Pairing the Base Station using the
VVX Phone
You can pair the base station with the VVX phone from the Features menu
on the VVX phone. When the base station is paired with the phone, the
Handset Icon displays on the phone.
Pair the Base Station via the PC Port
When the Ethernet cable is connected from the Base Station LAN port to the
VVX PC port, the phone pairs with the base station automatically.
To pair with the base station via PC Port Pairing:
1. Connect an Ethernet cable from the LAN Port on the base station to the
PC Port on the phone.
2. On the phone, navigate to Settings > Features >
VVX D60 Configuration.
3. Select VVX D60 Profile, then select Enable.
4. On the VVX D60 Configuration screen, select Base Station, then
select PC Port Pairing.
Pair the Base Station via Auto Pairing
When the Ethernet cable is connected from the Base Station LAN port into a
LAN outlet, the phone pairs with the base station automatically.
To pair with the base station via Automatic Discovery:
1. On the phone, navigate to Settings > Features > VVX D60
Configuration.
2. Select VVX D60 Profile, then select Enable.
3. On the VVX D60 Configuration screen, select Base Station, then
select Auto Pairing.
4. When the base station displays, select Pair.
Register a VVX D60 Wireless Handset
After the VVX D60 Base Station is paired with the VVX phone, you can regis-
ter up to five wireless handsets to the base station.
To register the wireless handset with the base station:
1. On the wireless handset, navigate to Settings > Features >
Registration, then select Register.
2. The wireless handset displays a message informing you to press the
FIND button or register on the VVX phone.
3. Press and hold the Find button on the base station for more than five
seconds.
4. The wireless handset displays Register to VVX D-60?.
5. Select Yes to confirm the registration with the base station.
6. When the registration is successful, the screen displays Registration
Successful.
LIMITED WARRANTY. Polycom warrants to the end user ("Customer") • The product software is the current major version or the next
that this product will be free from defects in workmanship and materials, preceding major version (software revisions are labeled as "x.y.z,"
under normal use and service, for one year from the date of purchase with the first two digits designating major versions).
from Polycom or its authorized reseller. Polycom's sole obligation under • The product software comes with 90-day software warranty,
this express warranty shall be, at Polycom's option and expense, to repair providing for software updates (minor releases/bug fixes). To
the defective product or part, deliver to Customer an equivalent product or continue to receive support, purchasing a maintenance contract is
part to replace the defective item, or if neither of the two foregoing options the most economical solution.
are reasonably available, Polycom may, on its sole discretion, refund to
Customer the purchase price paid for the defective product. All products Requests for software support should be made through the Polycom
that are replaced will become the property of Polycom. Replacement Reseller from whom the product was purchased.
products or parts may be new or reconditioned. Polycom warrants any
LIMITATION OF LIABILITY. TO THE FULL EXTENT ALLOWED BY
replaced or repaired product or part for ninety (90) days from shipment, or
LAW, POLYCOM EXCLUDES FOR ITSELF AND ITS SUPPLIERS ANY
the remainder of the initial warranty period,
LIABILITY, WHETHER BASED IN CONTRACT OR TORT (INCLUDING
whichever is longer. Products returned to Polycom must be sent prepaid NEGLIGENCE), FOR INCIDENTAL, CONSEQUENTIAL, INDIRECT,
and packaged appropriately for safe shipment, and it is recommended SPECIAL, OR PUNITIVE DAMAGES OF ANY KIND, OR FOR LOSS
that they be insured or sent by a method that provides for tracking of the OF REVENUE OR PROFITS, LOSS OF BUSINESS, LOSS OF
package. Responsibility for loss or damage does not transfer to Polycom INFORMATION OR DATA, OR OTHER FINANCIAL LOSS ARISING
until the returned item is received by Polycom. The repaired or replaced OUT OF OR IN CONNECTION WITH THE SALE, INSTALLATION,
item will be shipped to Customer, at Polycom's expense, not later than MAINTENANCE, USE, PERFORMANCE, FAILURE, OR INTERRUPTION
thirty (30) days after Polycom receives the defective product, and Polycom OF ITS PRODUCTS, EVEN IF POLYCOM OR ITS AUTHORIZED
will retain risk of loss or damage until the item is delivered to Customer. RESELLER HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH
DAMAGES, AND LIMITS ITS LIABILITY TO REPAIR, REPLACEMENT,
EXCLUSIONS. Polycom will not be liable under this limited warranty if its
OR REFUND OF THE PURCHASE PRICE PAID, AT POLYCOM'S
testing and examination disclose that the alleged defect or malfunction in
OPTION. THIS DISCLAIMER OF LIABILITY FOR DAMAGES WILL NOT
the product does not exist or results from:
BE AFFECTED IF ANY REMEDY PROVIDED HEREIN SHALL FAIL OF
ITS ESSENTIAL PURPOSE.
