Contec ITX-i7435/ATX Quick Installation Manual

Quick Installation Guide

Version: 1.0
ITX-i7435/ATX
FORM FACTOR
Mini-ITX
MEMORY
DDR2 2GB
Expansion Bus
PCI Express x 16
Mini PCI
Copyright © 2006 All Rights Reserved.

Technical Support

If you have any technical difficulites, please consult the user's manual first at:
ftp://ftp.arbor.com.tw/pub/manual
Please do not hesitate to call or e-mail our customer service when you still can
not find out the answer.
http://www.arbor.com.tw
E-mail: info@arbor.com.tw
Part Number: 4041743501100P

Specification

Form Factor Mini-iTX Embedded Board Size (170 x 170 mm)
μ FC-PGA478 pin Pentium-M Up to 2.26GHz (FSB533MHz)
Processor
Chipset NB : Intel 915GME SB: Intel ICH6M
Support Two 240-pin DDRII SDRAM DIMM Socket Up to 2GB
System Memory
Intel® Graphics Media Accelerator (GMA) 900 graphics core
with DVI, LVDS and CRT support
VGA/LCD Controller
(Support dual independent display)
Dual Realtek RTL8111B Gigabit Ethernet
Ethernet
I/O Chips WINBOND W83627HG
Phoenix-Award PnP Flash BIOS
BIOS
Audio ALC655 AC'97 Codec, supports MIC-in/Line-in/Line-out
2 x Serial ATA with 150MB/s transfer rate
Serial ATA
ATA/IDE 1 x Ultra DMA 100, support 2 IDE drives
1 x Type II Compact Flash Disk Socket (Share IDE resource)
Flash Disk
2 x COM ports
COM 1: RS-232
Serial Port
COM 2: RS-232/422/485 Select
Supports SPP/EPP/ECP mode
Parallel Port
K/B and Mouse 1 x PS2 K/B and Mouse
8 x USB 2.0
USB Port
DIO 8 bit programmable Digital I/O
6-pin mini wafer
TV out
LCD 18/36 bit LVDS
PCI ExpressX16 slot for High-performance Graphics Card or
PCI ExpressX1 device
Expansion Interface
1 x Mini PCI socket
Hardware Monitor Chip Integrated in W83627HG
Support Real Time Clock
RTC
Power Input Connector ATX Power Connector
0ºC ~ 60ºC
Operation Temp.
Watchdog Timer 255-level Reset
Dimension (L x W) 170 x 170 mm (6.7" x 6.7")
CPU CHIPSET
μFCPGA 478
Intel 915GME /
Pentium 2.26 GHz ICH6M
IDE I/O
1 x UDMA 100
USB/Serial/LPT
2 x SATA
LAN AUDIO
Dual Intel
PCI Express AC'97 Codec
Giga LAN
1
3

Packing List

Before you begin installing your single board, please make sure that the following
materials have been shipped:
1x ITX-i7435/ATX Mini ITX Embedded board
1x I/O Bracket
1x CPU Cooler or Heatsink
1x CD-ROM (For Driver used)
1x Quick Installation Guide
1x Warranty Card

Optional

1 x Cable Kit (CBK-07-7435-00) contains the followings:
Ultra DMA100 IDE Flat cable x 1
USB cable, L = 250 mm x 2
Serial ATA cable x 1
Print cable x 1
LPT to FDD cable x 1

Ordering Information

ITX-i7435VL2G/ATX
Pentium M Socket 478 Mini-ITX M/B with CRT/LCD, Audio, SATA, CF, Dual PCIE
Gb LAN and PCI ExpressX16 slot
ITX-i7435VL2G/ATX w/o CF
Pentium M Socket 478 Mini-ITX M/B with CRT/LCD, Audio, SATA, Dual PCIE
Gb LAN and PCI ExpressX16 slot
Cable Kit
CBK-07-7435-00

Jumper/Connector Quick Reference

Jumpers

Label Function
JBAT1 Clear CMOS
JRS1 COM2 RS-232/422/485 Select
JVLCD1 LVDS1 LCD Voltage Select
JFSB1 Front side bus clock Select

Connectors

ATXP1 ATX Power Connector
AUDIO1 Audio interface Port
CPUF1 CPU FAN Connector
SYSF1 System FAN Connector
DIMM1,2 240-pin DDR2 DIMM Socket
DIO1 Digital I/O Connector
IDE1 Primary IDE Connector
PCIE1 PCI ExpressX16 Interface Slot
MINIPCI1 Mini PCI Interface
LVDS1 LVDS LCD Panel Connector
INV1 LCD Inverter Connector
IR1 Infrared (IR) Connector
SATA 1, 2 Serial ATA 1, 2 Connector
LPT1 Parallel Port or Floppy Connector
CON1 RS-422/485 USB Connector
USB1, 2 USB Connector
KBM1/KBM2 PS/2 Keyboard and Mouse
VGA1 CRT Display & DVI Connector
LAN1, LAN2 Ethernet +USB Connector
JFRT1 Front Panel (Switches and Indicators)
CFD1 Compact Flash Socket
JPWR1 AT/ATX Power Type Selection
Note:
1. LPT/FDD select by BIOS
2. Compact Flash share by IDE1 resources, can not Hot swap
