RCA RDR1520 Quick Start Manual

Communications Systems
What's Included:
RDR1520
TM
Handheld Radio
Antenna
ANH1520U - UHF models
ANH1520V - VHF models
PS1521*
Power Supply
*Items sent in separate box if ordered.
RDR1520
TM
Digital Radios
B1520LI
Li-Ion Battery
(2000 mAh)
BC1520
Belt Clip
CH1521*
Desktop Rapid Charger

QUICK START GUIDE

Attaching the Battery:

Line up battery guide slots and
slide into place until it locks in.
Attaching Belt Clip:
Align the screw
holes and use a
small screwdriver
to fasten screws.
ATTENTION:
• Remove Battery
• Do Not Use
Power Tool
• Use Screwdriver
Only

Charging the Battery:

Slide battery into the charging
base with or without the
radio attached. Secure battery
in place, Red LED will be on
when charging.
Note: Charge a new battery 12 to 14 hours before initial use
for best performance. Maximum battery capacity is normally
achieved after two or three full charge / discharge cycles.

Attaching the Antenna:

Be sure radio is
off, line up screw
threads and twist
antenna clockwise
until it is secure.

Connecting the Charger:

Plug power supply into the outlet
and connect the other end to
charger base.