• Failure to follow Polycom's installation, operation, or maintenance
na instructions.
DISCLAIMER. Some countries, states, or provinces do not allow the
• Unauthorized product modification or alteration.
exclusion or limitation of implied warranties or the limitation of incidental
• Unauthorized use of common carrier communication services
or consequential damages for certain products supplied to consumers, or
accessed through the product.
the limitation of liability for personal injury, so the above limitations and
• Abuse, misuse, negligent acts or omissions of Customer and
exclusions may be limited in their application to you. When the implied
persons under Customer's control; or
warranties are not allowed to be excluded in their entirety, they will be
• Acts of third parties, acts of God, accident, fire, lightening, power
limited to the duration of the applicable written warranty. This warranty
surges or outages, or other hazards.
gives you specific legal rights which may vary depending on local law.
WARRANTY EXCLUSIVE. IF A POLYCOM PRODUCT DOES
GOVERNING LAW. This Limited Warranty and Limitation of Liability shall
NOT OPERATE AS WARRANTED ABOVE, CUSTOMER'S SOLE
be governed by the laws of the State of California, U.S.A., and by the laws
REMEDY FOR BREACH OF THAT WARRANTY SHALL BE REPAIR,
of the United States, excluding their conflicts of laws principles. The United
REPLACEMENT, OR REFUND OF THE PURCHASE PRICE PAID, AT
Nations Convention on Contracts for the International Sale of Goods is
POLYCOM'S OPTION. TO THE FULL EXTENT ALLOWED BY LAW, THE
hereby excluded in its entirety from application to this Limited Warranty
FOREGOING WARRANTIES AND REMEDIES ARE EXCLUSIVE AND
and Limitation of Liability. All rights reserved under International and Pan-
ARE IN LIEU OF ALL OTHER WARRANTIES, TERMS, OR CONDITIONS,
American Copyright Conventions. No part of the contents of this manual
EXPRESS OR IMPLIED, EITHER IN FACT OR BY OPERATION OF LAW,
may be copied, reproduced, or transmitted in any form or by any means,
STATUTORY OR OTHERWISE, INCLUDING WARRANTIES, TERMS, OR
or translated into another language or format, in whole or part, without
CONDITIONS OF MERCHANTABILITY, FITNESS FOR A PARTICULAR
written consent from Polycom, Inc. Do not remove (or allow anybody else
PURPOSE, SATISFACTORY QUALITY, CORRESPONDENCE WITH
to remove) any product identification, copyright or other notices. Polycom,
DESCRIPTION, AND NON-INFRINGEMENT, ALL OF WHICH ARE
the Polycom logo design, and Polycom VVX D60 Wireless Handset is a
EXPRESSLY DISCLAIMED. POLYCOM NEITHER ASSUMES NOR
trademark of Polycom, Inc. in the U.S. and various other countries.
AUTHORIZES ANY OTHER PERSON TO ASSUME FOR IT ANY
OTHER LIABILITY IN CONNECTION WITH THE SALE, INSTALLATION, COPYRIGHT. All rights reserved under International and Pan-American
MAINTENANCE OR USE OF ITS PRODUCTS. SERVICE AGREEMENTS. Copyright Conventions. No part of the contents of this manual may be
Please contact your Polycom Authorized Reseller for information about copied, reproduced, or transmitted in any form or by any means, or
service agreements applicable to your product. translated into another language or format, in whole or part, without written
consent of Polycom, Inc. Polycom ® and the logo design are registered
SOFTWARE SUPPORT. Polycom will provide support for software running is a
trademarks and Polycom VVX D60 Wireless Handset is a trademark of
on the Product if all of the following conditions are satisfied:
Polycom, Inc. in the United States, and various countries. Do not remove
• The product is under warranty or is covered by a Polycom service (or allow any third party to remove) any product identification, copyright
contract; or other notices.
