ELECTROMATIC CHECK LINE DTMB-200 Operating Manual

10.00 WARRANTY
ELECTROMATIC Equipment Co., Inc. (ELECTROMATIC) warrants to the original pur-
chaser that this product is of merchantable quality and confirms in kind and quality with
the descriptions and specifications thereof. Product failure or malfunction arising out of
any defect in workmanship or material in the product existing at the time of delivery
thereof which manifests itself within one year from the sale of such product, shall be
remedied by repair or replacement of such product, at ELECTROMATIC's option, except
where unauthorized repair, disassembly, tampering, abuse or misapplications has taken
place, as determined by ELECTROMATIC. All returns for warranty or non-warranty
repairs and/or replacement must be authorized by ELECTROMATIC, in advance, with all
repacking and shipping expenses to the address below to be borne by the purchaser.
THE FOREGOING WARRANTY IS IN LIEU OF ALL OTHER WARRANTIES,
EXPRESSED OR IMPLIED, INCLUDING BUT NOT LIMITED TO, THE WARRANTY
OF MERCHANTABILITY AND FITNESS FOR ANY PARTICULAR PURPOSE OR
APPLICATION. ELECTROMATIC SHALL NOT BE RESPONSIBLE NOR LIABLE FOR
ANY CONSEQUENTIAL DAMAGE, OF ANY KIND OR NATURE, RESULTING FROM
THE USE OF SUPPLIED EQUIPMENT, WHETHER SUCH DAMAGE OCCURS OR IS
DISCOVERED BEFORE, UPON OR AFTER REPLACEMENT OR REPAIR, AND
WHETHER OR NOT SUCH DAMAGE IS CAUSED BY MANUFACTURER'S OR
SUPPLIER'S NEGLIGENCE WITHIN ONE YEAR FROM INVOICE DATE.
Some State jurisdictions or States do not allow the exclusion or limitation of incidental or
consequential damages, so the above limitation may not apply to you. The duration of any
implied warranty, including, without limitation, fitness for any particular purpose and
merchantability with respect to this product, is limited to the duration of the foregoing
warranty. Some states do not allow limitations on how long an implied warranty lasts
but, not withstanding, this warranty, in the absence of such limitations, shall extend for
one year from the date of invoice.
ELECTROMACTIC Equipment Co., Inc.
600 Oakland Ave. Cedarhurst, NY 11516—USA
Tel: 1-800-645-4330/ Tel: 516-295-4300/ Fax: 516-295-4399
24
OI810B
1.00 INTRODUCTION . . . . . . . . . . . . . . . 2
2.00 DTMB OVERVIEW . . . . . . . . . . . . . 3
DESCRIPTION OF KEYS . . . . . . . . . 4
3.00
4.00 QUICK START INSTRUCTIONS . . 5
4.10 Setup
4.20 Operation
5.00 SETUP . . . . . . . . . . . . . . . . . . . . . . 8
5.10 Installing Batteries
5.20 AC Adapter
5.30 Configuring Dip Switches
5.31 Access the DIP Switch Block
5.32 Setting the DIP Switches . . . .
5.40 Thickness Compensator
5.41 Preparing Sample
5.42 Inserting Sample
5.50 Gravity Correction (Zero)
6.00 BUILT-IN MEMORY SYSTEM . . . . 14
6.10 Standard Memory
6.11 Viewing Data
6.12 Clearing Data
6.20 Standard NAPO Memory
INDEX
7.00 CALIBRATION . . . . . . . . . . . . . . . . 16
7.10 Checking Calibration
7.20 Field Calibration Adjustment
7.30 Special Calibraton
8.00 GENERAL NOTES . . . . . . . . . . . . . 19
8.10 Turning Power On/OFF
8.20 Display Indicators & Codes
8.21 Over Range
8.22 EPROM Error
8.23 Low Battery
8.30 Options
8.31 Ultra-High Speed Rollers
8.32 Lever
8.33 AC Adapter
8.34 Special Calibration
.
8.40 On-Line Mounting Holes
.
9.00 SPECIFICATIONS . . . . . . . . . . . . . . 22
10.00 WARRANTY . . . . . . . . . . . . . . . . . . 24
1
