Installing Simplex and Duplex Receptacles into:
• Series 9000 Structural Panel
®
• Series 9000 Energy Management Panel and Worksurface
®
• Avenir Power Panel
®
• 3-Circuit, Shared Neutral and System Ground
• 4-Circuit, 3 with Shared Neutral and System Ground
and 1- Isolated Circuit and Ground
Optional Wiring Schematics:
• 2-General Circuits with Shared Neutral & System Ground
and 2-Designated circuits with Shared Neutral and Isolated Ground
• 3-Separate Circuits - 2 with own Neutral and Isolated Ground,
1 with own Neutral and System Ground
• 4-Circuit - 3 with Shared Neutral and Isolated Ground,
1-Circuit with System Ground
ALL ELECTRICAL INSTALLATIONS SHOULD BE PERFORMED BY A
QUALIFIED PERSON IN ACCORDANCE WITH CODES AND
REGULATIONS APPLICABLE AT THE INSTALLATION SITE. CIRCUITS
SHOULD BE CHECKED FOR PROPER VOLTAGES
System
SIMPLEX SHOWN
WARNING:
Flag Color
(3) Black
(3+D) Black
System Flag Color
(2+2) Grey
(SN) White
(3I+1) Tan
939503122 Rev A
1
of
5