CE Mark R & TTE Directive (EU Only) Šiuo Polycom (UK) Ltd deklaruoja, kad šis Polycom VVX D60 Wireless Handset atitinka
esminius reikalavimus ir kitas 1999/5/EB Direktyvos nuostatas.
VVX D60 Wireless Handset
Polycom (UK) Ltd tímto prohlašuje, že tento Polycom VVX D60 Wireless Handset je ve
Hierbij verklaart Polycom (UK) Ltd dat het toestel Polycom VVX D60 Wireless Handset
shodě se základními požadavky a dal.imi příslušnými ustanoveními směrnice 1999/5/ES. a dal.imi 1999/5/EB
in overeenstemming is met de essentiële eisen en de andere relevante bepalingen van
Undertegnede Polycom (UK) Ltd erklærer herved, at følgende udstyr Polycom VVX richtlijn 1999/5/EG.
VVX D60 Wireless Handset
D60 Wireless Handset overholder de væsentlige krav og øvrige relevante krav i direktiv essentiële
Hawnhekk, Polycom (UK) Ltd, jiddikjara li dan Polycom VVX D60 Wireless Handset
1999/5/EF.
jikkon-forma mal-ħtiġijiet essenzjali u maprovvedimenti oħrajn relevanti li hemm
VVX D60 Wireless Handset
fid-Dirrettiva 1999/5/EC.
Hiermit erklärt Polycom (UK) Ltd, dass sich das Gerät Polycom VVX D60 Wireless
u ma
Handset in Übereinstimmung mit den grundlegenden Anforderungen und den übrigen
Alulírott, Polycom (UK) Ltd nyilatkozom, hogy a Polycom VVX D60 Wireless Handset
einschlägigen Bestimmungen der Richtlinie 1999/5/EG befindet.
megfelel a vonatkozó alapvetõ követelményeknek és az 1999/5/EC irányelv egyéb
VVX D60 Wireless Handset
Käesolevaga kinnitab Polycom (UK) Ltd seadme Polycom VVX D60 Wireless Handset elõírásainak.
vastavust direktiivi 1999/5/EÜ põhinõuetele ja nimetatud direktiivist tulenevatele teistele
Polycom (UK) Ltd erklærer herved at utstyret Polycom VVX D60 Wireless Handset er i
asjakohastele sätetele. VVX D60 Wireless Handset
samsvar med de grunnleggende
requirements and krav og
Hereby, Polycom (UK) Ltd. declares that this VVX D60 Wireless Handset is in compliance
krav og øvrige relevante krav i direktiv 1999/5/EF.
with the essential requirements and other relevant provisions of Directive 1999/5/EC.
VVX D60 Wireless Handset
Niniejszym Polycom (UK) Ltd oświadcza, że Polycom VVX D60 Wireless Handset
Por medio de la presente Polycom (UK) Ltd declara que el Polycom VVX D60 Wireless
jest zgodne z zasadniczymi wymaganiami oraz innymi stosownymi postanowieniami
Handset cumple con los requisitos esenciales y cualesquiera otras disposiciones
Dyrektywy 1999/5/WE
aplicables o exigibles de la Directiva 1999/5/CE. VVX D60 Wireless Handset
Polycom (UK) Ltd declara que este Polycom VVX D60 Wireless Handset está conforme
outras
ΜΕ ΤΗΝ ΠΑΡΟΥΣΑ Polycom (UK) Ltd ΔΗΛΩΝΕΙ ΟΤΙ Polycom VVX D60 Wireless
com os requisitos essenciais e outras disposições da Directiva 1999/5/CE.
Handset ΣΥΜΜΟΡΦΩΝΕΤΑΙ ΠΡΟΣ ΤΙΣ ΟΥΣΙΩΔΕΙΣ ΑΠΑΙΤΗΣΕΙΣ ΚΑΙ ΤΙΣ ΛΟΙΠΕΣ
VVX D60 Wireless Handset
ΣΧΕΤΙΚΕΣ ΔΙΑΤΑΞΕΙΣ ΤΗΣ ΟΔΗΓΙΑΣ 1999/5/ΕΚ. Polycom (UK) Ltd izjavlja, da je ta Polycom VVX D60 Wireless Handset v skladu z
relevantnimi
bistvenimi zahtevami in ostalimi relevantnimi določili direktive 1999/5/ES.
