누릅니다 . 화자의 음성을 포착합니다 . 7 FUNC. 3 스피커 향후...
Page 62
■ LED 의 기능 마이크 LED 정보 LED 보통상태 : 124 점등 마이크 음소거 : 124 점멸 펌웨어 업데이트 대기 중 : 모두 점멸 펌웨어 업데이트 중 : 13 · 24 교대로 점멸 펌웨어 업데이트 오류 : 꺼짐 스피커 LED 보통상태...
Page 63
본체를 Windows 와 함께 사용하기 시스템 사양 접속 다음 요건을 충족하는 PC 를 사용하십시오 . • OS: Windows 7 (32 비트 ), 함께 제공된 USB 케이블을 사용하 Windows Vista SP1 이상 (32 비트 ), 여 PC 에 본 장치를 연결하십시오 . Windows XP SP2 이상...
Page 64
보통 본 장치가 PC에 연결되어 있을 때에는 "Yamaha PJP-10UR" 가 자동으로 선택됩 " 시작 " 메뉴를 클릭하고 " 제어판 " 니다 . "Yamaha PJP-10UR" 가 선택되어 있지 않은 경우에는 직접 선택하십시오 . 을 클릭하십시오 . " 음성 " 탭을 클릭하십시오 .
Page 65
보통 본 장치가 PC에 연결되어 있을 때에는 "Yamaha PJP-10UR" 가 자동으로 선택됩 "Yamaha PJP-10UR" 가 자동으로 설정되 니다 . "Yamaha PJP-10UR" 가 선택되어 어 있습니다 ."Yamaha PJP-10UR" 가 선택 있지 않은 경우에는 직접 선택하십시오 . 되어 있지 않은 경우에는 직접 선택하십시...
Page 66
" 의 " 볼륨 " 을 클릭하십시오 . 보통 본 장치가 PC에 연결되어 있을 때에는 "Yamaha PJP-10UR" 가 자동으로 설정되 어 있습니다 ."Yamaha PJP-10UR" 가 선택 되어 있지 않은 경우에는 직접 선택하십시 오 . " 확인 " 을 클릭하여 " 소리 " 화면을...
Page 67
■ Windows 7/Windows Vista 를 "Microphone" 에서 마이크 감도를 사용하는 경우 조절하십시오 . "시작" 메뉴를 클릭하고 "제어판" - " 하드웨어 및 소리 " - " 소리 " 를 클릭하십시오 . " 소리 " 화면이 나타납니다 . " 녹음 " 탭을 클릭하십시오 . 본...
Page 68
본체를 Mac 과 함께 사용하기 시스템 사양 • 본 제품은 Mac 에서 기본 오디오 장치로 인식하므로 USB 드라이버를 별도로 설치 다음 사양의 Mac 을 사용하십시오 . 할 필요는 없습니다 . • OS: Mac OS 10.5 (Leopard) • 본 기기의 마이크로폰들은 주로 스피커 방 •...
Page 69
마이크 감도 조절하기 장비 목록에서 "Yamaha PJP- 10UR" 을 선택하십시오 . Apple 메뉴를 클릭하고 " 시스템 환 경설정 " - " 사운드 " - " 입력 " 탭 을 선택하십시오 . "입력 음량 " 에서 마이크 감도를 조 절하십시오 .
