  • Page 1 Eris Series E3.5 ™ High-Definition Near Field Studio Monitors Owner’s Manual ® English www.presonus.com...
  • Page 2: Table Of Contents

    Overview — 1 Hookup Diagram — 7 2.3. 1.1. Introduction — 1 Tutorials — 8 1.2. Summary of Eris E3.5 Features — 2 Monitor Placement — 8 1.3. What’s in the Box — 3 Level Setting — 9 Hookup — 4 Equalizer Setting Suggestions —...
  • Page 3: Overview

    Eris E3.5 studio monitors! ABOUT THIS MANUAL: We suggest that you use this manual to familiarize yourself with the features, applications, and connection procedures for your Eris E3.5 monitors before...
  • Page 4: Summary Of Eris E3.5

    Overview Eris™ Series E3.5 1.2. Summary of Eris E3.5 Features Owner’s Manual 1.2. Summary of Eris E3.5 Features • 1” (22 mm) silk-dome tweeter • 3.5” Woven composite woofer • Peak SPL: 100 dB • Frequency response: 80 Hz to 20 kHz •...
  • Page 5: What's In The Box

    1.3. What’s in the Box Owner’s Manual 1.3. What’s in the Box In addition to this manual, your Eris E3.5 package contains the following: • (1) PreSonus Eris E3.5 active studio monitor • (1) PreSonus Eris E3.5 passive studio monitor •...
  • Page 6: Hookup

    Hookup 2.1. Rear Panel Connections and Controls Each Eris E3.5 pair consists of one active E3.5 and one passive E3.5. Nearly every connection is located exclusively on the active speaker. This speaker provides signal and power for the passive speaker. The exceptions are the bare-wire connectors, which send power and signal from the active speaker to the passive speaker.
  • Page 7: Power (Active Speaker)

    2.1.3. Acoustic Tuning Controls (Active Speaker) High. Boosts or cuts all frequencies above 10 kHz by ±6 dB. Power User Tip: The High control on the Eris E3.5 is a high-shelf EQ and attenuates or boosts frequencies above 10 kHz. This EQ is much like the treble control on a car stereo: It raises or lowers the gain on all frequencies above the specified cutoff frequency.
  • Page 8: 2.1.4. Speaker Connections

    Hookup Eris™ Series E3.5 2.2. Active Speaker Front Panel Owner’s Manual 2.1.4. Speaker connections E3.5 Active Speaker E3.5 Passive Speaker Bare-wire connectors. This connection is used to power and send signal to the passive E3.5. Be sure to connect the positive and negative connections on your active E3.5 to the positive and negative connections, respectively, on the passive E3.5 (i.e.
  • Page 9: Hookup Diagram

    Hookup Eris™ Series E3.5 2.3. Hookup Diagram Owner’s Manual 2.3. Hookup Diagram USB 2.0 PHONES MIDI MAIN OUT AudioBox 22VSL Eris E3.5 Active Eris E3.5 Passive...
  • Page 10: Tutorials

    Tutorials Eris™ Series E3.5 Monitor Placement Owner’s Manual Tutorials Monitor Placement Ideally, near-field monitors should be placed so that the tweeters are at the same height as your ears when you are mixing. Eris speakers can be placed vertically or horizontally; when placed horizontally, they should form a mirror- image pair, with the tweeters on the outside.
  • Page 11: Level Setting

    Equalizer Setting Suggestions The Eris E3.5 provides both a high shelf and a low shelf EQ. In general, setting the High control to 0 (no boost or cut) will produce the best results. However, if the sound is too bright or shrill, try turning this control down below 0;...
  • Page 12: Resources

    Resources Eris™ Series E3.5 4.1. Technical Specifications Owner’s Manual Resources 4.1. Technical Specifications Inputs 2 balanced ¼” TRS, 2 unbalanced RCA, 1 stereo 1/8” Performance Frequency Response 80 Hz to 20 kHz Crossover Frequency 2.8 kHz Amplifier Power 25W per speaker Peak SPL at 1m 100 dB Input Impedance...
  • Page 13: Troubleshooting

    If it’s connected to a power conditioner, verify that the power conditioner is turned on and functioning. No audio. If your Eris E3.5 appears to power on but you hear no sound when playing audio from your audio source (the lights are on but nobody’s home), first make sure that the cable connecting your...
  • Page 14 PreSonus- branded products under normal use. This Limited Warranty applies only to hardware products manufactured by or for PreSonus that can be identified by the PreSonus trademark, trade name, or logo affixed to them. Exclusions and Limitations: This warranty does not cover the following: 1.
  • Page 15 PreSonus. 6. Products on which the serial number has been altered, defaced, or removed. 7. Products purchased from an unauthorized PreSonus dealer (products that have transferable warranties are excluded from this provision, provided the customer and the product are registered with PreSonus).
  • Page 16 Warranty Information Owner’s Manual What PreSonus Will Do: PreSonus will repair or replace, at our sole and absolute option, products covered by this warranty at no charge for labor or materials. If the product must be shipped to PreSonus for warranty service, the customer must pay the initial shipping charges.
  • Page 17 If you have any questions about this warranty or service received, please contact PreSonus (USA) at +1 (225) 216- 7887 or one of our authorized international distributors at: http://www.presonus.com/buy/international_distributors.
  • Page 19 Electronics, Inc. Capture, Impact, Mixverb Presence, RedLightDist, SampleOne, Studio One, and Tricomp are trademarks or registered trademarks of PreSonus Software Ltd. Mac and Mac OS are registered trademarks of Apple, Inc., in the U.S. and other countries. Windows is a registered trademark of Microsoft, Inc., in the U.S. and other countries. Temporal EQ and TQ are trademarks of Fulcrum Acoustic.
  • Page 20 Eris Series E3.5 ™ High-Definition Near Field Studio Monitors Owner’s Manual 18011 Grand Bay Ct. • Baton Rouge, ® Louisiana 70809 USA• 1-225-216-7887 Part#70-52000064-B www.presonus.com...
