Seiko 5t82a; watch movement
Hide thumbs

Advertisement

Quick Links

Instruction of Watch Movement
Cal. YM26A
 Display
World time hour hand
Small second hand
 Crown and button operation
Crown
Free
World time city setting
Button A
(Clockwise)
World time city setting
Button B
(Counterclockwise)
[*1] World time hand, alarm hand and city hand position adjustment
If the world time hands and the alarm hands are not adjusted to the current time or the city hand is not in the
"0" position, follow the procedures below to set them.
(1) Pull the crown out to the 2nd click position.
- If the alarm has been set and the crown is pulled out to the 2nd click position, the world time and alarm hands will turn to indicate
the current time.
(2) Set the alarm hands.
Press the button B repeatedly to set the alarm hands to the time the main time hands indicate.
(3) Set the city hand.
Press the button A for 2 seconds.
- The city hand turns a full round.
Press the button B to set the city hand to the desired city for which you know the current time.
In most cases, this is a city that belongs to the same time zone as your home city.
(4) Set the world time hands.
Press the button A for 2 seconds.
- The world time hands turn a full round.
Press the button B to set the world time hands to indicate the time in the city you selected in the step (3) .
Press the button A for 2 seconds here will allow you to resume the procedure again as indicated by the arrow if necessary.
(5) Push the crown back to the normal position.
Tips : When setting the hands, the hand moves quickly if the button B is kept pressed.
City hand
Hour hand
Alarm hour hand
N : normal
WORLD TIME & ALARM
- World time
- Alarm
World time minute hand
Minute hand
Button A
N → 1 → 2
Button B
Alarm minute hand
Crown position
1 : 1st click
Turn clockwise for date
change
Sound demonstration
(more than 2 seconds)
Alarm time setting
(at 6H small circle)
Crown
Date
2 : 2nd click
Time setting
[*1]
[*1]
