Summary of Contents for AKCP IO-digital8
-
Page 1: User Manual
IO-digital8 (Phoenix Connectors) User Manual Copyright © 2010, AKCP Co., Ltd. Provided by official AKCP-Distributor Didactum https://www.didactum-security.com/en/... -
Page 2: Sensor Settings
1) Introduction What is IO-digital8? • How to use this manual • Package contents • Connection points • 2) Installation • Connecting to the base unit • Setting up a sensor 3) Sensor Settings Provided by official AKCP-Distributor Didactum https://www.didactum-security.com/en/... -
Page 3: How To Use This Manual
IO-Digital8 User Manual 1) Introduction 1. What is IO-digital8? The IO-digital8 module extends the securityProbe 5E capabilities by connecting an additional eight dry contacts to a single intelligent sensor port on the securityProbe-5E. 2. How to use this manual This manual is meant to provide the user with a step by step guide on how to configure and set up their unit. -
Page 4: Connection Points
This is for connecting the IO-digital8 to the base unit via straight cable. 1) Installation 1. Connecting to the base unit Below is a diagram showing how to connect the IO-Digital8 to the AKCP securityProbe 5E. To begin setup the unit by following the instructions below:- Provided by official AKCP-Distributor Didactum... -
Page 5: Setting Up A Sensor
IO-Digital8 User Manual 2. Setting up a Sensor In this section we will now go through the basic set up of a sensor. This basic set up process is applicable to all of our dry contact sensors. If you require information on specific functions of a particular sensor then please download the manual for that sensor from our website, or locate it on your product CD. - Page 6 By clicking on the “Sensors” tab (indicated below). This will bring you to the following page, the sensors page:- As you can see in the above image, the IO-digital8 as shown connected to port number one Once you have clicked on the sensor port you require you will be bought to the following...
- Page 7 IO-Digital8 User Manual 3. Sensor Settings 1. Dry contact Array tabs Each dry contact sensor is listed in numeric order as “Dry contact Array”; Click any one of these to be taken to the settings page of the sensor chosen. 2. Sensor Name By clicking in this box you can change the name of each sensor to anything you desire.
- Page 8 IO-Digital8 User Manual This displays your chosen sensors current status. 4. Online / Offline This shows you if your chosen sensor is currently online or offline. 5. Direction Here you can set the direction of your sensor to either input or output, if you select output you will be shown the following options:- 5a.
- Page 9 7. Enable Graph This option allows you to enable your graphing data. To access your graph, click “click here to view graph” This will display the page shown below which contains all your graphing data. Provided by official AKCP-Distributor Didactum https://www.didactum-security.com/en/...
- Page 10 IO-Digital8 User Manual 8. Sensors URL...
- Page 11 IO-Digital8 User Manual In the “Sensor URL” box you can assign a website to your chosen sensor, this will be displayed within sensor information on the “Map” interface on the summary page. The website link can be opened in the current window or in a new window.
- Page 12 IO-Digital8 User Manual Provided by official AKCP-Distributor Didactum https://www.didactum-security.com/en/...
