Intelligent 3MP Wireless Cube IPCAM
with Temperature and Humidity Sensor
Quick Installation Guide
Advertisement
Table of Contents
Related Manuals for Air Live SmartCube 300W
Summary of Contents for Air Live SmartCube 300W
-
Page 1: Quick Installation Guide
OvisLink Tech Support Team for further assistance For any other question, please read the user SmartCube 300W manual in the CD or mail to tech@airlive.com for technical support. Intelligent 3MP Wireless Cube IPCAM with Temperature and Humidity Sensor... - Page 2 SmartCube 300W Package Contents I/O Interface Please check the package contents and contact your distributor if any part is missing. 802.11n Wi-Fi SmartCube 300W 5V AC Power Adapter Mounting Accessories (Screws / Plastic Anchors) Quick Installation Guide Micro SD Slot...
- Page 3 I/O Interface Remove Cover box Remove Cover box Power Input Ethernet Port WPS and Reset Button...
- Page 4 Remove Cover box Assemble the bracket and the stand Assemble the bracket and the stand...
- Page 5 Assemble the bracket and the stand Assemble the bracket and the stand...
- Page 6 Assemble the bracket and the stand Assemble the bracket and the stand...
- Page 7 Assemble the bracket and the stand Plug the adapter Plug the power cable into the camera.
-
Page 8: Mount The Camera
Power on SmartCube 300W Mount the camera When SmartCube 300W is powered on, the Please use three screws to fix the camera. green led will be on first. After SmartCube 300W is ready, the red len will be on and the... -
Page 9: Wifi Connection
Adjust the View of the Camera WiFi Connection There are two ways to connect to WiFi 1. WPS connection.(WPS function only supports that the router is in WPA2 AES security protocols or no protected password.) 2. Connect wire to setup wireless connection. - Page 10 Click WPS button on the router first. Click Reset/WPS button on SmartCube 300W then the green led will be on for 2 minutes. When SmartCube 300W connects to the router sucessfully, the green led will be flashing. 12V DC Ant.
-
Page 11: Reset The Camera To Default Settings
Reset/WPS button for 10 seconds,then release the button. The red led will be off and green led will be on. After SmartCube 300W is ready, the red led will be on and the green led will be off. micro... - Page 12 Notebook. Please download IP wizard II from However, if your wireless router does not have AirLive SmartCube 300W support page a WPS button. You can configure the camera http://www.airlive.com/product/SmartCube-300W by connecting the SmartCube's LAN port to your router's LAN port by Ethernet cable.
- Page 13 Smartcube 300W You need to install the ActiveX on your PC when you first access to the camera web UI. Important Note: Please make sure you have made Internet Explorer as your default browser first.
- Page 14 "Configuration" icon to go into the configuration click on search icon. You should see 2 page. Then click on "Network"->"Wireless" "SmartCube 300W" on the list if the camera has page. Select your wireless router's SSID and made successful wireless connection to your key in the security key.
- Page 15 Mobile Wizard Wifi Setup SmartCube 300W Setup When user unplugs the Ethernet cable, please Please select setup page, click "Wizard" button. replug the power cable at the same time. Wireless connection will be rebuilt in three minutes.
-
Page 16: Time Adjustment
Time Adjustment E-mail Settings Adjust the time and date of the camera and It requires E-mail information to send the click "Next" button. counting report. - Page 17 Sounds Scenarios Setup You can adjust the sound volume on this page There are three scenarios. 1. Normal Mode 2. Door Cam Mode. 3. Store Entrance Mode. Please select the scenario to fit your environment and click "Arrow" button.
-
Page 18: Normal Mode
Normal Mode Door Cam Mode You can adjust resolution,frame rate and PIR In door cam mode, SmartCube 300W will detect motion detection in normal mode. people, send the notification to the smartphone and record video to SD card. -
Page 19: Face Detection
Store Entrance Mode Face Detection You can choose between face detection or The face detection method detect faces as the object counting to count the number of customers walk into the store customers. - Page 20 Face Detection Face Detection You can adjust the settings to fit the Face Detec on environment. Face View Installa on Facing the Entrance Orienta on Ceiling Height Less than 3.2 meter Requirement Advantage Get face shots, easy-to- setup Voice gree ng for entry only Disadvantage Recommend...
-
Page 21: Object Counting
Object Counting Object Counting "Object Counting register a count when people Object Counting require ceiling of higher 3.2 cross from zone 1 to zone 2 or vice versa. It meters for installation. The higher it is, the can have independent count for entry and exit. more accurate counting result is. - Page 22 Object Counting Object Counting You can adjust the settings to fit the Object Coun ng environment. Face View Installa on Over the top or Orienta on Side View Ceiling Height More than 3.2 meter Requirement Advantage Higher accuracy, separate gree ng voices for entry and exit.
- Page 23 Sensors Password You can set the Temp and Humidity alarm On this page you can change the password and settings on this page. Setup the wireless connection...
-
Page 24: Declaration Of Conformity
5F., NO.6, Lane 130, Min-Chuan Rd., Hsin-Tien Dist., New Taipei City 231, Taiwan Declare that the product Intelligent 3MP Wireless Cube IPCAM with Temperature and Humidity Sensor AirLive SmartCube 300W is in conformity with In accordance with 2004/108/EC Directive Clause Description ■...
