RCA RDR4320 Quick Start Manual

Communications Systems
What's Included:
MIC
RDR4320
RDR4350
Handheld Radio
Handheld Radio
Antenna BC4300
Belt Clip
ANH4300V - VHF
4
5
7
8
6
1
2
3
13
RDR4320 RDR4350
Prodcut Overview
1 P1 Key (hot key)
3 P2 Key (hot key)
5 Antenna
7 Channel Knob
9 Earpiece
(RDR4350/RDR4380 only)
LCD Display
11 (RDR4350/RDR4380
only)
13 Speaker
Duplex Microphone
15 (RDR4350/
RDR4380 only)
17 Accessory Jack Cover
19 Belt Clip
21 Battery Pole Piece
Micro SD Encryption Card
23
Cover
RDR4300 Series
Digital Radios
RDR4380 B4323LI
Handheld Radio Li-Ion Battery
(2550 mAh)
PS4301 CH4301
Power Supply Desktop Rapid
Charger
16
9
10
17
11
12
13
14
15
RDR4380
2 PTT Key (transmit key)
4 Emergency Call Key
6 LED Indicator
8 Radio On-Off/ Volume Knob
Simplex Microphone
10 (RDR4350/
RDR4380 only)
Function Keypad
12 (RDR4350/RDR4380
only)
Numeric Keypad
14 (RDR4350/RDR4380
only)
16 Battery Latch
18 Strap hole
20 Battery
22 Accessory Jack
Attaching the Antenna:
1. Turn the antenna clockwise to
attach it.
Note: To remove the antenna,
rotate it counter-clockwise.
Removing the Battery:
22
23
1. As shown, hold the radio like
1
this.
2. As shown, push up the battery
2
latch with another hand.
18
3. Slide the battery as
19
direction shown.
20
Attaching audio accessory / programming cable:
21
Function Keypad
Function/Enter key
Receive/Call key
Programmable Keys
[P1] key, [P2] key, four direction keys,
menu shortcut keys by your RCA dealer. The default state of [P1] and [P2]
shortcuts are for high-low power switching. You only need to press the
corresponding shortcut key to quickly access the needed menu or function.

QUICK START GUIDE

Attaching the Battery:
2
1. While laying flat, put the battery
into the radio as
horizontally push to the top along
the aluminum slot.
2. As shown, up the battery latch
2
forward until a click is heard.
Attaching the Belt Clip:
1
2
3
1. Rotate the screws counter-
clockwise to remove them.
2. Align the screw holes on the
belt clip with those on the
radio's body, and then tighten
arrow
3
the screws clockwise.
Note: To remove the belt clip,
loosen the screws.
1. Open the accessory jack cover.
As shown, align the plug
1
with the accessory jack, then
connet it.
2. As shown, tighten the screw
1 2
clockwise on the plug.
Note: To remove accessories,
loosen the screw counter-
2
clockwise.
(RDR4350 / RDR4380 models)
key, can be set as function or
1
shown,
1
Back/Option key
Hangup key
Direction key