Par la présente Polycom (UK) Ltd déclare que l'appareil Polycom VVX D60 Wireless
Handset est conforme aux exigences essentielles et aux autres dispositions pertinentes VVX D60 Wireless Handset Polycom (UK) Ltd týmto vyhlasuje, že Polycom VVX D60 Wireless Handset spĺňa
essenziali ed VVX D60 Wireless Handset is a
de la directive 1999/5/CE. základné požiadavky a všetky príslušné ustanovenia Smernice 1999/5/ES.
Con la presente Polycom (UK) Ltd dichiara che questo Polycom VVX D60 Wireless VVX D60 Wireless Handset Polycom (UK) Ltd vakuuttaa täten että Polycom VVX D60 Wireless Handset tyyppinen
Handset è conforme ai requisiti essenziali ed alle altre disposizioni pertinenti stabilite
aerar krofur, laite on direktiivin 1999/5/EY oleellisten vaatimusten ja sitä koskevien direktiivin muiden oleellisten
dalla direttiva 1999/5/CE. ehtojen mukainen.
VVX D60 Wireless Handset
Hér með lýsir Polycom (UK) Ltd yfir því að Polycom VVX D60 Wireless Handset er í Härmed intygar Polycom (UK) Ltd att denna Polycom VVX D60 Wireless Handset
prasibam un vasentliga
samræmi við grunnkröfur og aerar krofur, sem gerðar eru í tilskipun 1999/5/EC står I överensstämmelse med de vasentliga egenskapskrav och övriga relevanta
bestämmelser som framgår av direktiv 1999/5/EG.
Ar šo Polycom (UK) Ltd deklarē, ka Polycom VVX D60 Wireless Handset atbilst is a
Direktīvas 1999/5/EK būtiskajām prasibam un citiem ar to saistītajiem noteikumiem.
SAFETY AND REGULATORY INFORMATION. laquelle l'appareil est branché doit être installée près de l'équipement et
doit toujours être facilement accessible.
CE Safety
This Class [B] digital apparatus complies with Canadian ICES-003. Cet
VVX D60 Wireless Handset VVX D60 Wireless Handset
a dal.imi 1999/5/EB appareil numérique de la classe [B] sera conforme à la norme NMB-003
For pluggable equipment, the socket-outlet (power adaptor) shall be
du Canada.
VVX D60 Wireless Handset VVX D60 Wireless Handset
installed near the equipment and shall be easily accessible.
essentiële
To avoid electric shock, do not connect safety extra low voltage (SELV)
VVX D60 Wireless Handset circuits to teleconference station network (TNV) circuits. LAN ports contain VVX D60 Wireless Handset
FCC Part 15
u ma
SELV circuit, and WAN ports contain TNV circuits. Some LAN and WAN
ports both use RJ-45 connectors. Use caution when connecting cables.
Privacy of communications may not be ensured when using this telephone. VVX D60 Wireless Handset VVX D60 Wireless Handset
This product is rated 5V DC, 1.2A. When used with the optional external
Warning : Changes or modifications to this equipment not expressly
power supply (S008ACM0500120, or similar rated PSU), the power supply
VVX D60 Wireless Handset VVX D60 Wireless Handset
approved by the party responsible for compliance could void the user's
requirements and krav og shall be a Listed power supply with a LPS output, rated 5V, min. 1.2A.
authority to operate the equipment.
Hearing Aid Compatibility (HAC): This device is hearing aid compatible.
VVX D60 Wireless Handset VVX D60 Wireless Handset
This device complies with Part 15 of the FCC Rules. Operation is subject
Australia Warning: This equipment will be inoperable when mains power
to the following two conditions:
fails.
