Fault Possible Cause
Control Panel has no display
12V Power turns off
Control Panel
Problems
Control Panel locked / erratic
function
No 230V supply
Charger not switched on
Battery not connected and /
or charged
Power button on control panel
No 12 volt
not switched to on
output from
Battery flat / Battery fuse
PSU
blown
Fuse blown
Equipment switched off /
unplugged
Other fault
Proposed Fix
Check batteries and fuses, turn PSU isolate
switch and charger switch on and ensure
mains supply is connected.
Check control panel connecting lead at
PSU and behind Control Panel.
Contact your Dealer.
Battery protect feature has operated to
protect the Vehicle battery and or the
Leisure battery. See 3.4C
Over voltage protection has been activated,
the control panel will display a warning. A
number of things can cause this but the
most common is the solar panel, it is worth
checking the regulator is connected correctly
and operating within the correct parameters.
Engine has been started, all equipment
has been disconnected to meet EMC
requirements. See 2.4
Observe control panel handling instructions.
Control panel software may have crashed.
Reboot control panel by turning off the PSU
isolate switch. Wait 30 seconds then turn
the switch back on. Check with your dealer
that your system has the latest software
installed, as an update may be available.
Check all above
Turn charger switch on, switch will illuminate
Install charged battery as per 3.4
Turn power on at control panel
Recharge battery, check fuses, check
charging voltage is present at battery.
Check all fuses are intact and the correct
value fuse is installed as per fuse table.
Check equipment is switched on and
connected to the 12V supply
Contact your Dealer
