IO-Digital8 User Manual
4. Connection Points
Fig 1. Side panels
1. Terminal Block connectors
There are eight female terminal block connectors on the IO-digital8, these are for connecting
your additional dry contacts via the male terminal block connector.
2. RJ45 Connection point
This is for connecting the IO-digital8 to the base unit via straight cable.
1) Installation
1. Connecting to the base unit
Below is a diagram showing how to connect the IO-Digital8 to the AKCP securityProbe 5E.
To begin setup the unit by following the instructions below:-
Provided by official AKCP-Distributor Didactum
https://www.didactum-security.com/en/
4