VVX D60 Wireless Handset VVX D60 Wireless Handset
(1) This device may not cause harmful interference, and (2) This device outras
Radiation Exposure Statement: The antenna used for this transmitter must
must accept any interferences received, including interference that may
VVX D60 Wireless Handset VVX D60 Wireless Handset
be installed to provide a separation distance of at least 20 centimeters
cause undesired operation. relevantnimi
from all persons and must not be co-located or operating in conjunction
VVX D60 Wireless Handset Polycom VVX D60 Wireless Handset
Caution: To maintain the compliance with the FCC's RF exposure with any other antenna or transmitter. This portable device with its
essenziali ed
guideline, place the base unit at least 20 cm from nearby persons. antenna complies with FCC's RF radiation exposure limits set forth for an
VVX D60 Wireless Handset VVX D60 Wireless Handset
uncontrolled environment. To maintain compliance, this transmitter must
aerar krofur, For body worn operation, this handset has been tested and meets the oleellisten
not be co-located or operating in conjunction with any other antenna or
FCC RF exposure guidelines when used with the accessories supplied
VVX D60 Wireless Handset VVX D60 Wireless Handset
transmitter. FCC ID: EW780-9800-00.
prasibam un or designated for this product. Use of other accessories may not ensure vasentliga
compliance with FCC RF exposure guidelines.
IC RF
NOTE: This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to part 15 of the FCC Rules.
This product meets the applicable Industry Canada technical
These limits are designed to provide reasonable protection against harmful
specifications.
interference in a residential installation. This equipment generates, uses 5V DC, 1.2A
This device complies with Industry Canada licence-exempt RSS
and can radiate radio frequency energy and, if not installed and used in
standard(s). Operation is subject to the following two conditions: 1) This
accordance with the instructions, may cause harmful interference to radio
device may not cause interference, and 2) this device must accept any
communications. However, there is no guarantee that interference will
interference, including interference that may cause undesired operation
not occur in a particular installation. If this equipment does cause harmful
of the device.
interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct Caution: To maintain the compliance with the Industry Canada's RF
the interference by one or more of the following measures: Reorient or exposure guideline, place the base unit at least 20 cm from nearby
relocate the receiving antenna; Increase the separation between the persons. For body worn operation, this handset has been tested and
equipment and receiver; Connect the equipment into an outlet on a circuit
meets the Industry Canada RF exposure guidelines when used with
different from that to which the receiver is connected; or Consult the dealer
the accessories supplied or designated for this product. Use of other
or an experienced radio/TV technician for help. accessories may not ensure compliance with Industry Canada RF
exposure guidelines.
AC adaptor with Ferrite Core must be used with this equipment to ensure
compliance with the Class B FCC limits. Privacy of communications may not be ensured when using this telephone.
IC: 1135B-80980000.
Hereby, Polycom, Inc. declares that the products in this manual are CE
marked and in compliance with all EU directives and regulations that
apply to them including: R&TTE Directive 1999/5/EC. A full copy of the Taiwan:
EW780-9800-00
Declaration of Conformity can be obtained from Polycom Ltd., 270 Bath
Road, Slough, Berkshire, SL1 4DX, UK.
注意！
In accordance with Part 15 of the FCC Rules, the user is cautioned that
any changes or modifications not expressly approved by Polycom, Inc. 依據 低功率電波輻射性電機管理辦法
could void the user's authority to operate the equipment.
第十二條
Operating Ambient Conditions: Operating temperature: +32 to 104°F 經型式認證合格之低功率射頻電機，非經許可，公司、商號或使用者均不得擅自變更頻率、
(0 to 40°C); 加大功率或變更原設計之特性及功能。
Relative humidity: 5% to 95%, noncondensing; Storage temperature: -40 第十四條
to +160°F (-40 to +70°C).
低功率射頻電機之使用不得影響飛航安全及干擾合法通信；經發現有干擾現象時，應立即停
用，並改善至無干擾時方得繼續使用。
Installation must be performed in accordance with all relevant national
前項合法通信，指依電信法規定作業之無線電通信。
wiring rules. L'Installation doit être exécutée conformément à tous les
低功率射頻電機須忍受合法通信或工業、科學及醫療用電波輻射性電機設備干擾。
règlements nationaux applicable au filage électrique.
The outlet to which this apparatus is connected must be installed near the
equipment and must always be readily accessible. La prise électrique à
VVX D60 Wirel
VVX D60 Wireless Han
VVX D60 Wireles
VVX D60 Wireless H
VVX D60 Wireless
VVX D60 Wireless H
VVX D60 Wireless Ha
VVX D60 Wireless Handset
VVX D60 Wireless Handset
Polycom VVX D60 Wireless Handset
VVX D60 Wireless Handset
VVX D60 Wireless Ha
VVX D60 Wireless Handset
S008ACM0500120
5V 1.2A
1135B-80980000
1725-17820-001 Rev.A
