Genelec 7050C Quick Setup Manual page 2

LINE LEVEL SIGNAL SOURCE
7050C ACTIVE SUBWOOFER
IN
OUT
ROLL-OFF PHASE
-8 dB -270°
-4 dB -90°
-180°
ON
ISS
ISS SENSITVITY LOW
LFE +10 dB
Connect a monitor to
the subwoofer and feed
an 85 Hz test signal
to the corresponding
input connector.
SERIAL
NUMBER
www.genelec.com
MADE IN FINLAND
IN 1 IN 2 IN 3 IN 4
OUT 1 OUT 2 OUT 3 OUT 4 OUT 5
5.1 Connetion and Wiring
TIP
SLEEVE
Bypass Switch Connection
ROLL-OFF PHASE
-8 dB -270°
-4 dB -90°
-180°
ON
ISS
ISS SENSITVITY LOW
LFE +10 dB
Toggle the subwoofer's
-180 degree phase switch
"on" and "off" and set
it to the position which
gives the lowest sound
level at the listening
position.
Phase Alignment
Quick setup guide
WARNING
ELECTRIC SHOCK HAZARD. DO NOT OPEN. DO NOT SUBJECT TO WATER OR MOISTURE. NO USER
SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED PERSONNEL. USE EARTHED MAINS
CONNECTION ONLY.
AVERTISSEMENT
RISQUE DE CHOC ÉLECTRIQUE. NE PAS OUVRIR. NE PAS EXPOSER À L'EAU OU L'HUMIDITÉ. AUCUN
COMPOSANT À L'INTÉRIEUR REMPLAÇABLE PAR L'UTILISATEUR. ADRESSER TOUTE RÉPARATION À
UN PERSONNEL QUALIFIÉ. CET APPAREIL DOIT ÊTRE RACCORDÉ À LA TERRE.
BYPASS
IN 5 LFE IN
ROLL-OFF PHASE
-8 dB -270°
-4 dB -90°
-180°
0
+3
-3
+6
-4
ON
+12 -6
THIS DEVICE COMPLIES WITH FCC PART 15 AND
CANADIAN ICES-003 RADIO FREQUENCY CLASS B
INPUT dBu
ISS
EMISSION REQUIREMENTS. REFER TO OPERATING
PRODUCING
ISS SENSITVITY LOW
MANUAL FOR FULL INFORMATION.
LFE +10 dB
100 dB SPL (1 m)
ROLL-OFF PHASE
-8 dB -270°
-4 dB -90°
-180°
ON
ISS
ISS SENSITVITY LOW
LFE +10 dB
Toggle the subwoofer's
-90 degree phase switch
"on" and "off" and set
it to the position which
gives the lowest sound
level at the listening
position.
7050C
LAITE ON LIITETTÄVÄ
SUOJAKOSKETTIMILLA
VARUSTETTUUN PISTORASIAAN.
APPARATET MÅ TILKOPLES
JORDET STIKKONTAKT.
APPARATEN SKALL ANSLUTAS
TILL JORDAT UTTAG.
MAINS INPUT
50 / 60 Hz 150 W
100 - 240 V~
Bass management by-
pass function is active
when tip and ring are
connected together.
ROLL-OFF PHASE
-8 dB -270°
-4 dB -90°
-180°
ON
ISS
ISS SENSITVITY LOW
LFE +10 dB
Set the -180 degree
switch to the opposite
position.
