Control Products BD-5000 Instruction Manual

B a s i c A l a r m B D - 5 0 0 0
Thank you for purchasing the Basic Alarm BD-5000. If you should ever have
any questions or concerns about this product, feel free to contact us. Our phone
number, web sites and email addresses are listed at the back of this instruction
manual.
GENERAL DESCRIPTION
The Basic Alarm BD-5000 is designed to alert you by telephone if the alarm
contacts are opened or closed. The BD-5000 has a two conductor wire that can
be connected to any device that has a dry contact that will either close or open.
The BD-5000 can call one phone number if the contact is either closed or
opened.
FEATURES
•
Automatically dials to one telephone number when the alarm contact is
either closed or opened by an external alarm device. The BD-5000 can call
any telephone number including a cell phone, calling card number, or
international number.
•
Plays a pre-recorded voice alarm message in English. The message is:
"This is your remote monitoring system. There is an alarm
condition at your remote monitored location. Please check
conditions at your monitored location."
The BD-5000 will repeat the message for a full minute, allowing it to be
recorded on an answering machine or voice mail if desired.
•
The BD-5000 continues to call your programmed telephone number until
the alarm call out is canceled by calling back to the BD-5000 from any
phone in the world.
•
Enter and change the "call-to" telephone number easily. Special memory
keeps the phone number stored forever even if the battery goes dead or is
removed.
•
Call-to telephone number can be up to 40 digits long including the "*" key
if required.
•
Dialing indicator light
•
Operates on Touch Tone™ telephone lines only.
•
FCC Approved
Control Products offers a full line of alarm devices for temperature, humidity,
moisture/water detection and motion detection to connect to the BD-5000.
Contact Customer Service at 800-880-6000 for information on any of these
products.
M o d e l B D - 5 0 0 0
1
TABLE OF CONTENTS:
General Description & Features.....................................................................1
Installation & Programming ..........................................................................2
Programming and Changing the "Call-To" phone number.......................4
Extending The Phone Wire And Contact Wire .............................................6
Testing Your Bd-5000...................................................................................6
Operation
During An Alarm .....................................................................................6
Canceling The Alarm Call-Out ................................................................7
Resetting Your Bd-5000.........................................................................7
Use With Answering Machines And Voice Mail.......................................7
Troubleshooting............................................................................................9
Commonly Asked Questions .........................................................................9
Specifications .............................................................................................10
Fcc Statement............................................................................................10
Contacting Information and Technical Support ............................................11
Warranty And Return Information................................................................11
INSTALLATION & PROGRAMMING
IMPORTANT
•
Read the warranty information on page 14 and the FCC statement on page
13 before using this product.
•
The performance of local and long distance telephone lines vary from
location to location and may affect operation of the BD-5000. Therefore, it
is important that the BD-5000 be fully tested after installation to confirm
telephone compatibility. Please see the Testing your BD-5000 on page 6
for further instructions.
•
Caution - To ensure proper operation, this equipment must be installed
according to the enclosed installation instructions. To verify that the
equipment is operating properly and can successfully report an alarm, this
equipment must be tested immediately after installation, and periodically
thereafter, according to the enclosed test instructions.
•
Caution – This equipment cannot report an alarm when other equipment
(telephone, answering system, computer modem, etc.) connected to the
same phone line is in use.
•
Important – Do not program emergency phone numbers for the police, fire
or other emergency personnel or departments unless you have specific
approval from such agencies. The BD-5000 does not identify the location
that is calling and therefore cannot provide an audible notification of what
address this phone call originated from.
A. What You Will Need:
1. One 9-volt alkaline or lithium battery (not included).
2. Phillips screwdriver (not included)
2
